Chapter 12
Configuring Interface Characteristics
Use the first or second method in the previous list to manually configure the cutoff-power value by entering the power inline
consumption default wattage or the power inline [auto | static max] max-wattage command. If you do not manually
configure the cutoff-power value, the switch automatically determines the value by using CDP power negotiation. If the switch
cannot determine the value by using one of these methods, it uses the default value of 15.4 W. Power Consumption Values
You can configure the initial power allocation and the maximum power allocation on a port. However,
these values are only the configured values that determine when the switch should turn on or turn off
power on the PoE port. The maximum power allocation is not the same as the actual power consumption
of the powered device. The actual cutoff power value that the switch uses for power policing is not equal
to the configured power value.
When power policing is enabled, the switch polices the power usage at the switch port, which is greater
than the power consumption of the device. When you are manually set the maximum power allocation,
you must consider the power loss over the cable from the switch port to the powered device. The cutoff
power is the sum of the rated power consumption of the powered device and the worst-case power loss
over the cable.
The actual amount of power consumed by a powered device on a PoE port is the cutoff-power value plus
a calibration factor of 500 mW (0.5 W). The actual cutoff value is approximate and varies from the
configured value by a percentage of the configured value. For example, if the configured cutoff power is
12 W, the actual cutoff-value is 11.4 W, which is 0.05% less than the configured value.
We recommend that you enable power policing when PoE is enabled on your switch. For example, if
policing is disabled and you set the cutoff-power value by using the power inline auto max 6300
interface configuration command, the configured maximum power allocation on the PoE port is 6.3 W
(6300 mW). The switch provides power to the connected devices on the port if the device needs up to
6.3 W. If the CDP-power negotiated value or the IEEE classification value exceeds the configured cutoff
value, the switch does not provide power to the connected device. After the switch turns on power on the
PoE port, the switch does not police the real-time power consumption of the device, and the device can
consume more power than the maximum allocated amount, which could adversely affect the switch and
the devices connected to the other PoE ports.
Because the switch supports internal power supplies and the Cisco Redundant Power System 2300 (also
referred to as the RPS 2300), the total amount of power available for the powered devices varies
depending on the power supply configuration.

Connecting Interfaces

Devices within a single VLAN can communicate directly through any switch. Ports in different VLANs
cannot exchange data without going through a routing device. With a standard Layer 2 switch, ports in
different VLANs have to exchange information through a router. By using the switch with routing
enabled, when you configure both VLAN 20 and VLAN 30 with an SVI to which an IP address is
assigned, packets can be sent from Host A to Host B directly through the switch with no need for an
external router
OL-9775-08
If a power supply is removed and replaced by a new power supply with less power and the switch
does not have enough power for the powered devices, the switch denies power to the PoE ports in
auto mode in descending order of the port numbers. If the switch still does not have enough power,
the switch then denies power to the PoE ports in static mode in descending order of the port numbers.
If the new power supply supports more power than the previous one and the switch now has more
power available, the switch grants power to the PoE ports in static mode in ascending order of the
port numbers. If it still has power available, the switch then grants power to the PoE ports in auto
mode in ascending order of the port numbers.
(Figure
12-1).
Catalyst 3750-E and 3560-E Switch Software Configuration Guide
Interface Types
12-11
