  • Page 1 Hikvision Technical Manual DS-8000HSI-S Series Net DVR Technical Manual ©2006 – 2010 by HIKVISION. All rights reserved.
  • Page 2 HIKVISION and then only on the condition that this notice is included in any such reproduction. No information as to the contents or subject...
  • Page 3 Hikvision Technical Manual Contents 1. Overview 2. Model Description 3. Features 4. Specifications ©2006 – 2010 by HIKVISION. All rights reserved.

  • Page 4: Front Panel

    DS-8000HSI-S series combines the advantages of Digital Video Recorder (DVR) and Digital Video Server (DVS). It is widely applied as a stand-alone unit or a part of a powerful surveillance system. Front Panel DS-8004HSI-S Rear Panel DS-8008HSI-S Rear Panel ©2006 – 2010 by HIKVISION. All rights reserved.
  • Page 5 Hikvision Technical Manual DS-8016HSI-S Rear Panel ©2006 – 2010 by HIKVISION. All rights reserved.

  • Page 6: Model Description

    Hikvision Technical Manual 2. Model Description DS-8004HSI-S: 4-ch video input and 4-ch video loop out. No audio input. Each channel can max support CIF encoding resolution real time. It has 4 SATA interfaces. DS-8008HSI-S: 8-ch video input and 8-ch video loop out. No audio input. Each channel can max support CIF encoding resolution real time.

  • Page 7: Preview And Playback

    Support play forward, backward, pause, frame-by-frame, etc  Support play back by files or by time/date  Displays local record status 3.2.3 PTZ:  Support multiple PTZ protocols  Support preset, sequence and cruise ©2006 – 2010 by HIKVISION. All rights reserved.
  • Page 8 RS-232 supports transparent channel function  Support IE preview and configuration  Support SADP protocol  Support remote log query 3.5 Development support:  Provide network SDK (Software Development Kit)  Provide client demo source code ©2006 – 2010 by HIKVISION. All rights reserved.

  • Page 9: Specifications

    1 USB interface, can support USB disk, USB HDD, USB USB interface DVD-R/W and CD-R/W 1 VGA interface, support resolution: 800x600/60Hz, VGA interface 1024x768/60Hz, 1280*1024/60Hz External alarm Relay output Power supply 100~240VAC, 6.3A, 50~60Hz Power ≤70W (without HDD) consumption ©2006 – 2010 by HIKVISION. All rights reserved.
  • Page 10 Hikvision Technical Manual Working -10° C ~ +55° C temperature Working 10% ~ 90% humidity Size 470mm(D)*441mm(W)*90mm(H) Weight ≤8Kg (without HDD) PAL: 176×144(QCIF), 352×288(CIF), 704×288(2CIF), 528×384(DCIF), 704×576(4CIF); NTSC: 176×120(QCIF), 352×240(CIF), 704×240(2CIF), 528×320(DCIF), 704×480(4CIF). ©2006 – 2010 by HIKVISION. All rights reserved.
