3. Hardware Overview
3.1. Tool Description
ITEM
OBD II CONNECTOR
❶
Connects the tool to the vehicle's Data Link connector (DLC).
Dongle
❷
USB dongle.
USB CONNECTOR
❸
Connects the tool to the PC/Laptop through USB Cable.
Programmer
❹
Program keys.
Programmer Female Pin
❺
Connects programmer to device.
Programmer Male Pin
❻
Connects programmer to device.
BMW Multi Tool User Manual
Description
5
