Linak TWINDRIVE TD1 Product Data Sheet

P R O D U C T D A T A S H E E T
TWINDRIVE
TD1

Features:

• Angle footrest 45°± 3°
• Angle headrest 68° ± 3°
• Compatible with HB10 and HB20
• EOP in TD1 280 version
• Toroidal Transformer in TD1 280 and EI core
Transformer in TD1 220
• Duty cycle: 10% ~ 6 min. per hour max. 2 min.
continuous use followed by 18 min. not in use
• Max. speed: 0.58 RPM with max. torque
• Installation dimension: 796 mm length x 90 mm
height x 90 mm width. Installation dimension
on the shaft 581 ± 1 mm
• Colour: Grey plastic on motor
housing RAL 7035, closing
device Grey RAL 7016
• Ambient temperature:
+5°C to +40°C
• Storage and transport
temperature:
-10°C to + 70°C
• Approved according to EN 60335-1
• EMC according to EN55014 -1 / EN55014 - 2
• Low built-in height
• Low noise level

Options:

• Emergency lowering (2 x 9V batteries)
• External Mains cut-off
• Internal mains cut off (only TD1 220)
• 1 extra channels for an extra motor (analogue
systems)
• Up to 2 extra channels for extra motors (only
TD1 280 with memory and Infrared)
• Memory (only TD1 280)
• Memory and Infrared (only TD1 280)
• Black
TM
The TWINDRIVE™ TD1 is a completely new
product, which is part of the Comfort furniture
group and has been produced to supply the
growing demands for motorised systems in the
leisure bed area.
TD1 is characterised by the very low built in
height, which makes it unique in this market
and gives much more free height under the bed
than previous systems for e.g. storage or easy
cleaning access.
