IPC Eagle 14” Operation Manual

Commercial upright vacuum
Hide thumbs
Table of Contents

Advertisement

Quick Links

COMMERCIAL
14" and 16"
UPRIGHT VACUUM
OPERATIONS & PARTS MANUAL
March 2004
REV A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 14” and is the answer not in the manual?

Questions and answers

Related Manuals for IPC Eagle 14”

Summary of Contents for IPC Eagle 14”

  • Page 1 COMMERCIAL 14” and 16” UPRIGHT VACUUM OPERATIONS & PARTS MANUAL March 2004 REV A...
  • Page 2 If you observe the recommendations listed below, this will ensure maximum performance by the appliance, the longest possible life and a high level of safety. • Do not clean the appliance with solvents - the body and accessories are in plastic and, therefore, may get dama- ged.

  • Page 3: System Start-Up

    SYSTEM START-UP COMMERCIAL 1 Ergonomic handle 2 Power cord 3 Hose 4 Telescoping extension 5 Switch 6 Carrying handle 7 Cord winding device 8 Cover 9 Vent grid 10 Container 11 Engine housing 12 Electric brush 13 Base 14 Hi/Low vac motor switch CONNECTING THE HOSE Insert the rotating sleeve into the bag-holding sleeve, insert the second rota- ting sleeve into the telescoping element, and hook the hose to the handle.

  • Page 4: Starting The Brush

    STARTING THE BRUSH Put your foot on the PUSH sign and tilt the vacuum-cleaner body. CHECKING THE BRUSH The brush-checking device continuously monitors the operation of the brush: Green light: the brush is working correctly Red light: the brush is either blocked or it is undergoing excessive stress. Turn the machine off, detach the plug from the mains, and look for the cause of the blocking.

  • Page 5: Replacing The Filter

    REPLACING THE FILTER Pull out the filter holder and replace the filter, or clean it by tapping it lightly (replace it approximately every 20 bags). REPLACING THE HEPA FILTER; REPLACING OR CLEANING THE PRE-FILTER Pull latch “A” in order to unhook the vent grid; at the same time, slide it (in the direction shown by the arrow) so that it comes free.

  • Page 6: Replacing The Roller

    In order to disassemble the vac motor housing, remove the dust bag cover, unhook the vent grid and unscrew the four screws from the shell. INSTALLING THE VAC MOTOR Place the rubber block of the engine holder onto its dedicated, oriented sup- porting element.
  • Page 7 REPLACING THE ELECTRONIC BOARD Slide the board off the guides and detach the connection. Disconnect the supply wires from the terminal and replace the board. DISASSEMBLING THE JOINT Unscrew the case screws. Lift the cover and free the joint. Unscrew the cable-holder screws from the vacuuming device. Slide the joint off.

  • Page 8: Specification

    ACCESSORIES PROVIDED 1 - Small brush 2 - Crevice tool 3 - Curved sleeve 4 - Hose 5 - Telescoping extension SPARE PARTS 1 - Hepa filter 2 - Air freshener 3 - Filter bag 4 - Filter 5 - Pre-filter ELECTRIC DIAGRAM Caution! Any job involving the electric plant...
  • Page 9 COMMERCIAL 14 & 16 VACUUM ASSEMBLY Reference Part Number Description Number VCSA1GUV0 HOUSING, VACUUM USE KIT VC2000 SCREW VCSA1PORTBBU BACK COVER, COMPLETE W/GASKET VCSA3MAWCC MOTOR, VACUUM, COMPLETE VCA8LAMO CLIP, BRASS USE KIT VC2000 SCREW VCA1CWEGC COVER, UPPER, LIGHT GRAY 10+11 VCA1TAPDX RIGHT INSERT, BACK COVER VCA1TAPSX...
  • Page 10 COMMERCIAL 14 & 16 VACUUM ASSEMBLY Reference Part Number Description Number VCSA1INDNE FULL BAG INDICATOR, BLACK VCA1MASAGS SLEEVE, DARK GRAY VCA1ANMGS RING, SLEEVE, DARK GRAY VC1000 BAG, PAPER VCA1MAGINE HOSE CUFF, BLACK VCA2TESC46 HOSE, L=18" VCA4PNE ROUND BRUSH TOOL, BLACK VCA4LNE CREVICE TOOL, BLACK VCA1MACUNE...
  • Page 11 COMMERCIAL 14 & 16 VACUUM ASSEMBLY Reference Part Number Description Number VCA3INTR RED BIPOLAR SWITCH, WITH LIGHT VCA3INTN BLACK SWITCH, HI-LOW VCA1MPWHSGRCU COVER, SWITCH VCA8LAMO1 PLATE USE KIT VC2000 SCREW VCA3CA3NEUS POWER CORD, BLACK, 50' VC2000 HARDWARE KIT FOR VACUUM ASSEMBLY Recommended Stocking Item PAGE 9...
  • Page 12 COMMERCIAL 14 & 16 BASE ASSEMBLY Reference Part Number Description Number VCA1BAS350 BASE, 14" BASE, 16" USE KIT VC2001 SCREW USE VCSA4RSP14N OR TBD RIGHT SIDE PLATE, ROLLER BRUSH USE VCSA4RSP14N OR TBD BEARING USE VCSA4RSP14N ROLLER BRUSH 14" USE TBD ROLLER BRUSH 16"...
  • Page 13 COMMERCIAL 14 & 16 BASE ASSEMBLY Reference Part Number Description Number VCA1PER PIN, WHEEL VCSA1MICG MICROSWITCH, COMPLETE VCA1CMICG COVER, MICROSWITCH USE KIT VC2001 SCREW 17+22 VCSA1CFSNEG TOP COVER WITH WINDOW USE KIT VC2001 SCREW USE KIT VC2001 SCREW VCA1CABCC CLAMP, CORD VCSA3SEG2 CIRCUIT BOARD, 120 VOLT VCA1VETGBE...

  • Page 14: Warranty Policy

    Warranty Policy Limited Warranty Eagle Power Products (EPP) warrants new cleaning equipment against defects in material and workmanship under normal use and service to the original purchaser as detailed below. 10 Years Subject to the conditions stated below, EPP warrants polyethylene tanks and housings to be free from defects in materials and workmanship for a period of ten years.
