4.4.1 Performing a measurement

Measurements can be performed using rectangular cells of
various path lengths (10, 20, 50 mm / 100 mm Prove 600) and
Spectroquant® round cells. Insert cells as follows to start the
measurement:
Measuring with a round cell with closed lid
2
3
4
1. Insert the barcoded Spectroquant® round cell through the
opening , ensuring that the white position mark
1
cell is aligned with the positioning mark on the spectrophoto-
meter .
3
2. Measurement starts automatically, and the measurement result
is displayed in the concentration measurement overview
(see page 7).
5
18
Measuring with rectangular cells with open lid – insert
AutoSelector
6
2
1
7
3
1. Open the flip-up cover
on the 2. Insert the AutoSelector vertically into the cell compartment
2
ensuring that the white position mark
is aligned with the positioning mark on the spectrophotometer
.
7
3. The photometer is ready to measure.
by pushing it back with your fingers.
4
on the AutoSelector
6
