No.
Parts
3
Top Cover & Drain Pan
Procedure
7) Remove the screw and separate the Display
Cover. (Use +Screw Driver)
8) ) Remove the 2 screws. (Use +Screw Driver)
9) Push the hook and separate the Cover.
10) Remove the 8 screws. (Use +Screw Driver)
11) Separate the Indoor Unit upper part from
the Body
3-7
Disassembly and Reassembly
Remark
