Misc. on the TD3 TWINDRIVE
This system is a TWINDRIVE system developed for leisure beds and for indoor use in private homes.
Warranty
There is 36 months' warranty on the TWINDRIVE
date of the individual products (see label). LINAK A/S' warranty is only valid in so far as the equipment has been used and
maintained correctly and has not been tampered with. Furthermore, the system must not be exposed to violent treatment. In
the event of this, the warranty will be ineffective/invalid. For further details, please see standard terms of sale and delivery for
LINAK A/S.
Maintenance
Clean dust and dirt on the outside of the system at appropriate intervals and inspect them for damage and breaks.
Inspect the connections, cables and plugs and check for correct functioning as well as fixing points.
The cleaners and disinfectants must not be highly alkaline or acidic
(pH value 6-8).
It is not allowed to use solvents for cleaning up.
Max. load running head and foot end motors at the same time in upward direction is 350 Nm on Head
motor, and 200 Nm on Foot end motor.
For customers in the US/Canada:
The mains cable for this product has a polarised plug (one blade is wider than the other). It will only fit in a polarised
outlet one way. If it does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician
to install a proper outlet. Do not change the plug in any way.
Description of the TWINDRIVE
Each TWINDRIVE TD3 unit consists of 2 internal motors and a built-in control, which makes it a very compact unit. The mains
®
cable is exchangeable. Only the handset must be paired.
Application of the TWINDRIVE
Irrespective of the load the Duty cycle: 10% ~ 3 min./ hour or max. 2 min. at continous use followed by 18 min.
not in use.
Do not turn on the system if it is not mounted in a bed.
system
®
products against manufacturing faults calculated from the production
®
TD3 system
®
TD3 system:
®
