Network operation

Ethernet connection

This section provides the following information for operating the instrument on

a local LAN network:

How to conﬁgure the instrument for operation on an IP network

How to conﬁgure the instrument to send and/or receive SNMP remote

commands

How to use a Web browser to start a remote application to enable control

of the instrument, or to download the Event and Diagnostic log ﬁles, or to

capture images of the instrument display

Connect the instrument to your network using an Ethernet cable. You can connect

it directly to the instrument or through a HUB, as shown below.

Figure 10: Connecting to ethernet
