Instruction Manual
REMOTE ALARM
POWER
Data, drawings, and other material contained herein are proprietary to Cross Technologies, Inc.,
but may be reproduced or duplicated without the prior permission of Cross Technologies, Inc.
for purposes of operating the equipment. Printed in USA.
When ordering parts from Cross Technologies, Inc., be sure to include the equipment
model number, equipment serial number, and a description of the part.
FC = 1350
MENU
G=+10.0 REF AUTO-I
EXECUTE
C
T
ROSS
ECHNOLOGIES, INC.
6170 Shiloh Road
Alpharetta, Georgia 30005
(770) 886-8005
FAX (770) 886-7964
Toll Free 888-900-5588
WEB www.crosstechnologies.com
E-MAIL info@crosstechnologies.com
Model 2083-1919-02
MODEL 2083
TRANSLATOR
C
Translator
April 2017, Rev. 0
T
ROSS
ECHNOLOGIES INC.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 2083-1919-02 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cross Technologies 2083-1919-02

Summary of Contents for Cross Technologies 2083-1919-02

  • Page 1 POWER Data, drawings, and other material contained herein are proprietary to Cross Technologies, Inc., but may be reproduced or duplicated without the prior permission of Cross Technologies, Inc. for purposes of operating the equipment. Printed in USA. When ordering parts from Cross Technologies, Inc., be sure to include the equipment model number, equipment serial number, and a description of the part.

  • Page 2: Table Of Contents

    All Cross Technologies, Inc. products are warranted against defective materials and workmanship for a period of one year after shipment to customer. Cross Technologies, Inc.’s obligation under this warranty is limited to repairing or, at Cross Technologies, Inc.’s option, replacing parts, subassemblies, or entire assemblies. Cross Technologies, Inc. shall not be liable for any special, indirect, or consequential damages.

  • Page 3: General

    1.0 General 1.1 Equipment Description 2083-1919-02 Block Translator - The 2083-1919-02 Block Translator inverts a ± 250 MHz block in the 0.95- 1.95 GHz band with low group delay and flat frequency response. The 0.95-1.95 GHz input is mixed with a synthesized local oscillator (LO) signal, first to a ±...

  • Page 4: Technical Characteristics

    1.2 Technical Characteristics TABLE 1.0 2083-1919-02 Block Translator Specifications* Input Characteristics Input Impedance/RL 75Ω / 12 dB Frequency 950 - 1950 MHz Input Composite Level -50 to -30 dBm Input, maximum no damage +10 dBm Output Characteristics Impedance/RL 75Ω / 12 dB Frequency Fc = 1.2 - 1.7 GHz,±250 MHz...
  • Page 5 75Ω BNC (RF IN), 75Ω BNC (RF OUT) 50Ω BNC (RF IN), 50Ω BNC (RF OUT) NN - 50Ω N (RF IN), 50Ω N (RF OUT) Contact Cross Technologies for other options. 2017 Cross Technologies,Inc. 2083-1919-02 Manual, Rev. 0 Page 5...

  • Page 6: Monitor & Control Interface

    A) Remote serial interface Protocol: RS-232C, 9600 baud rate, no parity, 8 data bits, 1 start bit, and 1 stop bit. (RS-232C, RS-422, or RS-485 - option -Q) M&C Cable Diagram - Cross Technologies Frequency Converters Male DB-9 Female DB-9 2015/16/17 M&C Port...
  • Page 7 B) Status Requests - Table 1.1 lists the status requests for the 2083-1919--02 and briefly describes them. * PLEASE NOTE: The two character {aa}(00-31) prefix, in the table below, should be used ONLY when RS-485, (OPTION-Q), is selected. TABLE 1.1 2083-1919-02 Stat t us TABLE 1.1 2083-1919-02 Status Requests Status Requests...
  • Page 8 C) Commands Table 1.2 lists the commands for the 2083-1919-02 and briefly describes them. After a command is sent the 2083 sends a return “>” indicating the command has been received and executed. General Command Format - The general command format is {CND...}, where:...

  • Page 9: Installation

    The 2083-1919-02 consists of one RF/Controller PCB housed in a 1 RU (1 3/4 inch high) by 16 inch deep chassis. A switching, ± 12, +24, +5 VDC power supply provides power for the assemblies. The 2083-1919-02 can be secured to a rack using the 4 holes on the front panel. Figure 2.0 shows how the 2083-1919-02 is assembled.
  • Page 10 -50 to -30 dBm output, -50 to -30 dBm input, 100-240 ±10% VAC, 47-63 Hz. BNC Connector. see Table 2.2. see Table 2.2. FIGURE 2.1 2083-1919-02 Rear Panel I/Oʼs TABLE 2.1 J1 1 0 TABLE 2.1 J10 Pinouts* Function Rx+ (RS-232C) Tx+ (RS-232C) TABLE 2.2 In n put/Output...

  • Page 11: Operation

    2.4 Installation / Operation 2.4.1 Installing and Operating the 2083-1919-02, Frequency Translator Section 1. Connect a -50 dBm to -30 dBm signal to RF IN, J3 (Figure 2.1) 2. Connect the RF OUT, J1, to the external equipment 3. Connect 100-240 ±10% VAC, 47 - 63 Hz to AC connector on the back panel.

  • Page 12: Menu Settings

    If programming is initiated and no operator action takes place for approximately 30 seconds (before the final press of the Menu/Execute switch) the display will revert to its previous status and you will need to start over. 2083-1919-02 Manual, Rev. 0 Page 12 04/19/17...
  • Page 13 During gain changes, the vertical movement will raise or lower the number in the direction of the arrows. b. For other functions such Remote on/off, the vertical switch will alternately turn the function on or off regardless of the direction operated. 2083-1919-02 Manual, Rev. 0 Page 13 04/19/17...
  • Page 14 OR you can scroll to “R”, push the Menu/Execute switch to get to: SAVE SETTINGS? Selecting Y will save the new settings. Selecting N will revert to the previous settings. Figure 2.5 (page 12) gives the menu items and how to make changes. 2083-1919-02 Manual, Rev. 0 Page 14 04/19/17...
  • Page 15 Internal 10 MHz Reference. REF = AUTO -I appears on the front panel display where -I indicates that the unit is using the Internal 10 MHz Reference. The Internal 10 MHz Reference is present on the reference output connector, J8. 2083-1919-02 Manual, Rev. 0 Page 15 04/19/17...
  • Page 16 Menu 9 Set RS-485 Address RS485 ADDRESS = 00 SCROLL PUSH BUTTON (Option -Q only) SCROLL <> SAVE SETTINGS? Save? When go to end SCROLL PUSH BUTTON FIGURE 2.4 Menu Display and Sequences 2083-1919-02 Manual, Rev. 0 Page 16 04/19/17...

  • Page 17: Environmental Use Information

    G. Top Cover - There are no serviceable parts inside the product so, the Top Cover should not be removed. If the Top Cover is removed the ground strap and associated screw MUST BE REINSTALLED prior to Top Cover screw replacement. FAILURE TO DO this may cause INGRESS and/or EGRESS emission problems. 2083-1919-02 Manual, Rev. 0 Page 17 04/19/17...

  • Page 18: Shiloh Road Alpharetta, Georgia

    ROSS ECHNOLOGIES, INC. 6170 Shiloh Road Alpharetta, Georgia 30005 (770) 886-8005 FAX (770) 886-7964 Toll Free 888-900-5588 WEB www.crosstechnologies.com E-MAIL info@crosstechnologies.com Printed in USA 2083-1919-02 Manual, Rev. 0 Page 18 04/19/17...
