1
SAFETY ........................................................ 3
2
INSTALLATION ............................................ 4
2.1
Aligning the appliance........................................................ 4
2.2
Electrical connection .......................................................... 4
2.3
Water connection................................................................ 4
3
OPERATION ................................................. 5
3.1
Control panel....................................................................... 5
3.2
Display ................................................................................. 5
3.3
Pushbuttons / Additional functions (Sa-Sc) .................... 6
3.4
Pushbuttons / Programme selection (S1-S6)................... 7
3.5
Special functions ................................................................ 8
4
COMPONENTS........................................... 10
4.1
Operating module ............................................................. 10
4.2
Display module (optional) ................................................ 10
4.3
Power module ................................................................... 10
4.4
Actuator ............................................................................. 13
4.5
Aqua sensor (optional) ..................................................... 14
4.6
Aqua Stop valve ................................................................ 15
4.7
Info light (optional)............................................................ 16
4.8
NTC .................................................................................... 17
4.9
Salt and rinse-aid indicators (optional)........................... 18
4.10
Optical low rinse-aid sensor (optional) ........................... 19
4.11
Dispenser........................................................................... 20
SL6KLN1AU_ara_en_a_638_X.doc - 15.02.08
R
E
P
A
I
R
I
N
S
T
R
U
C
T
I
O
N
R
E
P
A
I
R
I
N
S
T
R
U
C
T
I
O
N
R
E
P
A
I
R
I
N
S
T
R
U
C
T
I
O
N
Dishwasher
4.12
Dispenser (top dispenser) ............................................... 21
4.13
Instantaneous water heater ............................................. 22
4.14
Detergent-solution pump ................................................. 23
4.15
Level sensor with safety function ................................... 24
4.16
Filter system ..................................................................... 25
4.17
Spray system .................................................................... 26
4.18
Rinsing and pumping system.......................................... 27
4.19
Door spring ....................................................................... 28
4.20
Circulation pump (SICASYM) .......................................... 29
4.21
Water inlet with heat exchanger ...................................... 30
4.22
Water points...................................................................... 32
5
FUNCTIONS................................................33
5.1
3 in 1 detergents ............................................................... 33
6
REPAIR .......................................................34
6.1
Operating module ............................................................. 34
6.2
Replacing the Aqua Stop valve ....................................... 35
6.3
Worktop (optional)............................................................ 36
6.4
Removing and installing dispenser ................................ 37
6.5
Removing and installing circulation pump .................... 38
6.6
Detergent-solution pump ................................................. 40
6.7
Removing and installing hinge........................................ 41
6.8
Water softening system ................................................... 43
6.9
Instantaneous water heater ............................................. 44
6.10
6.11
Replacing the door seal ................................................... 46
Seite 1 von 49
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Kleenmaid SL6KLN1AU
Summary of Contents for Kleenmaid SL6KLN1AU
-
Page 1: Table Of Contents
Dishwasher 4.12 Dispenser (top dispenser) ..........21 SAFETY ............3 4.13 Instantaneous water heater ..........22 INSTALLATION ..........4 4.14 Detergent-solution pump ..........23 4.15 Level sensor with safety function ........24 Aligning the appliance............4 4.16 Filter system ..............25 Electrical connection ............ - Page 2 6.12 Diagnosis aids..............47 TECHNICAL SPECIFICATIONS ....48 General technical specifications ........48 SL6KLN1AU_ara_en_a_638_X.doc – 15.02.08 Seite 2 von 49...
-
Page 3: Safety
SAFETY WARNING DANGER Comply with the following instructions: Repairs may be carried out by a qualified electrician only! If conducting the test in accordance with VDE 0701 via the connector, The user may be put at risk and injured by improper repairs! the heater (instantaneous water heater) must be tested directly for insulation faults due to all-pole disconnection (relays;... -
Page 4: Installation
INSTALLATION Water connection If the appliance is connected to the drain with the standard hose Aligning the appliance length, the max. permitted height from the floor is 90 cm. If the drainage hose is extended, a max. height of 80 cm must not be To ensure a perfect locking function and prevent leaks in the area of exceeded. -
Page 5: Operation
OPERATION 3.2.2 Display (at front) The following symbols can be indicated via the optional display Control panel module: The control panel here has maximum features (A) Timer programming symbol (B) Check water supply (optional) Display (C) Sensor check 3.2.1 Display control (on top) When a programme starts, the values of the NTC and the Aqua sensor are checked. -
Page 6: Pushbuttons / Additional Functions (Sa-Sc)
(E) Hygienic rinsing symbol 3.3.3 Top basket (optional) Depending on the programme and special function, the hygienic rinsing symbol is displayed from the final rinse. If the The top basket button must be pressed if only the top basket is to be door is opened during this time, the symbol goes out and is no rinsed. -
Page 7: Pushbuttons / Programme Selection (S1-S6)
Pushbuttons / Programme selection (S1–S6) 3.4.4 ECO 50° The programme consists of a wash cycle at 50°, one intermediate 3.4.1 Auto 65°–75° rinse cycle, final rinse at 65° and a drying cycle. The Aqua sensor is not active in this programme. Please ensure that the utensils are Two Aqua sensor decisions are made while the programme is washed in the bottom basket only until the temperature is reached. -
Page 8: Special Functions
Special functions 3.5.3 Setting the buzzer Hold down the S4 button and switch on the appliance. The set value is indicated on the display. The set value increases by one each time the 3.5.1 Setting the hardness range S4 button is pressed. The volume setting can be changed between 0 Hold down the S3 button and switch on the appliance. - Page 9 3.5.5 Programme reset Press the S2 and the S4 buttons for 3 seconds while the appliance is on. Close the door; the pump is actuated for approx. one minute. Then close the detergent dispenser to reset the dispenser. SL6KLN1AU_ara_en_a_638_X.doc – 15.02.08 Seite 9 von 49...
-
Page 10: Components
COMPONENTS Power module Operating module 4.3.1 Tap turned off If the filling level (f1) is not reached after 3½ minutes, the control re- mains in this position and waits until the level has been reached. The buzzer sounds to indicate a filling fault. The message “Check water supply”... - Page 11 4.3.4 Power failure The electronics module has a power failure memory function which ensures that the current rinse programme continues in the event of a power failure or programme interruption. 4.3.5 Sensors All outgoing signals from the door switch, the level switch, the NTC sensor and the refill switches are recorded and evaluated by the microprocessor at the required time.
- Page 12 4.3.6 Consumers The consumers such as the the valves, the detergent and rinse aid dispensers (actuator) are actuated by triacs (see photo). The circula- tion pump, drainage pump and the instantaneous water heater are switched on by relays. Before replacing a module, start the customer service test programme.
-
Page 13: Actuator
Actuator The thermohydraulic system consists of a metal cylinder with plunger. The cylinder is filled with a substance which expands greatly when heated. The heat source is a PTC (positive temperature coefficient) (1) which is in direct contact with the metal cylinder (4). A strong pressure spring (3) returns the plunger (6) back to its original position when the heat source is switched off. -
Page 14: Aqua Sensor (Optional)
48 programme structures are possible in the automatic programme. Aqua sensor (optional) In each programme sequence in which the Aqua sensor is active the sensor is also calbrated. If the calibration is defective, a fault is written to the fault memory of the module, the measurement is set to turbid and a maximum pro- gramme sequence occurs. -
Page 15: Aqua Stop Valve
Aqua Stop valve The Aqua Stop valve consists of two solenoid valves (A) in a row, the filler and safety valves. These valves are actuated in parallel. There are two filters on the screw connection for the tap. Under the filters is the flow limiter. -
Page 16: Info Light (Optional)
Info light (optional) The user is provided with additional information by fully integratable models with a programme status display visible from the outside (info light). The info light consists of an LED and a fibre-optic cable. The light is bundled via the fibre-optic cable and is projected as a red light spot on the subsurface in front of the dishwasher while the programme is running. -
Page 17: Ntc
The utilised temperature safety switch (>85 °C) is combined with the NTC sensor. If a fault occurs, the heater is switched off at a water temperature of 85 °C (operates in switching mode). Temperature in °C Resistance in kW Tolerance +/– °C 48.4 38.5 16.5... -
Page 18: Salt And Rinse-Aid Indicators (Optional)
Salt and rinse-aid indicators (optional) The dispenser contains a float with an integrated permanent magnet (A). The magnetic field actuates a reed switch on the outside of the dispenser. The lamps of the refill indicators in the control panel are switched on via this reed switch. -
Page 19: Optical Low Rinse-Aid Sensor (Optional)
4.10 Optical low rinse-aid sensor (optional) The optical low rinse-aid sensor consists of a transmitter diode and a receiver diode. A light beam is transmitted from the transmitter diode (A) to the receiver diode (B) via a prism (C). If the dispenser is full, the light beam in the prism is scattered. -
Page 20: Dispenser
4.11 Dispenser Dosing plunger Magnetic float Switching core Reed contact (optional) Actuator Optical sensor (optional) The release mechanism is activated by an actuator (C). When the actuator is actuated for the first time, the detergent-dispenser cover is opened. At the same time the release pawl engages with the switching core (B) of the rinse-aid lever so that when the actuator (C) is activated again, the dosing plunger (A) is lifted off the rinse aid. -
Page 21: Dispenser (Top Dispenser)
4.12 Dispenser (top dispenser) The detergent chamber in the top dispenser can be swivelled out of the dispenser by pressing the side button. This facilitates filling. The release mechanism is actuated by a coil which is actuated by impulses emitted by the electronics module (detergent dispenser 20 sec. -
Page 22: Instantaneous Water Heater
4.13 Instantaneous water heater Technical specifications: The instantaneous water heater is installed in the water circuit for the spray arms. When the detergent solution flows through the instan- Designation Value Unit taneous water heater, a rubber membrane (B) attached to the flange Nominal voltage 230–240 actuates the safety pressure switch (D) for the heating element (C). -
Page 23: Detergent-Solution Pump
4.14 Detergent-solution pump The detergent-solution pump is flange-mounted on the pump sump. It pumps the detergent solution out of the appliance. Technical specifications: Designation Value Unit Nominal voltage 230 - 240 Frequency Ω Resistor approx. 110 - 260 Delivery height Delivery capacity SL6KLN1AU_ara_en_a_638_X.doc –... -
Page 24: Level Sensor With Safety Function
4.15 Level sensor with safety function If the dishwasher controller or components malfunction, causing the machine to overfill, the valve combination is closed via the safety system, shutting off the water supply. The drainage pump is switched on via the safety level switch (B). Pumping continues until the safety level switch (B) switches back again. -
Page 25: Filter System
4.16 Filter system The rough filter cylinder must be locked firmly to the pump sump (observe marking) in order to prevent dirt particles penetrating the rinsing circuit. 3-stage filter system 4-stage filter system A Coarse filter E Rinsing tank B Fine filter cylinder F Pump sump C Surface filter G Supply pipe to upper spray arm... -
Page 26: Spray System
4.17 Spray system The rotor spray system consists of three spray levels, the lower spray arm (E), the upper spray arm (F) and the roof shower head (A). Water is supplied to the upper spray arm (F) and the roof shower head (A) via the supply pipe (C) attached to the inside of the tank rear panel. -
Page 27: Rinsing And Pumping System
The circulation (D) and drainage pumps (H) as well as the 4.18 Rinsing and pumping system instantaneous water heater (C) are connected to the pump sump (G) via plug-and-socket connections. The instantaneous water heater (C) is also screwed securely to the pump sump (G). The filter system consists of fourfold filtration. -
Page 28: Door Spring
4.19 Door spring If the furniture doors are very heavy (e.g.: marble), the tensile force The door spring compensates for the weight of the furniture front. of the standard installed springs and maximum pretension of the spring tensioner is no longer adequate. In this case stronger door springs (see table) may be used. -
Page 29: Circulation Pump (Sicasym)
4.20 Circulation pump (SICASYM) Technical specifications The circulation pump is driven by a two-pole single-phase a.c. motor. Designation Value Unit The switching of the two motor windings with the motor capacitor is Nominal voltage 230 - 240 actuated either via electronics or a relay on the motor connection via the module . -
Page 30: Water Inlet With Heat Exchanger
4.21 Water inlet with heat exchanger When the filling valve has been opened, the water flows towards the integrated inlet via the free flow channel and into the water softening system and as soft water into the heat exchanger. When the regeneration chamber has filled up, the water flows into the restricting funnel of the level sensor via the overflow channel. - Page 31 4.21.1 Filling process for appliances with heat exchanger During the initial water inflow for the rinse programme this volume of The electronics measure the time between the opening command of water compensates for the loss of water which is used to wet the dry the filling valve and the closing of the level switch (f1).
-
Page 32: Water Points
4.22 Water points Technical specifications: The water points are responsible for alternate rinsing and for different rinsing pressures. They consist of a synchronous motor with gears, Designation Value Unit cam disc (B) , microswitch (A) and locking disc (C). The synchronous Nominal voltage (synchronous motor) 230–240 motor is actuated via a triac. -
Page 33: Functions
FUNCTIONS 3 in 1 detergents 5.1.1 Detection function If combined detergent products (e.g. 3 in 1) are used, the drying result will be worse. To improve the drying result, a special programme se- quence with less water is started in the intermediate rinse cycles. In addition, the final rinse temperature is increased by 3K (as for inten- sive drying). -
Page 34: Repair
REPAIR 6.1.2 Installation Operating module ► Push module from below into the support plate until the two catches on the module housing engage in the support plate. 6.1.1 Removal When installing, ensure that ► Remove the furniture front (if fitted) ►... -
Page 35: Replacing The Aqua Stop Valve
Replacing the Aqua Stop valve ► Open the housing ► Disconnect the inlet hose ► Cut through the electric connecting cables ► Strip the insulation off the cable ends ► Push the shrink-fit hose over the cable ► Connect electric cables to the insulating sleeves (1.) ►... -
Page 36: Worktop (Optional)
Worktop (optional) 6.3.1 Removal Catch tappets are located on the rear right and left hand sides of the worktop. ► Press up the catch tappets ► Push back the worktop and lift off 6.3.2 Installation ► Insert worktop into the guide ►... -
Page 37: Removing And Installing Dispenser
Removing and installing dispenser 6.4.1 Removal Wear protective gloves; risk of cuts. ► Unscrew the outer door ► Leave top basket in the appliance and close the door ► Remove the electrical connections ► Using a screwdriver, lift the retention plates (A) stamped out of the inner door off the catches (B). -
Page 38: Removing And Installing Circulation Pump
Removing and installing circulation pump 6.5.2 Installation ► Prior to installation, lubricate the seal with washing-up liquid. 6.5.1 Removal ► Connect pump to the pump housing ► Remove side panels and base plate ► Loosen connection between stainless steel container and plastic Leaks base pan, (2 screws at front and 2 screws at rear) ►... - Page 39 6.5.4 Installing the slide ring seal Sluggish or blocked fan impeller ► Ensure that the spacer ring is re-attached to the motor shaft. ► Press slide ring seal into the pump housing ► Manually rotate fan impeller firmly onto the motor shaft ►...
-
Page 40: Detergent-Solution Pump
Detergent-solution pump 6.6.2 Installation ► Insert detergent-solution pump 6.6.1 Removal ► Rotate detergent-solution pump to rear until the locking lever ► Unscrew base panel and base plate engages ► Press lever (1) to right and disengage ► Screw on base plate and base panel ►... -
Page 41: Removing And Installing Hinge
Removing and installing hinge 6.7.1 Removal ► Unscrew outside door, base panel, angle strip and side panels. ► Detach tension cord (E) from hinge lever (B) ► Unscrew hinge lever (B) from the inner door ► Disengage bearing bush (C) and remove hinge lever (B) ►... - Page 42 6.7.2 Installation ► Insert spring clamp (D) into the hinge plate (A) ► Insert hinge plate (A) into the base pan ► Screw hinge plate (A) to the frame and base pan ► Insert hinge lever (B) with the bearing bush (C) into the hinge plate ►...
-
Page 43: Water Softening System
Water softening system 6.8.2 Installation 6.8.1 Removal Please note before and during installation Unscrew outside door, base panel, angle strip and side panels. ► Place the seal on the filler neck of the salt Detach the tension cords from the hinge levers dispenser Remove the screws which connect the base pan to the hinge ►... -
Page 44: Instantaneous Water Heater
Instantaneous water heater 6.9.2 Installation The instantaneous water heater is installed in reverse sequence 6.9.1 Removal Unscrew outside door, base panel, angle strip and side panels. Detach the tension cords from the hinge levers. Unscrew the screws which connect the base pan to the hinge plates. -
Page 45: Smooth Running Pull-Out Rail For Top Basket (Optional)
6.10 Smooth running pull-out rail for top basket 6.10.2 Installation (optional) ► Bend back fixing brackets 6.10.1 Removal ► Insert pull-out rail and press forwards until it engages Fixing brackets may break off ► Carefully bend fixing brackets. If the fixing bracket breaks, the appliance can no longer be repaired. -
Page 46: Replacing The Door Seal
6.11 Replacing the door seal The new seal must be adjusted prior to installation. Adjusting the seal ► Prior to insertion, ensure that the seal lip is pointing towards the middle of the rinsing tank, otherwise there will be leaks in the area of the door ►... - Page 47 6.12 Diagnosis aids Transparent door: Material no.: 21 4115 – appliance dimension 81 cm Material no.: 21 4114 – appliance dimension 86 cm Test prod: Material no.: 340730 (remove the components from the module before measuring the resistance) Protective gloves: Material no.: size 9 = 340728 size 10 = 340729...
- Page 48 TECHNICAL SPECIFICATIONS General technical specifications Voltage / frequency 230–240 V / 50 Hz Connected load 2.3 kW Heat output 2.15 kW Fuse 10 / 13 A SL6KLN1AU_ara_en_a_638_X.doc – 15.02.08 Seite 48 von 49...
-
Page 49: Seite 1 Von
7.1.1 Consumption rates Auto 65–75° Auto 55–65° Auto 35–45° Eco 50° Quick 45° Prerinse Plate Intensive 70° warming Power 75 Duration in min. 105–135 85–140 70–80 with a half load 95–105 85–130 with Vario Speed 86–90 71–75 50–54 65–70 Current consumption in kWh 1.45–1.75 1.00–1.60 0.70–0.75...
