Signal Input; Digitizing Probe Input - MachMotion IO6 V4.0 Manual

5. +24V signal input
User Input
+24V Signal Input
GND
6.

Digitizing Probe Input

+5 volt is connected to GND by probe
On Board 5V
+12V
+5V
Probe Signal
GND
XX-X
X-XXL
On Board
XX-X
X-XXL
15
IO6 Board
GND
330ohm
4.7nf
IO6 Board
330ohm
4.7nf
+24V
+5
V
Jumper
3.9K
GND
GND +24V
+5
V
Jumper
3.9K
GND
