Installation Instructions - Bestway Lay-Z-Spa Owner's Manual

WARNING: TO REDUCE THE RISK OF INJURY: Never pour water with a temperature higher than 40°C (104°F)
into the spa pool directly.
WARNING: The use of alcohol, drugs, or medication can greatly increase the risk of fatal hyperthermia.
Hyperthermia occurs when the internal temperature of the body reaches a level that is several degrees above the
normal body temperature of 37°C(98.6°F). The symptoms of hyperthermia include an increase in the internal
temperature of the body, dizziness, lethargy, drowsiness, and fainting. The effects of hyperthermia include failure to
perceive heat; failure to recognize the need to exit spa or hot tub; unawareness of impending hazard; fetal damage
in pregnant women; physical inability to exit the spa or hot tub; and unconsciousness resulting in the danger of
drowning.
CONSULT YOUR PHYSICIAN FOR RECOMMENDATIONS.
CAUTION: The spa should not be setup or left out in temperature lower than 4˚C (40˚F).
CAUTION: Do not use the spa alone.
CAUTION: People with infectious diseases should not use a spa.
CAUTION: Do not use the spa immediately following strenuous exercise.
CAUTION: Always enter and exit the spa slowly and cautiously. Wet surfaces are slippery.
CAUTION: To avoid damage to the pump, the spa must never be operated unless the spa is filled with water.
CAUTION: Immediately leave spa if the user feels uncomfortable or sleepy.
CAUTION: Never add water to chemicals. Always add chemicals to water to avoid strong fumes or violent reactions
that may result in hazardous chemical spray.
NOTE: Please examine equipment before use. Notify Bestway at the customer service address listed on this
manual for any damaged or missing parts at the time of purchase. Verify that the equipment components represent
the models that you had intended to purchase.
SAVE THESE INSTRUCTIONS
SPECIFICATIONS (FOR #54075)
Capacity:
Water Capacity(80%):
Inflated Size:
Filled Weight:
Power Rate:
Temperature Capacities:
Massaging Turbo Blower:
SPECIFICATIONS (FOR #54090)
Capacity:
Water Capacity(80%):
Inflated Size:
Filled Weight:
Power Rate:
Temperature Capacities:
Massaging Turbo Blower:

INSTALLATION INSTRUCTIONS

NOTE: Check to ensure all parts are present.
I: Top Leatheroid Cover
II: Chemical Floater
III: Inflation Hose
IV:Side Tables ( for Oval Pool #54090)
V: Pump
VI: Spa with Leatheroid Cover
VII: Repair Patch
VIII: Spa Components
4 Adults
900L (240gal)
206cmx71cm (81"x28")
1,200Kg (2,643Lb)
220-240V AC, 2050W
40°C (104°F).
600W
4-6 Adults
1200L (317gal)
286cmx183cmx76cm (112.5"x72"x30")
1,550Kg (3,414Lb)
220-240V AC, 2050W
40°C (104°F).
600W
IV
Heat Element:
Pump:
RCD Protection:
Power Cable:
Increased Heat Rate:
Nominal Water Flow:
Actual Water Flow:
Heat Element:
Pump:
RCD Protection:
Power Cable:
Increased Heat Rate:
Nominal Water Flow:
Actual Water Flow:
I
V VI
3
Stainless steel, 2,000W
50W Circulation Filter Pump
Yes
4.5m
Approximately 1.5-2°C/h (3-4°F/h)
2,006 L/h (530 gal./h)
757 L/h ( 200 gal./h)
Stainless steel, 2,000W
50W Circulation Filter Pump
Yes
4.5m
Approximately 1°C/h (1.8°F/h)
2,006 L/h (530 gal./h)
757 L/h ( 200 gal./h)
II III
VII VIII
