Cisco Nexus 3600 Hardware Installation Guide
First Published: 2017-09-11
Americas Headquarters
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-1706
USA
http://www.cisco.com
Tel: 408 526-4000
800 553-NETS (6387)
Fax: 408 527-0883

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Nexus 36180YC-R and is the answer not in the manual?

Questions and answers

Summary of Contents for Cisco Nexus 36180YC-R

  • Page 1 Cisco Nexus 3600 Hardware Installation Guide First Published: 2017-09-11 Americas Headquarters Cisco Systems, Inc. 170 West Tasman Drive San Jose, CA 95134-1706 http://www.cisco.com Tel: 408 526-4000 800 553-NETS (6387) Fax: 408 527-0883...
  • Page 2 Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To view a list of Cisco trademarks, go to this URL: www.cisco.com/go/trademarks . Third-party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company.
  • Page 3: Related Documentation

    Release Notes Release Notes for the Cisco Nexus 3000 Series switches. Transceiver Compatibility Transceiver Modules Compatibility Information Regulatory Compliance Guides Regulatory, Compliance, and Safety Information for the Cisco Nexus 3000 and 9000 Series switches. Cisco Nexus 3600 Hardware Installation Guide...
  • Page 4 Preface Related Documentation Cisco Nexus 3600 Hardware Installation Guide...
  • Page 5 Overview of the Cisco Nexus 36180YC-R Switch The Cisco Nexus 36180YC-R (N3K-C36180YC-R) is a 1 rack unit (RU) switch with 48 25-Gigabit SFP28 ports and 6 100-Gigabit QSFP28 ports, 2 management ports, 1 console port, and 1 USB port. The switch supports both port-side exhaust and port-side intake airflow schemes.
  • Page 6 Overview of the Cisco Nexus 36180YC-R Switch The following figure shows the fan-side chassis features that you use when installing the chassis or replacing its modules. Figure 1: Fan-Side View of the Cisco Nexus 36180YC-R Chassis Power supply modules (2) Management port (RJ-45)
  • Page 7 Overview of the Cisco Nexus 36180YC-R Switch The following figure shows the port-side chassis features that you use when installing the chassis. Figure 2: Port-Side View of the Cisco Nexus 36180YC-R Chassis Beacon (BCN), Status (STS), and Environment 100-Gigabit QSFP28 ports (6)
  • Page 8 Overview Overview of the Cisco Nexus 36180YC-R Switch Cisco Nexus 3600 Hardware Installation Guide...
  • Page 9: Preparing The Site

    To prevent contaminant buildup and increased internal chassis temperatures, make sure that the operating environment is as clean as possible and free of dust and other contaminants. Do not permit smoking, food, or drinks near the switch. Cisco Nexus 3600 Hardware Installation Guide...
  • Page 10 Preparing the Site Dust and Contaminants Cisco Nexus 3600 Hardware Installation Guide...
  • Page 11: Table Of Contents

    Starting the Switch, page 19 Safety Before you install, operate, or service the switch, see the Regulatory, Compliance, and Safety Information for the Cisco Nexus 3000 and 9000 Series for important Safety Information. Warning Statement 1071—Warning Definition IMPORTANT SAFETY INSTRUCTIONS This warning symbol means danger.
  • Page 12: Preparing To Install The Chassis

    Caution Avoid UPS types that use ferroresonant technology. These UPS types can become unstable with systems such as the Cisco Nexus 3000 Series switches. These switches can have substantial current draw fluctuations because of fluctuating data traffic patterns. Ensure that circuits are sized according to local and national codes. For North America, the power supply requires a 15-A or 20-A circuit.
  • Page 13: Unpacking And Inspecting The Chassis

    Keep the shipping container in case the chassis requires shipping in the future. The switch is thoroughly inspected before shipment. If any damage occurred during transportation or any Note items are missing, contact your customer service representative immediately. Cisco Nexus 3600 Hardware Installation Guide...
  • Page 14: Installing A 1 (Ru) Chassis In A Four-Post Rack

    • Port-side exhaust airflow direction indicated with blue coloring Installing a 1 (RU) Chassis in a Four-post Rack This section describes the rack installation for the Cisco Nexus 3016, 3048, 3064T, 3064-32T, 3064-X, 3132Q, 3132Q-X, 3172PQ, 3172TQ, 3232C, 3524P-10G, 3524P-10GX, 3548P-10G, 3548P-10GX, and 36180YC-R chassis.
  • Page 15 Rear rack-mount guide aligned to the power supply and fan the chassis module end of the chassis c) Secure the front-mount bracket to the chassis using four M4 screws and tighten each screw to 12 in-lb (1.36 N·m) of torque. Cisco Nexus 3600 Hardware Installation Guide...
  • Page 16 Repeat Steps 3a and 3b to attach the other slider rail to the other side of the rack. To make sure that the slider rails are at the same level, use a level tool, tape measure, or carefully count the screw holes in the vertical mounting rails. Cisco Nexus 3600 Hardware Installation Guide...
  • Page 17 Align the two rear rack-mount guides on either side of the switch with the slider rails installed in the rack. Slide the rack-mount guides onto the slider rails, and then gently slide the switch all the way into the rack until the front rack-mount brackets come in contact with two rack or cabinet posts. Cisco Nexus 3600 Hardware Installation Guide...
  • Page 18: Installing A 1 (Ru) Chassis In A Two-Post Rack

    Installing a 1 (RU) Chassis in a Two-post Rack This section describes the rack installation for the Cisco Nexus 3000 series switch into a two-post rack. To install a switch, you must attach mounting brackets to the switch and secure the switch to the rack.
  • Page 19 • If the switch has port-side exhaust modules (fan modules with blue coloring), position the switch so that its fan and power supply modules will be in the cold aisle. b) Position the bracket so that four of its screw holes are aligned to the screw holes on the side of the chassis. Cisco Nexus 3600 Hardware Installation Guide...
  • Page 20 Installing the Chassis Installing a 1 (RU) Chassis in a Two-post Rack Rear-mounting position Number-8 Phillips flat-head screws (4 each bracket) Front-mounting position Cisco Nexus 3600 Hardware Installation Guide...
  • Page 21: Grounding The Chassis

    • You connect the chassis (at its grounding pad) to the data center ground. If the rack is fully-bonded and grounded, you can ground the switch by connecting it to the rack. Cisco Nexus 3600 Hardware Installation Guide...
  • Page 22 (see Callout 2 in the following figure). Verify that the ground wire is securely attached to the grounding lug by attempting to pull the wire out of the crimped lug. Figure 7: Grounding the Chassis Chassis grounding pad Two M4 screws used to secure the grounding lug to the chassis Cisco Nexus 3600 Hardware Installation Guide...
  • Page 23: Starting The Switch

    Connect a positive cable from the power source to the right (+) terminal on the power supply. e) Clip on the clear plastic safety cover over the power supply terminals to prevent accidental touching of these terminals. f) Turn on the power at the circuit breaker. Cisco Nexus 3600 Hardware Installation Guide...
  • Page 24 If not green, try removing the module part way from its slot and reinstalling it. • System Status LED—lit and green (if this LED is orange or red, then one or more environmental monitors is reporting a problem.) • Link LEDs for the Ethernet connector—Off Cisco Nexus 3600 Hardware Installation Guide...
  • Page 25: Connecting The Switch To The Network

    We recommend that you use this port to create a local management connection to set the IP address and other initial configuration settings before connecting the switch to the network for the first time. Cisco Nexus 3600 Hardware Installation Guide...
  • Page 26: Connecting The Management Interface

    To prevent an IP address conflict, you must complete the initial configuration and establish an IP address for the switch. Step 1 Connect the appropriate modular cable to on the switch. Step 2 Connect the other end of the cable to the switch, hub, or router. Cisco Nexus 3600 Hardware Installation Guide...
  • Page 27 Excessively removing and installing an SFP or SFP+ transceiver can shorten its life. Unless it is absolutely necessary, do not remove and insert SFP or SFP+ transceivers. To prevent damage to an optical cable and transceiver, we recommend that you disconnect cables before installing or removing transceivers. Cisco Nexus 3600 Hardware Installation Guide...
  • Page 28 Step 7 For QSFP+ transceivers equipped with a pull-tab, do the following: a) Hold the transceiver so that the identifier label is on the top. Cisco Nexus 3600 Hardware Installation Guide...
  • Page 29 If you cannot install the cable into the transceiver, insert or leave the dust plug in the cable end of the transceiver. For instructions on verifying connectivity, see the appropriate Cisco Nexus Series configuration guide. Maintaining Transceivers and Optical Cables Transceivers and fiber-optic cables must be kept clean and dust free to maintain high signal accuracy and prevent damage to the connectors.
  • Page 30 Connecting the Switch to the Network Maintaining Transceivers and Optical Cables • Inspect routinely for dust and damage. If you suspect damage, clean and then inspect fiber ends under a microscope to determine if damage has occurred. Cisco Nexus 3600 Hardware Installation Guide...
  • Page 31: Replacing Modules

    Replacing an AC Power Supply, page 28 Replacing a 1 (RU) Fan Module The 1 (RU) fan module is used in Cisco Nexus 3132Q-X, 3132Q, 3172PQ, 3172TQ, 3232C, 3548-10GX, 3548-10G, and 3524P switches. If you do not have the appropriate replacement fan module, leave the original fan module in its slot to preserve the designed airflow for the switch until you have the replacement fan module.
  • Page 32: Replacing An Ac Power Supply

    Place your other hand under the power supply to support it while you slide it out of the chassis. Either place the power supply on an antistatic surface or pack it in its packing materials. Cisco Nexus 3600 Hardware Installation Guide...
  • Page 33 Depending on the outlet receptacle on your power distribution unit, you might need the optional jumper Note cable to connect the switch to your outlet receptacle. c) Verify that the power supply is operational by checking that the power supply OK LED is green. Cisco Nexus 3600 Hardware Installation Guide...
  • Page 34 Replacing Modules Replacing an AC Power Supply Cisco Nexus 3600 Hardware Installation Guide...
  • Page 35: Rack Specifications

    See below. The cabinet or rack must also meet the following requirements: • The minimum vertical rack space per Cisco Nexus 3000 Series switch chassis must be one RU (rack units), equal to 1.75 inches (4.4 cm). • The width between the rack-mounting rails must be at least 17.75 inches (45.0 cm) if the rear of the device is not attached to the rack.
  • Page 36 • The roof should be perforated with at least a 20-percent open area. • The cabinet floor should be open or perforated to enhance cooling. The Cisco R Series rack conforms to these requirements. About Requirements for Open Racks In addition to the requirements listed in the “General Requirements for Cabinets and Racks” section on page...
  • Page 37: System Specifications

    0 to 10,000 feet (0 to 3050 m) Ambient nonoperating –1000 to 30,000 feet (–304 to 15,150 m) Switch Dimensions Switch Component Width Depth Height Cisco Nexus 36180YC-R 17.3 inches (43.9 cm) 26.9 inches (68.2 cm) 1.72 inches (4.37 cm) chassis Cisco Nexus 3600 Hardware Installation Guide...
  • Page 38: Ac Power Cables

    Cabinet Jumper Power Cord 250 VAC 2.2 feet (0.7 m) 13 A, C13-C14 Connectors HVDC Power Cables Type Power Cord Part Number Cord Set Description HVDC CAB-HVDC-3T-2M 6.6-foot (2.0 m) cable with Saf-D-Grid and three terminal connectors Cisco Nexus 3600 Hardware Installation Guide...
  • Page 39: Chassis Leds

    Chassis LEDs, page 35 • Fan LEDs, page 36 • Power Supply LEDs, page 36 Chassis LEDs This table provides information about chassis LEDs for Cisco Nexus 3000 Series switches. Component Status Description Chassis (front and On (blue) Identifies the chassis receiving the beacon signal.
  • Page 40: Fan Leds

    The module has a runtime failure and is brought offline. Power Supply LEDs This table provides information about power supply LEDs for Cisco Nexus 3000 Series switches. Component Status Description...
  • Page 41 A P P E N D I X Spare Parts Table • Spares Support Table, page 37 Spares Support Table This table provides information about spare parts for the Cisco Nexus 3000 Series switches. Product Chassis Power Supply Options Fan Options...
