Polycom SoundStation2 Nortel Specifications page 2

Polycom SoundStation2
®
Architecture
• Tabletop console contains audio processing
functions and keypad. Wall module contains power
and PBX line interfaces.
• Cables consist of 21 ft (6.4 m) single-cord
connection to tabletop console and 6 ft (1.8 m)
connection to RJ-11 telephone jack. Optional
Extended microphone modules connect to console
via 7 ft. (2.1 m) cables
Console
Size (L x W x H)
• 14.5 x 12.25 x 2.5 in
• (36.8 x 31.1 x 6.4 cm)
Weight
• 1.75 lb. (0.8 kg)
Power
• 110V 60Hz AC / 220V 50 Hz AC (depending on
country-specific SKU)
Network interface
• Nortel Meridian Digital PBX
PBX Compatibility
• Compatible with
- Nortel Meridian
- Meridian 1 (option 11 to 81)
- SL-1 or SL-100
User interface*
• User selectable ring tones
• Configurable soft keys for easy dialing of voice
conferencing services
• Multi-lingual support: English, German, French,
Italian, Spanish, Portuguese, Norwegian
• Password protected configuration settings for
administrators
Caller ID and phone book
• Phone book/speed dial list – up to 25 entries
Users receive the same great quality and features as the Polycom SoundStation2 conference phone, including:
Polycom Acoustic Clarity Full Duplex
3 Cardiod microphones
10ft Microphone Pickup range
Intelligent microphone mixing
Dynamic Noise Reduction
Volume (adjustable up to 94 dBA @ 0.5m)
User selectable ring tones
12-key telephone keypad
Mute, Volume up/down keys
Mute, Conference keys
Graphical Backlit LCD
Configurable conference Speed Dial Key
3 Context sensitive soft-keys
Multi-lingual User Interface
CallerID
25 Entry Phone Book
RCA Auxiliary Audio Jack
Applications Port
EX microphone jacks
Polycom Worldwide Headquarters
4750 Willow Road, Pleasanton, CA 94588
1.800.POLYCOM or +1.925.924.6000
www.polycom.com
© 2009, Polycom, Inc. All rights reserved. POLYCOM®, the Polycom "Triangles" logo and the names and marks associated with Polycom's products are trademarks and/or service marks of Polycom, Inc. and are
registered and/or common law marks in the United States and various other countries. All other trademarks are property of their respective owners. No portion hereof may be reproduced or transmitted in any form
or by any means, for any purpose other than the recipient's personal use, without the express written permission of Polycom.
Avaya2490
®
Keypad
• 12-key telephone keypad
• On-hook/off-hook, conference, mute, volume up/
down keys, menu, navigation keys*
• 3 context sensitive soft keys* including redial, hold,
programmable conference key
Console loudspeaker
• Frequency response: 300 to 3300 Hz
• Volume: adjustable to 94 dBA SPL (peak) volume
at 0.5 meters
Console microphones
• 3 cardioid microphones 300 to 3500 Hz
Audio
• Polycom Acoustic Clarity full duplex – IEEE 1329
Type 1
• Up to 10 ft. microphone pick-up range
• Gated microphones with intelligent microphone
mixing
• Dynamic noise reduction
Interfaces
• 2 EX microphone connections*
• Applications Port* for connection to other
communication devices such as mobile phones†
and computers
• RCA Auxiliary audio jack
Accessories
• 2 cardioid extension microphones 300 – 3500 Hz
(for EX model only)
Regulatory compliance
• NA Cl/C-UL
• FCC Part 68
• FCC Part 15 Class B
• Canadian ICES-003
• CE Mark (R & TTE Directive)
Environmental requirements
• Operating temperature: 40° - 104°F (5° - 40°C)
• Relative humidity: 20% - 85% (noncondensing)
• Storage temperature: -22° - 131°F (-30° - 55°C)
Specifications
Recommended room conditions
• Reverberation time: <0.5 seconds
• Noise level: <48 dBa
SoundStation2 ships with:
• Tabletop phone console
• 21 ft. (6.4 m) cord to console
• 6 ft. (1.8 m) telco cable to RJ-11 telephone jack
• User documentation (user guide CD, quick
installation guide, registration card)
Warranty
• 1 year
Part Numbers (North America)
• 2200-17120-001: SoundStation2 Direct Connect
for Nortel
• 2200-16155-001: Extension microphone kit
† SoundStation2 uses a cable that connects to
a standard 2.5mm headset connector. If your
mobile phone model does not support this type of
connection you will need an adapter (not included).
Connecting the SoundStation2 to a mobile phone
is analogous to connecting a headset to a mobile
phone. Not all mobile phone models recognize the
SoundStation2 as a headset. For a list of mobile
phones that are known to work with SoundStation2,
please consult www.polycom.com.
Part No. 3726-17476-001 Rev 082409
