Step 3:
Press and hold the pair button for 3 seconds or more until both
RED and GREEN LEDs blink together.
Step 4:
From the APP, press "+" camera to search for the Focus72, then
follow the instructions from the APP.
Via LAN
Step 1:
Connect the LAN cable to the camera's LAN socket and the
other end to your router, and screw in the waterproof cover.
Step 2:
Insert the power adapter connector into the camera's power
socket and screw in the waterproof cover. Connect the power
adaptor plug to a suitable mains socket and wait for the LED to
start blinking RED.
Step 3:
Press and hold the pair button for 3 seconds or more until both
RED and GREEN LEDs blink together.
Step 4 :
From the APP, press "+" camera to search for the Focus72, then
follow the instructions from the APP.

3.1.2 Install your Camera

NOTE: We recommend you set up your camera with your router and make
sure that the camera operates fully with your Wi-Fi / LAN in the location you
are going to mount it, before you start to drill holes for the installation.
A. Drill the Screw Holes
• Mark the position on the wall using the camera base plate as a template,
making sure the cable guide in the base plate is correctly aligned for the
direction you want the camera wires to leave the mounting, unless you
pass them directly through the wall behind the base plate.
• Drill 3 holes (4.5mm diameter) and hammer the expansion plugs (included)
into the holes as needed.
• If you want to pass the camera wires through the wall behind the base plate,
drill a 22mm diameter hole in the midpoint between the screw holes.
Getting started - Connecting Devices
4.5mm
45.73 mm
9
