2
Select an option:
• Select the time the active track began.
• Select Entire Log.

Viewing a List of Saved Tracks

Select User Data > Tracks > Saved Tracks.
Editing a Saved Track
1
Select User Data > Tracks > Saved Tracks.
2
Select a track.
3
Select Edit Track.
4
Select an option:
• Select Name, and enter the new name.
• Select Track Color, and select a color.
Saving a Track as a Route
1
Select User Data > Tracks > Saved Tracks.
2
Select a track.
3
Select Edit Track > Save Route.
Browsing for and Navigating a Recorded Track
Before you can browse a list of tracks and navigate to them, you
must record and save at least one track
1
Select User Data > Tracks > Saved Tracks.
2
Select a track.
3
Select Follow Track.
4
Select an option:
• To navigate the track from the starting point used when
the track was created, select Forward.
• To navigate the track from the destination point used
when the track was created, select Backward.
5 Review the course indicated by the colored line.
6
Follow the line along each leg in the route, steering to avoid
land, shallow water, and other obstacles.
Deleting a Saved Track
1 Select User Data > Tracks > Saved Tracks.
2
Select a track.
3 Select Delete.
Deleting All Saved Tracks
Select User Data > Manage Data > Clear User Data >
Saved Tracks.
Retracing the Active Track
The track currently being recorded is called the active track.
1
Select User Data > Tracks > Follow Active Track.
2 Select an option:
• Select the time the active track began.
• Select Entire Log.
3
Review the course indicated by the colored line.
4
Follow the colored line, steering to avoid land, shallow water,
and other obstacles.
Clearing the Active Track
Select User Data > Tracks > Clear Active Track.
The track memory is cleared, and the active track continues
to be recorded.
Managing the Track Log Memory During Recording
1
Select User Data > Tracks > Active Track Options.
2
Select Record Mode.
3
Select an option:
Navigation with a Chartplotter
(Tracks, page 12).
• To record a track log until the track memory is full, select
Fill.
• To continuously record a track log, replacing the oldest
track data with new data, select Wrap.
Configuring the Recording Interval of the Track Log
You can indicate the frequency at which the track plot is
recorded. Recording more frequent plots is more accurate but
fills the track log faster. The resolution interval is recommended
for the most efficient use of memory.
1
Select User Data > Tracks > Active Track Options >
Record Interval > Interval.
2
Select an option:
• To record the track based on a distance between points,
select Distance > Change, and enter the distance.
• To record the track based on a time interval, select Time >
Change, and enter the time interval.
• To record the track plot based on a variance from your
course, select Resolution > Change, and enter the
maximum error allowed from the true course before
recording a track point.
Deleting All Saved Waypoints, Routes, and
Tracks
Select User Data > Manage Data > Clear User Data > All >
OK.
Auto Guidance
The Auto Guidance feature is based on electronic chart
information. That data does not ensure obstacle and bottom
clearance. Carefully compare the course to all visual sightings,
and avoid any land, shallow water, or other obstacles that may
be in your path.
NOTE: Auto Guidance is available with premium charts, in some
areas.
You can use Auto Guidance to plot the best path to your
destination. Auto Guidance uses your chartplotter to scan chart
data, such as water depth and known obstacles, to calculate a
suggested path. You can adjust the path during navigation.
Setting and Following an Auto Guidance Path
1 Select a destination (Destinations, page
2
Select Navigate To > Auto Guidance.
3
Review the path, indicated by the magenta line.
4
Select Start Navigation.
5
Follow the magenta line, steering to avoid land, shallow
water, and other obstacles.
NOTE: When using Auto Guidance, a gray segment within
any part of the magenta line indicates that Auto Guidance
cannot calculate part of the Auto Guidance line. This is due to
the settings for minimum safe water depth and minimum safe
obstacle height.
Creating an Auto Guidance Path
1
Select Navigation > Routes & Auto Guidance Paths > New
> Auto Guidance.
2
Select SELECT, and choose a destination point.
Filtering a List of Routes and Auto Guidance Paths
You can filter a list of routes and Auto Guidance paths to quickly
find a saved destination.
1
Select MENU > Filter.
2 Select an option.
CAUTION
10).
13
