- Page 1 Instruction Manual ICM A6N Clamp Meter 600V 750Vac 1000Vdc ...
-
Page 2: Safety Information
Safety Information Read and understand this Instruction Manual completely before using this instrument. Failure to observe the warnings and cautions in this Instruction Manual may result in injury or death, or damage to the instrument and other equipment or property. If this instrument is used in a manner not specified in these instructions, the protec- tion provided by the instrument may be... - Page 3 - Verify the instrument is operating correctly by measuring a known voltage before use. If in doubt, have the instrument serviced. - Do not apply more than the rated voltage as marked on the instrument between terminals, or between any terminal and earth ground.
-
Page 4: Maintenance
Maintenance Do not attempt to repair this Instrument. It contains no user-serviceable parts. Repair or servicing should only be performed by qualified personnel. This instrument should be calibrated yearly, or more frequently if used in harsh conditions or if it is suspected of being inaccurate. For calibration and repair contact RS Components - the address is given at the end of these instructions. -
Page 5: Power On/Off
Power On / Off • When first turned on, the instrument displays the remaining capacity of the battery. Replace the battery when 0% is shown or the low battery symbol “<” remains visible in the display. After a successful battery self-test, the instrument will automatically select resis- tance (Ω)/continuity mode. -
Page 6: Ac Current Measurement
Self-Testing Aid Fail of usage Ready to use • Do not attempt to measure while power- ing up, as it will cause the self-test to fail. Caution If “FAIL” is shown in the display, do not use the instrument as an internal fault has occurred. - Page 7 AC V / DC V Caution When connecting the test leads to the circuit or device, connect the black lead before the red lead. When removing the test leads, remove the red lead before the black lead. • Input Impedance Note : The input impedance is≧4K for an input voltage up to 30V and increases automatically with input voltage to approxi-...
- Page 8 Continuity Resistance / Diode EN - 8...
- Page 9 Priority of function The LCD display shows volt- age mode, when the voltage at the input terminals satisfies the following conditions: ACV: Between 1.3V and 999.9V DCV: Between 2.1V and 999.9V, or between -0.7V ~ -999.9V The LCD display shows resistance (Ω) mode when the resistance at the input termi- nals satisfies the following...
- Page 10 Data Hold Beep Guard The internal sounder will beep continuously and the LCD display will flash if either of the following two situations are met in Data -hold mode : 1. The instrument measures a characteristic different from the LCD reading;...
-
Page 11: Auto Power Off
Auto Power-off Battery Replacement When the low battery indicator "<" appears on the LCD, replace the batteries with the type given in the specifications. WARNING Disconnect the test leads from the circuit and the instrument before removing the battery cover. Refer to the following figure to replace the batteries: EN - 11... -
Page 12: General Specifications
Specifications 1-1 General Specifications LCD display : 4 full large scale LCD readout. Measuring rate : 5 times / sec. Overrange display : “OL” is displayed for “Ω” functions, shows the real value is shown for the “A” and “V” functions. Automatic power off time : Approximately 20 minutes after power on without operations. - Page 13 Measurement Category lll is for measure- ments performed in the building installation. Examples include measurements on distribution boards, junction boxes, socket- outlets and wiring and cables in the fixed installation. Measurement Category lV is for measure- ments performed at the source of the low-voltage installation.
-
Page 14: Electrical Specifications
1-3 Electrical Specifications Accuracy is ±(% reading + number of digits) at 23°C ± 5°C < 80%RH. Temperature coefficient : Add 0.2 x (Specified accuracy) / °C ,< 18°C > 28°C . Voltage Function Range Accuracy ±(1.5%+ 3 dgt) 1.3V ~ 750.0V V... -
Page 15: Limited Warranty
Limited Warranty This instrument is warranted to the original purchaser against defects in material and workmanship for 3 year from the date of purchase. During this warranty period, RS Components will, at its option, replace or repair the defective unit, subject to verifica- tion of the defect or malfunction. - Page 16 EN - 16...
- Page 17 Africa RS Components SA P.O. Box 12182, Vorna Valley, 1686 20 Indianapolis Street, Kyalami Business Park, Kyalami, Midrand South Africa www.rs-components.com Asia RS Components Pte Ltd. 31 Tech Park Crescent Singapore 638040 www.rs-components.com China RS Components Ltd. Suite 23 A-C East Sea Business Centre Phase 2 No.
