4-1-3. Order for Setting Options (Wired Remote Controller)

1. If you want to use the various additional functions for your Wired Remote Controller, press the Set and Esc buttons at the
same time for more than three seconds.
You will enter the additional function settings, and the [main menu] will be displayed.
2. Refer to the list of additional functions for your Wired Remote Controller on the next page, and select the desired menu.
Using the [ ]/[ ] buttons, select a main menu number and press the [ ] button to enter the sub-menu setting screen.
Using the [ ]/[ ] buttons, select a sub-menu number and press the [ ] button to enter data setting screen.
When you enter the setting stage, the current setting will be displayed.
Refer to the chart for data settings.
Using the [ ]/[ ] buttons, select the settings. Press the [ ] button to move to the next setting.
Press the Set button to save the settings and exit to the sub-menu setting screen.
Press the Esc button to exit to normal mode.
While setting the data, you can use the [ ]/[ ] buttons to set the range of Data bit.
While configuring the setting, press the Esc button to exit to the setting sub-menu without saving your changes.
Main Menu
Sub-menu
SEGs for Use
1 2 3 4 5 6
4-12
