HOW TO DO 360º STUNT ROLLS
1.In order to make your ATOM™ X do 360º rolls you must fully charge your battery.
Note: The ATOM™ X will not do 360º stunt rolls in Mode1 and when the drone is running low
battery (The LED lights on the drone start flashing).
2.Once you are ready to attempt a 360º roll,short press the "STUNT" button on the top right hand side
of your controller (see Remote Diagram D),you will hear continous beeping sounds.This means you
are now in"STUNT MODE"
3.Now quickly move your right control stick in any of 4 directions; up,down,left or right and your
ATOM™ X copter will instantly roll in the associated direction(See diagram E).After stunt roll the
beeping sounds will stop.
360˚Stunt-Roll
D
9

USING YOUR ON BOARD CAMERA AND VIDEO RECORDER

Your ATOM™ X comes equipped with an onboard digital camera that takes both video and still photographs.
Now you can have hours of fun creating aerial photography and videos for family and friends.
WHAT YOU WILL NEED TO GET STARTED USING YOUR CAMERA
1.One microSDHC card (not included)
2.One microSDHC card reader (included)
3.One Computer with USB port and Windows Media Player or other Media player that can play AVI files
(not included).
FORMATTING YOUR microSDHC CARD
Before you can begin to take videos or digital photographs you must first format your microSDHC card. To
format your microSDHC card simply place the microSDHC card into the included USB card reader and plug
it into your computers USB port (See diagram 1 and 2 below). After a few moments an icon will appear on
your Desktop.Right click on the Icon and follow instructions to format your microSDHC card.
INSTALLING THE microSDHC CARD IN YOUR NEUTRON
• Keep ATOM™ X power turned off.
• Place the formatted microSDHC card into the back of the quadrocopter's digital camera port( see
diagram 3 below).Push gently and consistently until you hear and feel the microSDHC card"click"into the
digital camera slot.
• Turn on your ATOM™ X power and properly sync it to the Controller (see HOW TO SYNC YOUR DRONE on
page 4 ).
• When you have successfully installed your microSDHC card and your quadrocopter is powered up,you will
see solid green LED lights on the top of your ATOM™ X.
NOTE:If you see the green LED lights keep flashing,it means you have not installed your microSDHC card
correctly or there is a problem with your card. If this happens first make sure that the product is not in
Video Record mode and if not then please reformat and try again.If you continue to encounter problems
E
call our customers service line at 949.566.9573 Ext 1 for assistance.
TAKING DIGITAL PHOTOS
To take photographs simply short press the CAMERA/VIDEO button on the top of the controller (refer to
CONTROLLER DIAGRAM on pg.3),when you push the button you will hear a "beep" and the green
indicating LED light will flash one time indicating that a picture has been taken.
RECORDING VIDEOS
To record a video first make sure that your quadrocopter is fully charged and that you have correctly
installed the microSDHC card in the quadrocopters camera port.Begin recording a video by pressing the
CAMERA/VIDEO button for a few seconds (see CONTROLLER DIAGRAM on page 3).The green LED lights on
the top ATOM™ X will flash constantly to indicate that you are in video mode and the camera is recording.
To stop the video recording,press the button again.The green LED lights on the top of the camera will
change to solid indicating that video recording has stopped and the Camera is in ready mode again.
IMPORTANT NOTICE : You can not take photos and videos at the same time.
TM QUADROCOPTER
microSDHC card
goes in back slot
microSDHC card facing up microSDHC card facing up
Diagram 1 Diagram 2 Diagram 3
Red LED
Light
Diagram 4
