KM112 - KM112P
6. HoRN oRIENTATIoN
The KM112 features a 12" coaxial transducer coupled to an asymmetric horn. Because the horn is
asymmetric, its sound dispersion pattern is different in respect to its axes: 100° x 30°.
The horn can be manually rotated 90° thanks to the red guide that rotates the horn from a 100°
horizontal coverage (Wide) to a 30° horizontal coverage (Narrow).
WIDE
100° horizontal - 30° vertical
NARROW
30° horizontal - 100° vertical
Ver. 1.0
9
