3.1.4 Status of LED Indication:

Status
Power Up Initialising
Connecting to Wi-Fi router
In pair mode after press & hold
the Pair Button for 3sec
During Video Streaming
Connected to Server but
without video streaming
Connected to router
previously but ping to Server
failed
Note: You can only setup via a compatible smartphone or tablet and not via a PC.
12
LED Behaviour
GREEN and RED LED ON for around 5 sec
Then GREEN LED ON for 10 sec
RED LED Blink every 2 sec
Both RED and GREEN LEDs blink together
The LED blinks GREEN every second
The LED is on GREEN continuously
The LED blinks RED every second
Getting started - Connecting Devices
