Limit Switch Input; Pnp Proximity Sensor; Opto Sensor Input - MachMotion IO6 V4.0 Manual

1. +24 V Limit Switch Input
NO or NC Limit Switch

2. PNP Proximity Sensor

(Proxy switch) PNP 24V is preferred, such as Jameco Electronics TS12-02P-1

Opto sensor input

(Omron EE-SX872P PNP Sensor, sensing 24 volts) (PNP preferred)
Sensor
+V Brown
Load Black
0v Blue
IO6 Board
330ohm
XX-X
4.7nf
X-XXL
IO6 Board
330ohm
XX-X
4.7nf
X-XXL
13
GND +24V
+5
V
Jumper
3.9K
GND
GND +24V
+5
V
Jumper
3.9K
GND
