- Page 1 Ad18 Shenzhen ShuangMuSanLin Electronics Co., Ltd.
- Page 2 Safety Notes To assure the best performance, please read this manual carefully. Keep it in a safe place for future reference. Warning Install this unit in a well ventilated, cool, dry, clean place-away from direct sunlight, heat sources, vibration, dust, moisture, or cold. Do not expose this unit to sudden temperature changes from cold to hot, and do not locate this unit in an environment with high humidity ( i.e.
- Page 3 AD-18 Features Ad18 is a multi-functional power ampliÞer with headphone ampliÞer. Up to six kinds of input including USB, coaxial, analog, bluetooth and two optical jacks. Using the advanced CSR BT 4.2 as bluetooth solution. Using DSP+AMP from TI .
- Page 4 Part Names and Functions Display USB input Bluetooth antenna Remote receiver window *3.5 coaxial/3.5 optical left speaker+ Knob Subwoofer output left speaker- Earphone jack Optical input Right speaker+ Analog AUX input Power input jack Right speaker- *Note Coaxial Input Subwoofer Output Coaxial Input Subwoofer Output Grounding...
- Page 5 Bare wire length 8-10mm 3、lock the speaker cable 1、Rotary screw cap. Bare wire is too long, Using the 2、Side insert speaker cable cause a short-circuit Banana plugs [CORRECT] Operation Function Key: Long press to switch off unit. When menu display, Long press to return to desktop and short press to swiching menu.
- Page 6 8. in last usage, initial volume will set up as 8 itself when you restart it. EQ mode you are using. Digital Audio format. Main Menu lntroduction Short press MENU key into AD18 menu Input source→Output way→EQ Mode→Bass adjust→Treble adjust ↑ ← Display Color setting Dimmer Setting Input source MENU (Þgure 2)
- Page 7 OUTPUT mode (Þgure 3) Device includes two outputs, power ampliÞer and headphone ampliÞer OUTPUT output. Clockwise revolving knob to switch. SPK(Speaker)→HP(Headphone) SPEAKERS Output mode selection. (Þgure 3) EQ mode MENU (Þgure 4) EQ-MODE Totally seven kinds of input mode. Clockwise revolving knob to switch. EQ-OFF EQ-OFF→SDB→S-BASS→H-ROCK→L-ROCK ↑...
- Page 8 NFC is on when you connect with it. Ad18 will recognize phone when phone NFC area get close and induce to AD18 NFC area. Notes: Please make sure your phone get NFC before you want to use NFC function...
- Page 9 Switch Function Volume- Audio sourceselection EQmode Power AmpliÞer (Press A to switch to control the AD18) NO function NO function Shenzhen Shuangmusanlin Electronics Co., Ltd. Address: 8th Floor B6 Building JunFeng Industrial Park , Fuyong town BaoAn District Shenzhen China Tel: +86-755-27444178 http://www.smsl-audio.com/...
