Introduction
Congratulations on your purchase of Extech's Model RT30 (914Mhz) or RT32
(869MHz) Wireless AC Circuit Identifier. The detector can identify live circuits and
detect changes in light level with the wireless receiver. With careful use, this
detector will provide years of reliable service.

Meter Description

TRANSMITTER DESCRIPTION
1. Wire clamp slot
2. Wire Clamp release latch
3. Light sensor
4. Voltage/Light detect LED
5. Battery compartment
6. Power LED
7. Light setpoint button
8. Power/Mode select switch
9. External Probe Connector
RECEIVER DESCRIPTION
1. Detect LED (Amber)
2. Communication LED (Yellow)
3. Power/Mode
4. Power LED (Green)
5. Battery compartment
6. Pocket clip
7. Audio Buzzer
4
5
6
7
8
1 2
3
4
6
5
RT30 V2.0 11/08
