Menu Items
Trigger Setup
(continued)
RT60 dB Down
Auto RT60
Note

Settings Descriptions

RTA Settings Menu

11/8/00
Submenu Available Settings Options
Run Logic In
Logic Out 0 - 65535
8 Characters
Title Setting
Use the title setting to create a title or heading for printed
reports. This title will be placed at the top of each RTA
report you print.
Gain Setting
Gain adjusts the voltage level delivered to the measuring
portion of the meter from the microphone and preamplifier.
Bandwidth Setting
Selects 1/1 or 1/3 octave filter bandwidth for real-time anal-
ysis.
Detector Setting
Selects the averaging method to be used.
• Linear
RTA (optional)
Available Settings Options
Low
High
5
10
15
20
25
30
No
Yes
10-5
