This Driver's Handbook contains the information necessary:
– for you to familiarise yourself with your vehicle, to use it to its best advantage and to benefit fully from the all the functions and
the technical developments it incorporates.
– to ensure that it always gives the best performance by following the simple, but comprehensive advice concerning regular main-
tenance.
– to enable you to deal quickly with minor faults not requiring specialist attention.
It is well worth taking a few minutes to read this handbook to familiarise yourself with the information and guidelines it contains
about the vehicle and its functions and new features. For any additional clarifications,request you to contact nearby authorized
RENAULT dealer.
The following symbol will help you when reading this handbook:
To indicate a hazard, danger or safety recommendation.
The descriptions of the models given in this handbook are based on the technical specifications at the time of writing. This hand-
book covers all items of equipment (both standard and optional) available for these models, but whether or not these are
fitted to the vehicle depends on the version, options selected and the country where the vehicle is sold.
This handbook may also contain information about items of equipment to be introduced later in the model year.
Throughout the manual, the «approved dealer» is your DACIA dealer.
Enjoy driving your new vehicle.
Translated from French. Copying or translation, in part or in full, is forbidden unless prior written permission has been obtained from the vehicle manufac-
turer.
Welcome aboard your vehicle
0.1

Advertisement

Table of Contents
loading

Summary of Contents for Renault Lodgy 2017

  • Page 1 It is well worth taking a few minutes to read this handbook to familiarise yourself with the information and guidelines it contains about the vehicle and its functions and new features. For any additional clarifications,request you to contact nearby authorized RENAULT dealer. The following symbol will help you when reading this handbook: To indicate a hazard, danger or safety recommendation.
  • Page 3: Table Of Contents

    Sections Getting to know your vehicle ....... Driving ..............Your comfort ............Maintenance ............Practical advice ............ Technical specifications ........Alphabetical index ..........
  • Page 5 Section 1: Getting to know your vehicle Keys, radio frequency remote control: general information ....... . Locking/unlocking the doors .
  • Page 6: Keys, Radio Frequency Remote Control: General Information

    KEYS, RADIO FREQUENCY REMOTE CONTROL: general information (1/2) Driver’s responsibility when parking or stopping the vehicle Never leave an animal, child or adult who is not self-suffi- cient alone on your vehicle, even for a short time. They may pose a risk to themselves or to others by starting the engine, Key A Radio frequency remote...
  • Page 7: Operating Range

    KEYS, RADIO FREQUENCY REMOTE CONTROL: general information (2/2) The remote control unit operating range This varies according to the environ- ment. It is therefore important when handling the remote control to ensure that you do not lock or unlock the ve- hicle by inadvertently pressing the but- Replacement and additional keys tons.
  • Page 8: Locking The Doors

    KEYS/RADIO FREQUENCY REMOTE CONTROL: use Locking the doors Press locking button 1. The hazard warning lights and indica- tor lights flash twice to indicate that the doors have locked. If a door or the tailgate is open or not Driver’s responsibility properly shut, the doors or tailgate lock when parking or stopping then quickly unlock and the hazard war-...
  • Page 9: Locking And Unlocking The Doors

    LOCKING AND UNLOCKING THE DOORS (1/2) Manual control From the inside Locking the doors manually (depending on vehicle) (depending on vehicle) From the outside Push in button 2 to lock and lift button 2 If the remote control does not work, you Unlock the doors using the key in a to unlock.
  • Page 10 LOCKING AND UNLOCKING THE DOORS (2/2) Locking the opening Door and tailgate status elements without the radio indicator frequency remote control With the ignition on, the warning light integrated in switch 4 informs you of the For example, in the event of a dis- locking status of the opening elements: charged battery or the radio frequency remote control temporarily not working.
  • Page 11: Automatic Locking When Driving

    AUTOMATIC LOCKING WHEN DRIVING Operating principle When the engine is started, the system automatically locks the doors when the vehicle reaches a speed of approxi- mately 4 mph (7 km/h). Operating faults If you notice an operating fault (auto- matic locking impossible), first check that all doors are correctly locked.
  • Page 12: Opening And Closing The Doors

    OPENING AND CLOSING THE DOORS (1/2) Lights-on warning buzzer If you have left the lights on after switch- ing off the ignition, a reminder buzzer will sound when the driver’s door is opened. Door/tailgate open buzzer Depending on the vehicle, this alarm is fitted to the driver’s side door or on all opening elements.
  • Page 13: Child Safety

    OPENING AND CLOSING THE DOORS (2/2) Driver’s responsibility when parking or stopping the vehicle Never leave an animal, child or adult who is not self-suffi- cient alone on your vehicle, even for a short time. Child safety They may pose a risk to themselves To make it impossible for the rear doors or to others by starting the engine, to be opened from the inside, move...
  • Page 14: Headrests

    FRONT HEADRESTS To remove the headrest Press tab 1 and lift the headrest to re- lease it (tilt the seatback backwards if necessary). To refit the headrest Insert the rods into the sleeves, with the notches facing forwards, and lower the headrest to the desired height.
  • Page 15: Front Seats

    FRONT SEATS To move forwards or Heated seats For safety reasons, carry backwards Depending on the vehicle, with the igni- out any adjustments when Lift bar 1 to release. tion on, press switch 3. the vehicle is not being Release the bar 1 once the seat is in driven.
  • Page 16: Seat Belts

    SEAT BELTS (1/5) Before starting, first adjust your driv- Always wear your seat belt when trav- elling in your vehicle. You must also ing position, then ask all occupants comply with the legislation of the par- to adjust their seat belts to ensure ticular country you are in.
  • Page 17 SEAT BELTS (2/5) Unlocking Press the button 4 on catch 5 and the seat belt will be rewound by the iner- tia reel. Hold by the buckle to make this easier. ™ Front seat belt reminder warning light Depending on the vehicle, it comes on when the engine is started and if the driver’s and/or passenger’s seat belt is not fastened.
  • Page 18 SEAT BELTS (3/5) Second row rear seats Centre seat belt Unwind belt 15 slowly from its hous- Rear side seat belts ing 10. Slowly unwind belt 7 and click buckle 8 Pass the two buckles and the belt 15 in into red catch 9.
  • Page 19 SEAT BELTS (4/5) Operating the rear seats. Please see the information in the para- graphs on “Second row rear seats: functions” and “Third row rear seats: functions” in Section 3. Third row rear seats Remove strap 16 from hook A. Slowly unwind the strap 16.
  • Page 20 SEAT BELTS (5/5) The following information applies to the vehicle’s front and rear seat belts. – No modification may be made to the component parts of the originally fitted restraint system: seat belts, seats and their mountings. For special operations (e.g. fitting child seats), contact an authorised dealer. –...
  • Page 21: Methods Of Restraint In Addition To The Front Seat Belts

    SYSTEMS IN ADDITION TO THE FRONT SEAT BELTS (1/4) Depending on the vehicle, they are – Have the entire restraint composed of: system checked following – seat belt pretensioners; an accident. – chest force limiters; – No operation whatsoever is permitted on any part of the –...
  • Page 22 SYSTEMS IN ADDITION TO THE FRONT SEAT BELTS (2/4) Load limiter Each air bag system consists of: – an airbag and gas generator fitted Above a certain severity of impact, this on the steering wheel for the driver mechanism is used to limit the force of and, depending on the vehicle, in the the belt against the body so that it is at dashboard for the front passenger;...
  • Page 23 SYSTEMS IN ADDITION TO THE FRONT SEAT BELTS (3/4) Operation This system is only operational when the ignition is switched on. If a severe frontal impact occurs, the air bag(s) inflate(s) rapidly, cushion- ing the impact of the driver’s head and chest against the steering wheel and the front passenger’s head against the dashboard.
  • Page 24 SYSTEMS IN ADDITION TO THE FRONT SEAT BELTS (4/4) All of the warnings below are given so that the air bag is not obstructed in any way when it is inflated and also to prevent the risk of serious injuries caused by items which may be dislodged when the air bag inflates. Warnings concerning the driver’s air bag –...
  • Page 25: Side Protection Devices

    SIDE PROTECTION DEVICES Side air bags These air bags may be fitted to the front seats and are deployed at the sides of the seats (door side) to protect the oc- cupants in the event of a severe side impact. Warnings concerning the side air bag –...
  • Page 26: Additional Method Of Restraint

    ADDITIONAL METHODS OF RESTRAINT All of the warnings below are given so that the air bag is not obstructed in any way when it is inflated and also to prevent the risk of serious injuries caused by items which may be dislodged when the air bag inflates. The air bag is designed to complement the action of the seat belt.
  • Page 27: Child Safety: General Information

    CHILD SAFETY: General information (1/2) Carrying children Special features of LPG Children, and adults, must be correctly versions seated and strapped in for all journeys. The vehicle’s LPG installa- The children being carried in your vehi- tion may lead to changes to cle are your responsibility.
  • Page 28 CHILD SAFETY: General information (2/2) Using a child seat Set a good example by always fas- The level of protection offered by the tening your seat belt and teaching child seat depends on its ability to re- your child: strain your child and on its installation. –...
  • Page 29 CHILD SAFETY: choosing a child seat Rear-facing child seats Forward-facing child seats Booster cushions A baby’s head is, proportionally, heavier The child’s head and abdomen need to From 15 kg or 4 years, the child can than that of an adult and its neck is very be protected as a priority.
  • Page 30: Child Seat Mounting

    CHILD SAFETY: mounting a child seat (1/2) Attachment via the seat belt Attachment with the ISOFIX system The seat belt must be adjusted to Authorised ISOFIX child seats are ap- ensure that it is effective in the event of proved in accordance with regulation harsh braking or an impact.
  • Page 31 CHILD SAFETY: mounting a child seat (2/2) Anchorages 3 must be used to attach the child seat’s upper strap. It is forbidden to use other mounting points to attach this strap. The two ISOFIX rings 1 are located be- The third ring 3 of each side seat is tween the seatback and the base and used to attach the upper strap on some The ISOFIX anchorage...
  • Page 32: Fitting A Child Seat

    CHILD SAFETY: fitting a child seat (1/8) Some seats are not suitable for fitting The types of child seats indicated may After installing the child seat, if neces- child seats. The diagram on the follow- not be available. Before using a differ- sary, the seat may be advanced (so as ing page shows you how to attach a ent child seat, check with the manufac-...
  • Page 33 CHILD SAFETY: fitting a child seat (2/8) In the rear side seat Rear centre seat A carrycot can be installed across the A child seat may only be fitted in this vehicle and will take up at least two seat if it is equipped with an inertia-reel seats.
  • Page 34 CHILD SAFETY: fitting a child seat (3/8) The table below summarises the information already shown in the diagram on the following pages, to ensure the applicable regu- lations are respected. Five-seater versions Front passenger seat Rear seats Weight of Seat without airbag Type of child seat with airbag...
  • Page 35 CHILD SAFETY: fitting a child seat (4/8) Refer to the “Child safety equipment” booklet available from the network to choose the seat suited to your child and rec- ommended for your vehicle. X = Seat not suitable for fitting child seats. U = Seat which allows a child seat with “Universal”...
  • Page 36 CHILD SAFETY: fitting a child seat (5/8) Visual installation of the five-seater version Child seat attached using the ISOFIX fitting ü Seat which allows an ISOFIX child seat to be attached.   The rear seats are fitted with an anchorage point which allows a for- ward-facing ISOFIX child seat with uni- versal approval to be attached.
  • Page 37 CHILD SAFETY: fitting a child seat (6/8) Visual installation, 7-seater version Child seat attached using the ISOFIX fitting ü Seat which allows an ISOFIX child seat to be attached.   The rear seats are fitted with an anchorage point which allows a for- ward-facing ISOFIX child seat with uni- versal approval to be attached.
  • Page 38 CHILD SAFETY: fitting a child seat (7/8) The table below summarises the information already shown on the diagram on the previous page, to ensure the applicable regu- lations are respected. Seven-seat version Front passenger seat 2nd row rear seats 3rd row without Weight of with airbag...
  • Page 39 CHILD SAFETY: fitting a child seat (8/8) Refer to the “Child safety equipment” booklet available from the network to choose the seat suited to your child and rec- ommended for your vehicle. X = Seat not suitable for fitting child seats. U = Seat allowing a child seat with “Universal”...
  • Page 40: Deactivating/Activating The Front Passenger Air Bag

    CHILD SAFETY: deactivating/activating the front passenger air bag (1/3) Deactivating the front With the ignition on, it is essential to passenger air bags check that the 2 warning light is lit up. In order to be able to install a rear- facing child seat on the front passen- This warning light remains continu- ger seat, you must deactivate the front...
  • Page 41 CHILD SAFETY: deactivating/activating the front passenger air bag (2/3) The markings on the dashboard and labels A on each side of the passenger sun visor 3 (as shown above) repeat these instructions. DANGER Since operation of the front passenger airbag is not compatible with the position of a rear-facing child seat, NEVER fit a restraint system for a rear-fac-...
  • Page 42 CHILD SAFETY: deactivating/activating the front passenger air bag (3/3) DANGER Since front passenger airbag triggering and the position of a rear-facing child seat are incompatible, NEVER use a restraining device for rear- facing children on a seat with an ACTIVATED AIRBAG in front of it. This provides a risk of DEATH or SERIOUS INJURY to the CHILD.
  • Page 43: Steering Wheel/Clock

    STEERING WHEEL/CLOCK Press and hold button 3 to enter the hour setting mode. When only the hours flash, press button 3 briefly, to scroll through them. Press and hold button 3 to enter the minute setting mode. When only the minutes flash, press button 3 briefly, to scroll through them.
  • Page 44 DRIVER’S POSITION, LEFT-HAND DRIVE (1/2) 12 13 1.40...
  • Page 45 DRIVER’S POSITION, LEFT-HAND DRIVE (2/2) The presence of the equipment DEPENDS ON THE VEHICLE VERSION AND COUNTRY. 1 Side air vent. 13 Passenger airbag activation/deac- 25 Gearstick. tivation switch. 2 Side demister outlet. 26 ECO mode switch. 14 Glove compartment 3 Stalk for: 27 Cruise control/speed limiter main control.
  • Page 46: Warning Lights

    WARNING LIGHTS (1/5) The presence and operation of the warning lights DEPEND ON THE EQUIPMENT AND COUNTRY. á Main beam headlight tell-tale light Ò Dipped beam headlight tell- tale If the orange warning light comes on while you are driving, Front fog light tell-tale light drive carefully to an authorised dealer as soon as possible.
  • Page 47 WARNING LIGHTS (2/5) The presence and operation of the warning lights DEPEND ON THE EQUIPMENT AND COUNTRY. Ò Ô Warning light malfunction Coolant temperature warn- (red or orange) ing light If this remains lit while driving, ac- Urgent stop warning light (red) companied by a beep, this means the This lights up when the ignition is engine is overheating.
  • Page 48 WARNING LIGHTS (3/5) The presence and operation of the warning lights DEPEND ON THE EQUIPMENT AND COUNTRY. É Preheating warning light (on Anti-lock braking warning diesel version) light This should come on when the igni- This lights up when the ignition is tion is switched on.
  • Page 49 WARNING LIGHTS (4/5) The presence and operation of the warning lights DEPEND ON THE EQUIPMENT AND COUNTRY. Water in the diesel filter warning light Door(s) open warning light This lights up when the ignition is Refer to “Opening/closing the doors” in switched on and goes out after a few Section 1.
  • Page 50 WARNING LIGHTS (5/5) The presence and operation of the warning lights DEPEND ON THE EQUIPMENT AND COUNTRY. Front passenger air bag de- activated warning light Refer to the information on “Child safety: deactivating, activating the front passenger airbag". ™ Seat belt reminder light It is displayed on the con- sole B.
  • Page 51: Displays And Indicators

    DISPLAYS AND INDICATORS (1/2) Rev counter 1 (rpm x 1,000) Speedometer 2 (km or miles per hour) 1.47...
  • Page 52 DISPLAYS AND INDICATORS (2/2) Automatic gearbox display 5 This indicates the gear engaged. Refer to the information on the “Automatic gearbox” in Section 2. Fuel gauge warning light 3 On-board computer A or B or 4 Refer to the information on the “Trip computer and warning system”...
  • Page 53: Trip Computer And Warning System

    TRIP COMPUTER AND WARNING SYSTEM (1/6) Interpreting some of the f) Estimated range values displayed after g) Distance travelled resetting h) Average speed The values showing average fuel con- i) Oil change interval sumption, range and average speed j) Reset the tyre pressure will become more stable and reliable the further you travel after pressing the k) Speed limiter...
  • Page 54 TRIP COMPUTER AND WARNING SYSTEM (2/6) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Examples of selections Interpreting the display selected Display A Display B a) Total mileage recorder. b) Trip mileage recorder. – c) Fuel used since the last time the reset button was pressed. d) Average fuel consumption since the last time the reset button was pressed.
  • Page 55 TRIP COMPUTER AND WARNING SYSTEM (3/6) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Examples of selections Interpreting the display selected Display A Display B e) Current fuel consumption. This value is displayed after a speed of approximately 20 mph (30 km/h) –...
  • Page 56 TRIP COMPUTER AND WARNING SYSTEM (4/6) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Examples of selections Interpreting the display selected Display A Display B j) Mileage before service Distance remaining until the next oil change. Depending on the vehicle: Ê...
  • Page 57 TRIP COMPUTER AND WARNING SYSTEM (5/6) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Examples of selections Interpreting the display selected Display A Display B j) Reset the tyre pressure. Please refer to the information on the “Tyre pressure loss warning” in Section 2.
  • Page 58 TRIP COMPUTER AND WARNING SYSTEM (6/6) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Examples of selections Interpreting the display selected Display A Display B l) Time. m) Exterior temperature. – 1.54...
  • Page 59: Rear View Mirrors

    REAR VIEW MIRRORS (1/2) Door mirrors with manual Door mirrors with electrical adjustment adjustment: To adjust the door mirror, move With the ignition on, move button 2: switch 1. – position A to adjust the left-hand door mirror; Foldable door mirrors –...
  • Page 60 REAR VIEW MIRRORS (2/2) Interior rear view mirror The interior rear-view mirror is adjusta- ble. When driving at night, tilt lever 3 to avoid being dazzled by the headlights of the vehicle behind. For safety reasons, carry out any adjustments when the vehicle is not being driven.
  • Page 61: Exterior Lighting And Signals

    EXTERIOR LIGHTING AND SIGNALS (1/2) Dipped beam Switching off the lights headlights From the main beam head- Turn the end of stalk 1 until the symbol lights position, pull the stalk 1 towards is opposite mark 2. you, then turn the end of the stalk 1 This indicator light on the instrument until the symbol appears by the...
  • Page 62: Front Fog Lights

    EXTERIOR LIGHTING AND SIGNALS (2/2) Rear fog light Turning off the fog lights Turn centre ring 3 on the stalk until the symbol faces mark 2. Turn centre ring 3 on the stalk until the symbol faces mark 2. The rear fog lights will only work if both an external light and the forward fog The corresponding indicator light goes lights have been selected.
  • Page 63: Headlight Beam Adjustment

    HEADLIGHT BEAM ADJUSTMENT Examples of positions for adjusting control A according to the load Driver alone or with front passenger Driver with one front passenger and one rear passenger Control A is used to adjust the height of the headlight beams according to the load.
  • Page 64: Audible And Visual Signals

    AUDIBLE AND VISUAL SIGNALS Horn Hazard warning lights Direction indicators é Move stalk 1 parallel to the steering Press the end of the stalk 1. Press switch 3. wheel and in the direction you are going Depending on the vehicle, press one of This switch activates all four direction to turn it.
  • Page 65 WINDSCREEN WASH/WIPE Windscreen wiper With the ignition on, pull stalk 1 towards you. In frosty weather, make sure that the wiper blades are not stuck by ice A brief pull will trigger a single sweep (risk of motor overheating). of the wipers, in addition to the wind- screen washer.
  • Page 66: Rear Screen Wiper

    REAR SCREEN WASH/WIPE, DE-ICING Rear screen washer/ wiper (depending on vehicle) With the ignition switched on, turn the end of stalk 2 to align the symbol with mark 1. When the stalk is released, it returns to the rear wipe position. Rear screen wiper Heated rear screen (depending on vehicle)
  • Page 67: Fuel Tank (Filling With Fuel)

    FUEL TANK (1/5) Do not mix even small amounts of petrol (un- leaded or E85) with diesel. Do not use ethanol-based fuel if your vehicle is not compatible with this fuel. Do not add any additives to the fuel, you risk damaging the engine. Petrol and diesel versions Depending on the vehicle, lift lever 3 to Fuel filler cap: this is spe-...
  • Page 68: Fuel Grade

    FUEL TANK (2/5) Fuel grade Petrol version Filling with fuel It is essential to use unleaded petrol. Use a high-grade fuel that complies With the ignition off, insert the nozzle to The octane rating (RON) should match with the legislation in force in each open the valve and insert it fully before the information given on the label B lo- country.
  • Page 69 FUEL TANK (3/5) LPG versions Useful capacity of fuel tank: approx. 34 litres. Filling up with LPG Engage the handbrake, stop the engine, switch off the ignition and switch off the lights. Always respect the safety instructions given at filling stations. It is always advisable to completely fill the tank.
  • Page 70 FUEL TANK (4/5) When the pump finishes or if it has dif- ficulties operating, this means that the maximum tank fill level (80%) has been reached. The filling will stop as soon as you re- lease the button. Release the stop lever (a small amount of gas may be re- leased), lift the pistol and place it on the distributor.
  • Page 71 FUEL TANK (5/5) Vehicles without manual priming pump Put the ignition key in “Ignition On” (M) position and wait a few minutes before starting. This will enable the fuel circuit to be primed. If the engine does not start, repeat the procedure. No modifications what- soever are permitted on any part of the fuel supply...
  • Page 72 1.68...
  • Page 73 Section 2: Driving (Advice on use relating to fuel economy and the environment) Running in, Ignition switch ............Starting/stopping the engine .
  • Page 74: Running In, Ignition Switch

    RUNNING IN, IGNITION SWITCH Petrol version Ignition on position M For the first 600 miles (1,000 km), do The ignition is switched on: not exceed 78 mph (130 km/h) in the – petrol version: the engine may be highest gear, or 3,000 to 3,500 rpm. started.
  • Page 75: Starting/Stopping The Engine

    STARTING, STOPPING THE ENGINE (1/2) Starting the engine LPG versions At temperatures close to 0°C or less, it is recommended to use ECO mode to The engine is always started using In very cold conditions (temperatures maximise the use of LPG. Please refer petrol: below –20°C): so that it is easier to to the information on “Driving advice,...
  • Page 76 STARTING, STOPPING THE ENGINE (2/2) Stopping the engine With the engine idling, turn the key Driver’s responsibility back to “Stop” position St. Never leave an animal, child or adult who is not Special note self-sufficient alone on your Depending on the vehicle, accessories vehicle, even for a short time.
  • Page 77 STOP AND START function (1/3) For manual gearboxes: This system enables a reduced fuel consumption and lower greenhouse – the gearbox is in neutral; If you get out of the vehicle, a beep gas emissions. notifies you that the engine is on The system is activated automatically standby and has not been switched –...
  • Page 78 STOP AND START function (2/3) Preventing the engine from Conditions for coming out of Conditions preventing the standing by engine standby standby of the engine Certain conditions prevent the system In certain situations, such as negotiat- For automatic or sequential gearbox: from using the engine standby function, ing a crossroads for instance, it is pos- –...
  • Page 79: Stop And Start Function

    STOP AND START function (3/3) Special feature of the automatic The system is automatically reacti- engine re-start vated each time the vehicle is started (see “Starting, stopping the engine” in Under certain conditions, the engine Section 2). can restart on its own in order to guar- antee your safety and comfort.
  • Page 80: Special Features Of Petrol Versions

    SPECIAL FEATURES OF PETROL vERSIONS The following operating conditions If you notice any of the above operating should be avoided: faults, have the necessary repairs car- ried out as soon as possible by an ap- – driving for long periods when the low proved dealer.
  • Page 81: Special Features Of Diesel Versions

    SPECIAL FEATURES OF DIESEL vERSIONS Diesel engine speed Precautions to be taken in winter Diesel engines are fitted with an injec- To avoid any faults in icy weather: tion pump which prevents the engine – ensure that the battery is always fully speed being exceeded irrespective of charged, the gear selected.
  • Page 82: Special Features Of Lpg Versions

    SPECIAL FEATURES OF LPG vERSIONS (1/3) LPG vehicles Fuel gauge warning light A These vehicles operate using petrol or Warning lights A (4 green lights and 1 LPG. red light) indicate the level in the LPG They have two separate tanks. tank.
  • Page 83 SPECIAL FEATURES OF LPG vERSIONS (2/3) Automatic switch to petrol The system automatically switches to petrol mode if there is no more LPG remaining in the tank. You will be in- formed by: – the green D and yellow B warning lights coming on;...
  • Page 84 SPECIAL FEATURES OF LPG vERSIONS (3/3) Operating fault If driving under severe LPG has a very specific conditions In the event of a fault which may affect smell so you will be able to the correct operation of the engine, the detect any leaks easily.
  • Page 85: Driving Advice, Eco-Driving

    DRIvING ADvICE, ECO-DRIvING (1/4) Fuel consumption is accredited in ac- cordance with a standard regulatory method. Identical for all manufactur- ers, this enables vehicles to be com- pared with one another. Consumption in real time depends on vehicle usage conditions, the equipment fitted and the user’s driving style.
  • Page 86 DRIvING ADvICE, ECO-DRIvING (2/4) ECO mode While driving, it is possible to leave the ECO mode temporarily in order to im- ECO mode is a function which op- prove engine performance. timises fuel consumption. It acts on To do this, press the accelerator pedal certain power consuming systems in firmly and fully.
  • Page 87 DRIvING ADvICE, ECO-DRIvING (3/4) – Avoid sudden acceleration. – Brake as little as possible. If you an- ticipate an obstacle or bend in ad- vance, you may then simply release the accelerator pedal. – Do not try to maintain the same speed up a hill, accelerate no more than you would on the level.
  • Page 88 DRIvING ADvICE, ECO-DRIvING (4/4) – In vehicles fitted with air condi- tioning, it is normal to observe an increase in fuel consumption (es- pecially in urban conditions) when it is used. For vehicles fitted with manual air conditioning, switch off the system when it is not required.
  • Page 89: Maintenance And Antipollution Advice

    MAINTENANCE AND ANTIPOLLUTION ADvICE – Air filter, fuel filter: a choked ele- Your vehicle complies with criteria for In addition, replacing engine, fuel recycling and recovering vehicles at the supply system and exhaust compo- ment will reduce efficiency. It must end of their service life which will come nents with parts other than those origi- be replaced.
  • Page 90: Environment

    ENvIRONMENT Emissions Your vehicle has been designed with – At the end of the vehicle’s service respect for the environment in mind for life, it should be sent to approved Your vehicle has been designed to its entire service life: during production, centres to ensure that it is recycled.
  • Page 91: Tyre Pressure Loss Warning

    TYRE PRESSURE LOSS WARNING (1/3) Resetting the standard level for the tyre pressures This should be done: – when the standard tyre pressure needs to be changed to adapt to usage conditions (empty, carrying a load, motorway driving, etc.); – after swapping a wheel (however this practice is not recommended);...
  • Page 92 TYRE PRESSURE LOSS WARNING (2/3) Display – press and hold (around 3 seconds) the button 3 to start initialisation. Check tyre pressure Flashing, for around five seconds,  followed by a constant display of the The warning light comes on (not message “SEt tP"...
  • Page 93 TYRE PRESSURE LOSS WARNING (3/3) Puncture Readjustment of tyre Emergency spare wheel  pressures If the vehicle is equipped with an emer- The warning light and the red Ò gency spare wheel, it will not have a The tyre pressures must be adjusted warning light come on steady to- sensor.
  • Page 94: Gear Lever

    GEAR LEvER Selecting reverse gear (vehicle stationary) vehicle with manual gearbox: Follow the grid marked on knob 1 and, depend- ing on the vehicle, lift the ring against An impact to the under- the knob to engage reverse gear. side of the vehicle while manoeuvring (e.g.: strik- vehicles with automatic gear- ing a post, raised kerb or...
  • Page 95: Handbrake

    HANDBRAKE/POWER-ASSISTED STEERING To apply Power-assisted steering Pull lever 1 upwards and make sure the With the engine running, do not leave vehicle is immobilised. the steering wheel at full lock while sta- tionary as this may damage the power- assisted steering pump. With the engine switched off, or if there is a system fault, it is still possible to turn the steering wheel.
  • Page 96: Driver Correction Devices/Aids

    DRIvER CORRECTION DEvICES/AIDS (1/4) ABS (anti-lock braking Operating faults: Depending on the vehicle, this is com- posed of: system) – If the warning light on the in- – of the ABS (anti-lock braking strument panel comes on while driv- Under heavy braking, the ABS prevents system);...
  • Page 97: Electronic Stability Program

    DRIvER CORRECTION DEvICES/AIDS (2/4) Electronic stability program Understeer control Operating faults ESC with understeer control This system optimises the action of the When the system detects an operating   and traction control ESC in the case of pronounced under- fault, the and/or warning...
  • Page 98: Emergency Brake Assist

    DRIvER CORRECTION DEvICES/AIDS (3/4) Hazard warning lights switching on The traction control system offers ad- ditional safety. It is recommended that Depending on the vehicle, these may you do not drive with the function disa- light up in the event of sudden decel- bled.
  • Page 99 DRIvER CORRECTION DEvICES/AIDS (4/4) Hill start assistance Depending on the gradient of the in- cline, this system assists the driver when starting on a hill. It prevents the The hill start assistance vehicle from rolling backwards by au- system cannot completely tomatically applying the brakes when prevent the vehicle from the driver lifts his/her foot off the brake...
  • Page 100: Speed Limiter

    SPEED LIMITER (1/3) Controls Switching on The speed limiter function helps you stay within the driving speed limit that 1 Main “On/Off” switch. Press switch 1 on the side showing you choose, known as the limit speed.  . The warning light 6 comes on, lit 2 Limit speed activation, storage and orange and, depending on the vehicle, increase switch (+).
  • Page 101 SPEED LIMITER (2/3) varying the limit speed Exceeding the limit speed The limit speed may be changed by re- It is possible to exceed the limit speed peatedly pressing: at any time. To do this: press the accel- erator pedal firmly and fully (beyond –...
  • Page 102 SPEED LIMITER (3/3) Recalling the limit speed If a speed has been stored, it can be recalled by pressing switch 4 (R or, de- pending on the vehicle, RES). Putting the function on Switching off the function standby The speed limiter function is deac- tivated if you press switch 1: in this The speed limiter function is suspended case a speed is no longer stored.
  • Page 103: Cruise Control

    CRUISE CONTROL (1/4) This function is an addi- tional driving aid. However, the function does not take the place of the driver. Therefore, it can under no circum- Controls The cruise control function helps you to stances replace the driver’s respon- maintain your driving speed at a speed sibility to respect speed limits and to 1 Main “On/Off”...
  • Page 104 CRUISE CONTROL (2/4) Switching on Activating cruise control Driving  At a steady speed (above 18 mph Once a cruising speed is stored and Press switch 1 side (30 km/h approximately)) press switch 2 the cruise control function is active, The warning light 6 comes on, lit green or (+): the function is activated and the you may lift your foot off the accelera-...
  • Page 105 CRUISE CONTROL (3/4) Exceeding the cruising speed The cruising speed may be exceeded at any time by depressing the accelera- tor pedal. While it is being exceeded, the cruising speed flashes on the in- strument panel. Then, release the accelerator: after a few seconds, the vehicle will automati- cally return to its set cruising speed.
  • Page 106 CRUISE CONTROL (4/4) Returning to the cruising speed If a speed is stored, it can be recalled, once you are sure that the road con- ditions are suitable (traffic, road sur- face, weather conditions, etc.). Press switch 4 (R or, depending on the vehi- cle, RES) if the vehicle speed is above 20 mph (30 km/h).
  • Page 107: Parking Distance Control

    PARKING DISTANCE CONTROL (1/2) Operating principle Ultrasonic sensors, fitted in the vehi- cle’s rear bumper, measure the dis- tance between the vehicle and an ob- stacle when reversing. This measurement is indicated by beeps which become more frequent the closer you come to the obstacle, until they become a continuous beep when This function is an addi- the vehicle is approximately 40 centi-...
  • Page 108 PARKING DISTANCE CONTROL (2/2) Operating faults When the system detects an operating fault, there will be a three-second con- tinuous beep as a warning. Please con- sult an authorised dealer. Deactivating the system You can deactivate the system by pressing switch 1. The warning light built into the switch remains lit constantly.
  • Page 109: Reversing Camera

    REvERSING CAMERA (1/2) Operation Note: make sure that the reversing camera is not obscured (by dirt, mud, When using reverse gear, the camera 1 snow, etc.). located near the tailgate sends a view of the area behind the vehicle to the multimedia display 2 together with a static guide line.
  • Page 110 REvERSING CAMERA (2/2) This gauge remains fixed and indicates the vehicle trajectory if the wheels are in line with the vehicle. Static guide line 3: The static guide line 3 has coloured markers A, B and C showing the dis- The screen shows a reverse image.
  • Page 111: Selector Lever

    AUTOMATIC TRANSMISSION (1/3) Driving in automatic mode Put lever 1 into position D. In most road conditions you will en- counter, you will not need to touch your lever again: the gears will change au- tomatically at the right time and at the most suitable engine speed because the automatic system takes into ac- count the vehicle load and road contour...
  • Page 112 AUTOMATIC TRANSMISSION (2/3) Special cases Special circumstances In certain driving conditions (e.g. re- – If the bends and road surface do quiring engine protection, operation of not allow you to stay in automatic the Electronic Stability Program: ESC) mode (e.g. in the mountains), we the automatic system may change the recommend that you change to gear automatically.
  • Page 113: Automatic Gearbox

    AUTOMATIC TRANSMISSION (3/3) – In cold weather (temperatures Towing a vehicle with an under -20°C), wait a few seconds automatic gearbox before moving the selector lever With the engine switched off, the trans- from position P and engaging it in D mission is no longer lubricated.
  • Page 114 2.42...
  • Page 115: Your Comfort

    Section 3: Your comfort Air vents, air outlets ............. . Heating/Ventilation/Air conditioning .
  • Page 116: Air Vents, Air Outlets

    AIR VENTS, air outlets (1/2) 1 Left-hand side air vent 5 right-hand side window demister outlet 2 Left-hand side window demister vent 6 Right-hand air vent 3 Windscreen demisting vents 7 Front passenger footwell heater outlets 4 Centre air vents 8 Control panel...
  • Page 117 AIR VENTS, air outlets (2/2) To remove bad odours from your ve- hicles, only use the systems designed for this purpose. Consult an approved Dealer. Centre and side air vents Direction To direct the air flow, swivel side air Air flow vent 9.
  • Page 118: Heating/Ventilation/Air Conditioning

    HEATING, VENTILATION, AIR CONDITIONING (1/3) Adjusting the air temperature Turn the control 4 to obtain the desired temperature. The further the pointer is in the red, the more the temperature will be increased. Adjusting the ventilation fan speed. Turn control 3 from 0 to 4. The further to the right it is positioned, the more air is blown into the passenger compart- ment.
  • Page 119 HEATING, VENTILATION, AIR CONDITIONING (2/3) Rapid demisting Turn controls 1, 3 and 5 to positions – air from the outside; – maximum fan speed; – demisting. Using the climate control increases the speed of demisting. Switching passenger Air recirculation is used to: compartment isolation mode/ –...
  • Page 120: Passenger Compartment

    HEATING, VENTILATION, AIR CONDITIONING (3/3) Switching air conditioning on or off The air conditioning is switched on (in- dicator light illuminated) or off (indicator light extinguished) using button 2. Activation is not possible if the control 3 is set to 0. The air conditioning system is used for: –...
  • Page 121: Air Conditioning: Information And Advice On Use

    AIR CONDITIONING: information and advice on use Fuel consumption Operating faults You will normally notice an increase in As a general rule, contact your ap- fuel consumption (especially when driv- proved dealer in the event of an oper- ing in town) when the air conditioning is ating fault.
  • Page 122: Electric Windows

    ELECTRIC WINDOWS (1/3) Safety of rear occupants The driver can prevent op- eration of the rear elec- tric windows by pressing switch 4. Driver’s responsibility Never leave your vehicle with the key inside, and with a child, adult who is not self-sufficient or a pet, even for a short while.
  • Page 123 ELECTRIC WINDOWS (2/3) Manual window winders Rear side screen From the passenger seat, use switch 7. Turn the handle 8 to lower or raise the To half-open the window, turn handle 9 window to the required position. (movement A) then lock it by pushing the handle to the right.
  • Page 124 ELECTRIC WINDOWS (3/3) One-touch windows Operating faults When the vehicle is equipped with this In case of a fault when closing a window, function, the one-touch mode works in the system reverts to normal mode: pull addition to the operation of the electric the switch concerned up to fully close windows described previously.
  • Page 125: Interior Lighting

    INTERIOR LIGHTING Courtesy lights Map reading light Boot light 4 Press switch 1 of 3 for: Depending on the vehicle, press the The light 4 comes on when the boot is switch 2. opened. – continuous lighting; – lighting operated by opening just the driver’s door, or by opening one of the four doors, depending on the ve- hicle.
  • Page 126: Sun Visor/Grab Handle

    SUN VISOR, GRAB HANDLE (1/2) Front sun visor Sun visor storage 4 It can be used to hold motorway Lower the sun visor 1 or 2 over the passes, etc. windscreen or unclip it and turn it over the side window. Vanity mirror If the sun visor is fitted with a courtesy mirror 3, it has a cover.
  • Page 127 SUN VISOR, GRAB HANDLE (2/2) Child minder mirror 5 Grab handle 6 Child minder mirror 5 allows you to This offers support and can be held keep an eye on your child in the rear when the vehicle is being driven. seat.
  • Page 128 PASSENGER COMPARTMENT STORAGE/FITTINGS (1/5) Glove box Storage compartment 2 Dashboard storage 3 If fitted on the vehicle, pull paddle 1 to If the storage compartment has a cover, open. lift to open. You should avoid keeping liquids in this compartment (if a liquid leaks there is a risk of seepage).
  • Page 129 PASSENGER COMPARTMENT STORAGE/FITTINGS (2/5) Storage compartment A Door storage compartment 5 Front seat storage pockets 6 Pass a hand in location 4 and pull to open the storage compartment A. Ensure that no hard, heavy or pointed objects are Nothing should be placed placed in the “open”...
  • Page 130 PASSENGER COMPARTMENT STORAGE/FITTINGS (3/5) Mobile phone storage Front armrest 8 Storage compartments 9 compartment 7 and 10 (depending on the vehicle) 3.16...
  • Page 131 PASSENGER COMPARTMENT STORAGE/FITTINGS (4/5) Storage compartment 11 Cup holder 12, 13 and 14 Storage compartment 15 3.17...
  • Page 132 PASSENGER COMPARTMENT STORAGE/FITTINGS (5/5) Rear parcel shelves 16 17 storage pocket Raise them to their horizontal position, It is recommended that you use the shelves only when the vehicle is sta- tionary. 3.18...
  • Page 133 ASHTRAY, CIGARETTE LIGHTER, ACCESSORIES SOCKET (1/2) Ashtray 1 Cigarette lighter or accessories socket 3 This may be in location 2, 4 or 5. With the ignition on, push in the ciga- Lift the cover to open. rette lighter 3. It will spring back with a To empty, pull the ashtray towards you click when it is ready.
  • Page 134 ASHTRAY, CIGARETTE LIGHTER, ACCESSORIES SOCKET (2/2) Accessories socket 6 and 7 It is provided for connecting accessories approved by our Technical Department. Connect accessories with a maximum power of 120 Watts (12 V) only. When several accessory sockets are used at the same time, the total power of the connected accessories must not exceed 180 watts.
  • Page 135: Rear Headrests

    REAR HEADRESTS (1/2) Position for using headrest A To put the headrest back in place A Lift the headrest to maximum height, then lower it until it locks. Insert the rods into the holes, press the tab(s) 1 and lower the headrest. To raise the headrest A Headrest A storage Raise the headrest as far as it will go,...
  • Page 136 REAR HEADRESTS (2/2) To put the headrest back in place C Insert the rods into the holes, press lock tab 2 and lower the headrest. To adjust the height of the headrest C (depending on vehicle) Press lock tab 2 and simultaneously slide the headrest to the required po- sition.
  • Page 137 REAR SEAT FUNCTIONS: second row (1/3) To reposition the seatback – Raise the seatbacks; – make sure you lock the seat back in place. Fixed rear bench seat To fold down the seatback – Bring the front seats forward; When moving the rear –...
  • Page 138 REAR SEAT FUNCTIONS: second row (2/3) Rear bench seat with folding To reposition the seat A or bench seat B seat back and seat cushion – Lower the bench seat until it locks in When moving the rear To fold down the seat A or bench position;...
  • Page 139: Rear Seats

    REAR SEAT FUNCTIONS: second row (3/3) Accessing the third row rear seats – Lower handle 2; Restriction of use – lower the seatback onto the seat base; If a passenger is occupying one of – raise the seat until vertical. the second row seats, do not drive When refitting the seat- with the other second row seat...
  • Page 140 REAR SEAT FUNCTIONS: third row (1/3) To fold down the seats The third row rear seats can be folded down or removed for transporting bulky – Ensure that the rear seat belts are objects. correctly positioned on the hooks 1; –...
  • Page 141 REAR SEAT FUNCTIONS: third row (2/3) To reposition the seats – Ensure that the rear seat belts are correctly positioned on the hooks 1; Check that the rear seat – Lower the seat base until it locks in Restriction of use belts are positioned and position;...
  • Page 142: Second Row

    REAR SEAT FUNCTIONS: third row (3/3) To remove the seats To install seats – Ensure that the rear seat belts are – Ensure that the rear seat belts are correctly positioned on the hooks 1; correctly positioned on the hooks 1; –...
  • Page 143 REAR SEAT FUNCTIONS: Grouping of seats (1/3) The two rows of the rear seats can be grouped together to free up a maximum load surface area at the rear of the ve- hicle. For more information, see the following pages. For safety reasons, carry out any adjustments when the vehicle is stationary.
  • Page 144 REAR SEAT FUNCTIONS: grouping of seats (2/3) To group together the two rows of rear seats Fold down the second row rear seats. Refer to the information on the “Second row rear seats” in Section 3. Remove the third row rear seats Refer to the information on the “Third row rear seats”...
  • Page 145: Third Row

    REAR SEAT FUNCTIONS: grouping of seats (3/3) To reposition the seats Replace the third row rear seats in po- sition. Refer to the information on the Loosen and remove the attachment “Third row rear seats” in Section 3. straps 3 from the front headrest and Reposition the second row rear seats.
  • Page 146: Luggage Compartment

    LUGGAGE COMPARTMENT To open To close Pull down the tailgate using handle 2 Electric central locking inside the tailgate to assist you. With the opening elements unlocked, When the tailgate reaches shoulder press button 1 and lift the tailgate. height, gently push it shut. Manual locking Insert the key in the boot lock, turn and press button 1.
  • Page 147: Luggage Compartment Storage Space And Fittings

    LUGGAGE COMPARTMENT STORAGE SPACE AND FITTINGS Anchorage points Storage net 2 Anchorage points 1 located on each Always position the heavi- corner of the luggage compartment est items directly on the allow loads to be secured. floor. If the vehicle is equipped with anchorage points on the luggage compart- ment floor, use them.
  • Page 148: Transporting Objects In The Luggage Compartment

    TRANSPORTING OBJECTS IN THE LUGGAGE COMPARTMENT Always position the objects trans- ported so that the largest surface is against: – the rear bench seatbacks, for normal loads (eg: A); – the front seats when the second and/or third row rear seats are folded down.
  • Page 149 TRANSPORTING OBJECTS towing, attachments A = 940.6 mm Permissible nose weight, maxi- mum permissible towing weight braked and unbraked: Refer to the information on “Weights” in Section 6. Choice and fitting of towing equipment Maximum weight of towing equip- ment: 26 kg. Refer to the manufacturer’s instruc- If the towbar ball obscures the reg- tions for information on how to fit and...
  • Page 150: Luggage Net

    TRANSPORTING OBJECTS Luggage net Fitting the luggage net Fitting the luggage net If fitted, this can be used when trans- porting animals or luggage to isolate behind the second row rear behind the front seats them from the passenger section. seats Inside the vehicle on each side: It is fitted behind the second row bench...
  • Page 151: Luggage Compartment Cover

    LUGGAGE COMPARTMENT COVER (1/2) How to remove the luggage compartment cover A Using handle 1, pull it gently to release the pins from their mounting points lo- cated on each side of the luggage com- partment. Guide the luggage cover using han- dles 1.
  • Page 152 LUGGAGE COMPARTMENT COVER (2/2) Removing the luggage Refitting the luggage compartment cover compartment cover Push the luggage cover to the right Insert the right-hand side, then push it (movement B) and lift the left-hand side to the right and lower the left-hand side of the inertia reel.
  • Page 153: Roof Bars

    LONGITUDINAL ROOF BARS Precautions during use Handling the tailgate Before handling the tailgate, check the objects and/or accessories (bike rack, roof box, etc.) fitted to the roof bars: these must be correctly positioned and secured, so as not to hinder the opera- tion of the tailgate.
  • Page 154: Multimedia Equipment

    MULTIMEDIA EqUIPMENT Hands-free telephone The presence and location of this equipment depends on the vehicle’s integrated control multimedia equipment. On equipped vehicles, use micro- 1 Radio or navigation system; phone 3 and steering column control 2. 2 Steering column control; 3 Microphone.
  • Page 155 Section 4: Maintenance Bonnet ............... . Engine oil level: general information .
  • Page 156: Bonnet

    BONNET (1/2) The engine may be hot during operations in close proximity. In addition, the engine cooling fan may come on at any moment. Risk of injury. Opening the bonnet To open the bonnet, pull the handle 1. Lift the bonnet; you will need to guide it as it is held by a strut.
  • Page 157 BONNET (2/2) Ensure that the bonnet is properly locked. Ensure that nothing is pre- venting locking (grit, cloths, etc.). Make sure nothing is left in the engine compartment In the event of even a slight (cloth, tools, etc.). impact involving the radia- These may damage the tor grille or bonnet, have engine or cause a fire.
  • Page 158: Engine Oil Level: General Information

    ENGINE OIL LEVEL: general information It is normal for an engine to use oil for – remove the dipstick and wipe with a lubrication and cooling of moving parts clean, lint-free cloth; and it is normal to top up the level be- –...
  • Page 159: Engine Oil Level: Topping Up/Filling

    ENGINE OIL LEVEL: topping up/filling (1/2) Topping up/Filling – Unscrew cap 1; – top up the level (as a guide, the ca- The vehicle must be parked on level pacity between the minimum and ground and the engine should be cold maximum reading on the dipstick 2 (for instance, before the engine is is between 1.5 and 2 litres, depend-...
  • Page 160: Oil Change

    ENGINE OIL LEVEL: topping up/filling (2/2) Oil change Service interval: refer Maintenance Document for your vehi- cle. Never run the engine in an Oil change capacity enclosed space as exhaust Please refer to the maintenance docu- gases are poisonous. ment for your vehicle, or contact an au- thorised dealer.
  • Page 161: Levels

    LEVELS (1/3) Topping up Level After any operation on the hydraulic cir- It is normal for the level to drop as the cuit, a specialist must replace the fluid. brake shoes become worn, but it must Only use fluids approved by the never drop lower than the “MINI”...
  • Page 162: Windscreen Washer Reservoir

    LEVELS (2/3) Checking intervals Check the coolant level regularly (very severe damage is likely to be caused to the engine if it runs out of coolant). If the level needs to be topped up, only use products approved by our Technical Department which ensure: –...
  • Page 163: Power-Assisted Steering Fluid

    /FILTER LEVELS (3/3) Filters The replacement of filter elements (air filter, cabin filter, diesel fuel filter, etc.) is scheduled in the maintenance opera- tions for your vehicle. Replacement intervals for filter ele- ments: please refer to your vehicle’s maintenance document. Power-assisted steering fluid reservoir Deactivate the Stop and...
  • Page 164: Battery

    BATTERY (1/2) The charge status of your battery can decrease especially if you use your ve- hicle: – for short journeys; – for driving in town; – when the temperature drops; – after extended use of consumers (radio etc.) with the engine switched off.
  • Page 165 BATTERY (2/2) Label A Observe the indications on the battery: – 2 Naked flames and smoking are for- bidden; – 3 Eye protection required; – 4 Keep away from children; – 5 Explosive materials; – 6 Refer to the handbook; –...
  • Page 166: Tyre Pressure

    TYRE PRESSURE (1/2) F: tyre pressures for the rear wheels (motorway) (maximum of 2 people on board). G: tyre pressures for the front wheels (non-motorway) (more than 2 people on board). H: tyre pressures for the rear wheels (non-motorway) (more than 2 people on board).
  • Page 167 TYRE PRESSURE (2/2) Special note concerning fully laden Vehicle fitted with a tyre pressure vehicles (Maximum Permissible All-Up loss warning system Weight) and towing a trailer: the maxi- If under-inflated (puncture, low pres- mum speed must be limited to 60 mph ...
  • Page 168: Bodywork Maintenance

    BODYWORK MAINTENANCE (1/2) What you should not do You should A well-maintained vehicle will last longer. It is therefore recommended to Do not degrease or clean mechani- Wash your car frequently, with the maintain the exterior of the vehicle reg- cal components (e.g.
  • Page 169 BODYWORK MAINTENANCE (2/2) Vehicles with a matte paint Using a roller type car wash Respect local regulations about wash- ing vehicles (e.g. do not wash your ve- finish Return the windscreen wiper stalk to hicle on a public highway). the Park position (refer to the informa- This type of paint requires certain pre- Observe the vehicle stopping distances tion on the “Windscreen washer, wiper”...
  • Page 170: Interior Trim Maintenance

    INTERIOR TRIM MAINTENANCE (1/2) Glass instrument panel Textiles (seats, door trim, etc) A well-maintained vehicle will last longer. It is therefore recommended to (e.g.: instrument panel, clock, exterior Vacuum-clean the textiles regularly. maintain the interior of the vehicle regu- temperature display, radio display, mul- larly.
  • Page 171 INTERIOR TRIM MAINTENANCE (2/2) Removal/replacing removable You should not: equipment originally fitted in You are strongly advised not to po- the vehicle sition objects such as deodorants, scents, etc. near air vents, as this could If you need to remove equipment in damage your dashboard trim.
  • Page 172 4.18...
  • Page 173 Section 5: Practical advice Tools ............... . . Puncture .
  • Page 174: Tools

    Tools Accessing the tools Wheelbrace 4 Tow eye 3 The tools are located in the luggage This is used to tighten/loosen the wheel Please see “Towing: breakdown recov- compartment. bolts and, depending on the vehicle, to ery” in Section 5. The presence of the tools depends on access the emergency spare wheel.
  • Page 175: Puncture

    PUNCTURE (1/2) In the event of a puncture, depending on the vehicle, you will have: An emergency spare wheel or tyre in- flation kit (refer to the information on the following pages). If the emergency spare wheel has been stored for several years, have it checked by your Dealer to ensure that it is safe to use.
  • Page 176 PUNCTURE (2/2) Do not leave the tools un- Emergency spare wheel 2 To store the wheel in the cage secured inside the vehicle as they may come loose – Make sure the wheel is correctly po- This is stored in cage 4 under the floor under braking.
  • Page 177: Tyre Inflation Kit

    TYRE INFlATIoN KIT (1/6) Do not attempt to use the The kit is only approved for inflation kit if the tyre has inflating the tyres of the ve- been damaged as a result hicle originally equipped of driving with a puncture. with the kit.
  • Page 178 TYRE INFlATIoN KIT (2/6) Open the kit, remove caps 1 and 3 (it is – adjust the pressure: to increase essential not to remove the cap from it, continue inflating with the kit, to the bottle) then screw bottle 2 to its reduce it, turn button 7 located on base 3.
  • Page 179 TYRE INFlATIoN KIT (3/6) – store the kit; – after the first inflation procedure the tyre will still be leaking; it is vital to drive in order to plug the hole; – start immediately and drive at be- tween 12 and 36 mph (20 and 60 km/h) to distribute the product evenly throughout the tyre, stopping after a distance of 2 miles (3 kilome-...
  • Page 180 TYRE INFlATIoN KIT (4/6) – if the pressure is greater than 1.3 bar but less than the recommended pressure (refer to the label affixed to the edge of the driver’s door), read- just it; otherwise, please contact an authorised dealer: the tyre cannot be repaired.
  • Page 181 TYRE INFlATIoN KIT (5/6) With the engine running and the – after a maximum of 15 minutes, stop handbrake engaged: inflating and read the pressure (on pressure gauge 15). – unroll the hose from the container; Note: while the container is empty- –...
  • Page 182 TYRE INFlATIoN KIT (6/6) Precautions when using the – Affix the driving recommendation label to the dashboard where it can easily be seen by the driver; The kit should not be operated for more – Put the kit away. than 15 consecutive minutes. –...
  • Page 183 WHEEl TRIM - WHEEls Wheel trim with concealed Wheel trim with visible wheel wheel bolts bolts Remove the wheel trim using the To remove it without removing the hubcap tool 1, by inserting the tool into wheel, press it at the points indicated valve recess 2.
  • Page 184: Changing A Wheel

    CHANGING A WHEEl (1/2) Vehicles equipped with a jack Place the jack 4 horizontally; the jack head must be lined up with the sill 1 and wheelbrace closest to the wheel concerned, as If necessary, remove the hubcap. shown by arrow 2. Use the wheelbrace 3 to slacken off Crank up the jack 4 by hand at first to the wheel bolts.
  • Page 185 CHANGING A WHEEl (2/2) Undo the bolts and take off the wheel. Fit the emergency spare wheel on the central hub and turn it to locate the mounting holes in the wheel and the hub. If bolts are supplied with the emergency spare wheel, only use these bolts for the emergency spare wheel.
  • Page 186: Tyres (Tyre And Wheel Safety, Use In Winter)

    TYREs (1/3) Tyre and wheel safety When the tyre tread has been worn to the level of the warning strips, they The tyres are the only contact between become visible 2: it is then neces- the vehicle and the road, so it is essen- sary to replace your tyres because the tial to keep them in good condition.
  • Page 187: Tyre Pressures

    TYREs (2/3) Tyre pressures Vehicle fitted with a tyre pressure Pressures should be checked when the tyres are cold; ignore higher pressures loss warning system Adhere to the tyre pressures (including which may be reached in hot weather If under-inflated (puncture, low pres- the emergency spare wheel).
  • Page 188: Changing Wheels Around

    TYREs (3/3) Changing wheels around Use in winter snow or Winter tyres We would recommend that these be This practice is not recommended. Chains fitted to all four wheels to ensure that your vehicle retains maximum adhe- For safety reasons, fitting snow Emergency spare wheel sion.
  • Page 189: Front Lights: Changing Bulbs

    FRoNT lIGHTs: changing bulbs Daytime running light Turn the bulb holder 1 a quarter of a turn and take out the bulb. Bulb type: P21W. Front side light Turn the bulb holder 2 a quarter of a turn and take out the bulb. Bulb type: W5W.
  • Page 190: Fog Lights: Changing Bulbs

    FoG lIGHTs: changing bulbs Additional lights To comply with local legislation, or If you wish to fit fog lights to your ve- as a precaution, you can obtain an hicle, please see an authorised dealer. emergency kit containing a set of spare bulbs and fuses from an ap- proved Dealer.
  • Page 191: Rear Lights And Side Lights: Changing Bulbs

    REAR AND sIDE lIGHTs: changing bulbs (1/3) Direction indicator, brake and Release the light assembly from out- 4 side light and brake light side the vehicle by pulling towards the side lights Bulb type 4: P21/5W. rear. Undo bolt 1 to remove the light. 5 Indicator light Remove the bulb holder 3 by releasing Bulb type 5: PY21W.
  • Page 192 REAR AND sIDE lIGHTs: changing bulbs (2/3) High-level brake light Refitting To return it, proceed in the reverse – Remove the two plastic blanking order to removal. covers 8 from the inside. Check the tabs are correctly locked in – Unclip the light using a screwdriver, position.
  • Page 193 REAR AND sIDE lIGHTs: changing bulbs (3/3) Number plate lights 11 side indicator lights 12 Unclip the light 11 by pressing the Unclip the side mounted indicator tab 10 using a flat-blade screwdriver light 12 (using a flat-blade screwdriver or similar. or similar).
  • Page 194: Interior Lighting: Changing Bulbs

    INTERIoR lIGHTING: changing bulbs (1/2) Courtesy light Rear courtesy light Remove the bulb. Bulb type 2: W5W. Unclip lens 1 using a flat-blade screw- Remove the lens 3 using a tool such as driver or similar. a flat-blade screwdriver. Release the bulb. Bulb type: W5W.
  • Page 195: Luggage Compartment Light

    INTERIoR lIGHTING: changing bulbs (2/2) luggage compartment light Unclip the light 4 (using a tool such as a flat-blade screwdriver). Press tab 5 to release the lens 7 and access bulb 6. Bulb type: W5W. The bulbs are under pres- sure and may break when replaced.
  • Page 196: Fuses

    FUsEs (1/4) Fuses in passenger compartment A Clip 1 If any electrical component does not Remove the fuse using tweezers 1, lo- work, check the condition of the fuses. cated at the back of flap A. Unclip the access flap A. To remove the fuse from the tweezers, slide the fuse to the side.
  • Page 197 FUsEs (2/4) Fuses in engine compartment B special features of lPG versions Some functions are protected by fuses The specific LPG circuit shut-off fuse 2 located in the engine compartment is located in the box B. (unit B). However, because of their reduced accessibility, we advise you to have your fuses replaced by an approved Dealer.
  • Page 198 FUsEs (3/4) Allocation of fuses in the passenger compartment (the presence of certain fuses DEPENDs oN THE VEHIClE EQUIPMENT lEVEl) 5.26...
  • Page 199 FUsEs (4/4) Number Allocation Number Allocation Number Allocation Electric rear window Direction indicator light Automatic door locking Electric door mirrors Not used Electronic stability Front electric window program ESC Passenger compartment Courtesy light Automatic or sequential Steering column control gearbox Reverse and 29 Third row accessories...
  • Page 200: Radio Frequency Remote Control: Batteries

    RADIo FREQUENCY REMoTE CoNTRol: batteries Replacing the battery When refitting, ensure that the cover is correctly clipped into place. Open the cover at slot 1, using a flat- Note: It is not advisable to touch the blade screwdriver or similar, and re- electronic circuit in the key cover when place the battery 2, observing the type replacing the battery.
  • Page 201: Connecting A Battery Charger

    BATTERY: troubleshooting (1/2) To avoid all risk of sparks: Connecting a battery charger – Ensure that any consumers (cour- The battery charger must be com- tesy lights, etc.) are switched off patible with a battery with nominal before disconnecting or reconnect- voltage of 12 volts.
  • Page 202 BATTERY: troubleshooting (2/2) starting the vehicle using the battery from another vehicle If you have to use the battery from an- other vehicle to start, obtain suitable jump leads (with a large cross section) from an approved dealer or, if you al- ready have jump leads, ensure that they are in perfect condition.
  • Page 203: Wiper Blades

    WIPER BlADEs Check the condition of the wiper blades. You are responsible for their service life: – clean the blades, windscreen and rear screen regularly with soapy water; – do not use them when the wind- screen or rear screen are dry; –...
  • Page 204: Towing: Breakdown

    ToWING: breakdown (1/2) If the lever is stuck in P, even though Before any towing, put the gears into neutral (neutral position for vehicles you are depressing the brake pedal, the equipped with a manual gearbox or N lever can be released manually. position for vehicles equipped with an To do this, release the base of the lever, automatic gearbox).
  • Page 205 ToWING: breakdown (2/2) – Use a rigid towing bar. If a rope or cable is used (where the law allows this), Access to towing points only use the front 3 and rear 6 the vehicle being towed towing points. Unclip cover 5 or 7 by inserting a flat- must be able to brake.
  • Page 206: Fitting A Radio

    FITTING A RADIo location of front 2 or rear3 If your vehicle is not fitted with an audio system, one can be fitted and locations door speakers have been provided for: Unclip the cover using a flat-blade screwdriver or similar. –...
  • Page 207: Accessories

    ACCEssoRIEs Electrical and electronic accessories Before installing this type of accessory (particularly for transmitters/receivers: frequency bandwidth, power level, po- sition of the aerial, etc.), make sure it is compatible with your vehicle. You can get advice from an authorised dealer. Connect accessories with a maximum power of 120 Watts only.
  • Page 208: Operating Faults

    oPERATING FAUlTs (1/5) The following advice will enable you to carry out quick, temporary repairs. For safety reasons you should always contact an approved dealer as soon as possible. The starter is activated PossIBlE CAUsEs WHAT To Do Warning lights dim or fail to come on; Battery terminals disconnected, Retighten them, reconnect them or clean the starter does not run.
  • Page 209 oPERATING FAUlTs (2/5) on the road PossIBlE CAUsEs WHAT To Do Vibrations. Tyres not inflated to correct pres- Check the tyre pressures; if this is not the cause, have sures, incorrectly balanced or their condition checked by an approved dealer. damaged.
  • Page 210 oPERATING FAUlTs (3/5) on the road PossIBlE CAUsEs WHAT To Do Abnormal white smoke from the ex- Mechanical fault: damaged cylinder Stop the engine. haust head gasket. Contact an approved dealer. This is not necessarily a fault. Please refer to the information on “Special Smoke may be caused by features of diesel versions”...
  • Page 211 oPERATING FAUlTs (4/5) on the road PossIBlE CAUsEs WHAT To Do Whistling Roof aerial poorly positioned. Position the aerial. The engine overheats. The coolant Engine cooling fan not working. Stop the vehicle, switch off the engine and temperature indicator light comes contact an approved dealer.
  • Page 212 oPERATING FAUlTs (5/5) Electrical equipment PossIBlE CAUsEs WHAT To Do The wipers do not work. Wiper blades stuck. Free the blades before using the wipers. Faulty electrical circuit. Consult an approved dealer. The wiper does not stop. Faulty electrical controls. Consult an approved dealer.
  • Page 213 Section 6: Technical specifications Vehicle identification plates ............Engine identification plate .
  • Page 214: Vehicle Identification Plates

    VEHICLE IDENTIFICATION PLATES Quote the details given on identifica- 5 GTW (Gross train weight: vehicle tion plate A on all letters or orders. fully loaded, with trailer). The presence and location of the in- formation depends on the vehicle. 6 MPAW (Maximim Permissible Weight) for front axle.
  • Page 215: Engine Identification Plate

    ENGINE IDENTIFICATION PLATES The details given on engine plate A should be included with all correspond- ence and orders (location varies de- pending on engine). 1 Engine type 2 Engine suffix 3 Engine number...
  • Page 216: Engine Specifications

    ENGINE SPECIFICATIONS Versions 1.6 8V 1.6 16V 1.2 TCe 1.5 dCi Engine type H5Ft (see engine plate) Cubic capacity (cc) 1 598 1598 1 197 1.461 Diesel Type of fuel The use of unleaded petrol is essential, with the octane rating The label located in the Octane rating as stated on the label inside the fuel filler flap.
  • Page 217: Dimensions

    DIMENSIONS (in metres) 0,822 0,866 1,492 2.810 0.834 (1) 0.877 (1) 2,004 4,498 4.521 (1) 1.702 1,478 (1) depending on the vehicle...
  • Page 218: Weights (In Kg)

    WEIGHTS (in kg) (1/2) The weights indicated are for a basic vehicle without options: they vary depending on the your vehicle’s equipment. Consult an approved Dealer Five-seater versions, left-hand drive vehicles Maximum permissible all-up weight (MMAC) Weights indicated on the manufacturer’s plate (refer Maximum permissible all-up weight (MMTA) to Section 6 “Vehicle identification plate”) Gross Train Weight (MTR)
  • Page 219 WEIGHTS (in kg) (2/2) The weights indicated are for a basic vehicle without options: they vary depending on the your vehicle’s equipment. Consult an approved dealer. Seven-seater versions, left-hand drive vehicles Maximum permissible all-up weight (MMAC) Weights indicated on the manufacturer’s plate (refer Maximum permissible all-up weight (MMTA) to Section 6 “Vehicle identification plate”) Gross Train Weight (MTR)
  • Page 220: Replacement Parts And Repairs

    REPLACEMENT PARTS AND REPAIRS Original parts are based on strict specifications and are subject to highly-specialised tests. Therefore, they are of at least the same level of quality as the parts fitted originally. If you always fit genuine replacement parts to your vehicle, you will ensure that it performs well. Furthermore, repairs carried out within the manufacturer’s Network using original parts are guaranteed according to the conditions set out on the reverse of the repair order.
  • Page 221: Service Sheets

    SERVICE SHEETS (1/6) VIN: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □...
  • Page 222 SERVICE SHEETS (2/6) VIN: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □...
  • Page 223 SERVICE SHEETS (3/6) VIN: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □...
  • Page 224 SERVICE SHEETS (4/6) VIN: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □...
  • Page 225 SERVICE SHEETS (5/6) VIN: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □...
  • Page 226 SERVICE SHEETS (6/6) VIN: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □...
  • Page 227: Anticorrosion Check

    ANTICORROSION CHECk (1/6) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Stamp Corrosion repair operation to be carried out: Date of repair: Repair to be carried out: Stamp Date of repair: Repair to be carried out: Stamp Date of repair: 6.15...
  • Page 228 ANTICORROSION CHECk (2/6) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Stamp Corrosion repair operation to be carried out: Date of repair: Repair to be carried out: Stamp Date of repair: Repair to be carried out: Stamp Date of repair: 6.16...
  • Page 229 ANTICORROSION CHECk (3/6) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Stamp Corrosion repair operation to be carried out: Date of repair: Repair to be carried out: Stamp Date of repair: Repair to be carried out: Stamp Date of repair: 6.17...
  • Page 230 ANTICORROSION CHECk (4/6) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Stamp Corrosion repair operation to be carried out: Date of repair: Repair to be carried out: Stamp Date of repair: Repair to be carried out: Stamp Date of repair: 6.18...
  • Page 231 ANTICORROSION CHECk (5/6) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Stamp Corrosion repair operation to be carried out: Date of repair: Repair to be carried out: Stamp Date of repair: Repair to be carried out: Stamp Date of repair: 6.19...
  • Page 232 ANTICORROSION CHECk (6/6) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Stamp Corrosion repair operation to be carried out: Date of repair: Repair to be carried out: Stamp Date of repair: Repair to be carried out: Stamp Date of repair: 6.20...
  • Page 233 AlphAbeticAl index (1/5) changing a bulb .............5.17 → 5.21 ABS ...............2.24 → 2.27 changing a wheel............ 5.12 – 5.13 accessories................ 5.35 changing fuel while driving ........2.10 → 2.12 accessories socket ..........3.19 – 3.20 changing gear ..........2.22, 2.39 → 2.41 additional methods of restraint ..........
  • Page 234: Maintenance

    AlphAbeticAl index (2/5) fuel level ................1.48 electric door locking ............ 1.5 – 1.6 electric windows ............3.8 → 3.10 fuel priming bulb ..............1.67 emergency braking ..........2.24 → 2.27 fuel tank ..............1.63 → 1.67 emergency spare wheel ......5.3 – 5.4, 5.14 → 5.16 fuel tank capacity ...............
  • Page 235: Practical Advice

    AlphAbeticAl index (3/5) maintenance: jack ..............5.2, 5.12 – 5.13 bodywork ............4.14 – 4.15 interior trim ............4.16 – 4.17 mechanical ........ 4.4, 4.7 → 4.9, 6.9 → 6.14 keys ................1.2 → 1.4 map reading lights ............. 3.11 methods of restraint in addition to the front seat belts ....1.17 →...
  • Page 236: Technical Specifications

    ......... 1.2 – 1.3 tailgate ..............3.32 – 3.33 remote control electric door locking ........1.4 tanks and reservoirs RENAULT ANTI-INTRUDER DEVICE (RAID) ..... 1.7 brake fluid ..............4.7 replacement parts ..............6.8 coolant ................4.8...
  • Page 237: Alphabetical Index

    AlphAbeticAl index (5/5) vehicle identification ............6.2 vehicle identification plates ......... 6.2 – 6.3 ventilation heating and air conditioning system ....3.4 → 3.7 warning buzzer ........1.8 – 1.9, 1.57 – 1.58 warning lights........1.42 → 1.46, 1.49 → 1.54 washing ..............

Table of Contents
