Specifications

Air Velocity
m/s (meters per sec)
km/h (kilometers/hour)
ft/min (feet per minute)
mph (miles per hour)
knots (nautical MPH)
Air Flow
CMM (cubic meters/min)
CFM (cubic ft/min)
Air Temperature
Circuit
Display
Sampling rate
Sensors
Automatic Power off
Operating Temperature
Storage Temperature
Operating Humidity
Storage Humidity
Operating Altitude
Battery
Battery life
Battery Current
Weight
Dimensions
Copyright © 2007 Extech Instruments Corporation
All rights reserved including the right of reproduction in whole or in part in any form.
Range Resolution
0.40 - 30.00 m/s
1.4 - 108.0 km/h
80 – 5900 ft/min
0.9 – 67.0 mph
0.8 to 58.0 knots
Range Resolution
3
0-9999 m /min
3
0-9999 ft /min
Range Resolution
o o
14 - 140 F (-10 - 60 C)
Custom LSI microprocessor circuit
Dual function 0.5" (13 mm) 4-digit LCD
1 reading per second approx.
Air velocity/flow sensor: Conventional angled vane arms with
low-friction ball bearing
Temperature sensor: NTC-type precision thermistor
Auto shut off after 20 minutes to preserve battery life
32°F to 122°F (0°C to 50°C)
o o
14 to 140 F (-10 to 60 C)
<80% RH
<80% RH
2000 meters (7000ft) maximum
One 9 volt (NEDA 1604) battery
80 hours approx. (if the Backlight is used continuously, battery
life will be reduced significantly)
8.3 mA DC approx.
1.6 lbs. (725g) including battery & probe
Main instrument: 7.0 x 2.9 x1.2" (178 x 74 x 33mm)
Sensor Head: 2.75" (70mm) Diameter
8
Accuracy
0.01 m/s ± (3% + 0.20 m/s)
0.1 km/h ± (3% + 0.8 km/hr)
1 ft/min ± (3% + 40 ft/m)
0.1 mph ± (3% + 0.4 MPH)
0.1 knots ± (3% + 0.4 knots)
Area
2
1 0 to 9.999m
2
1 0 to 9.999ft
Accuracy
o o o
0.1 F/C 4.0 F (2.0 C)
AN100-EU V3.0 11/07
