- Page 1 Cisco SFS Multifabric Server Switch Shelf & Rack Ear Kit Installation Guide (Topspin 360) Part Number: OL-7733-01 Product ID: 140273...
- Page 2 Copyright © 2004 - 2005 Topspin Communications, Inc. All rights reserved. The Topspin Switched Computing System, Topspin Host Channel Adapter, Topspin Element Manager, and collateral software programs and documentation are subject to and made available only pursuant to the license agreement signed by you and Topspin, Communications, Inc.
- Page 3 Topspin Shelf and Rack Ear Kit Contents The following contents are included in this package: ______ Topspin Shelf and Rack Ear Kit for Topspin 360 Contents and Installation Guide(1) ______ Shelf (1) ______ Rack Ears (2) ______ Flat Countersink Screws (8)
- Page 5 Rack the Topspin 360 with the Optional Topspin Shelf and Rack Ear Kit The Topspin 360 can be installed using your own rack shelf. Refer to the Topspin 360 Hardware Guide for instructions on racking the server switch without the optional Topspin shelf.
- Page 6 Install the Rack Ears Determine the end of the Server Switch to position at the front of the rack. Install the rack ears using the screws provided. Install the Shelf Kit Separate the sliding piece from the main shelf unit.
- Page 7 1U hash mark. The switch and shelf will take up 5Us for the Topspin 360 or 6Us. Rear Rack Post Figure 2-3: Align Bracket with Rear Post Screw the brackets to the rack, using screws that fit your rack.
- Page 8 Align the back end of the shelf with the exposed ends of the mounted brackets in the rack. The back of the shelf unit is the straight end (opposite the end with flanges). There are channels inside the shelf into which the brackets slide. Figure 2-5: Align Shelf with Installed Brackets Push the shelf into the rack until the front flanges of the shelf meets the rack posts.
- Page 9 Attach the front of the shelf to the rack posts, using screws that fit your rack. (Optional) You may want to wait to completely tighten screws until you have placed the switch in the rack. This will allow you to make slight adjustments.
-
Page 10: Secure The Chassis
Lift the Chassis onto the Shelf Place the switch in the rack. NOTE: There are no side rails for the current Topspin 360 chassis. Secure the Chassis Attach the chassis handles to the rack posts, using screws that fit your rack.
