4 Operation

4.1 Switching the spectrophotometer on or off

Switching on
1
1. Press the ON / OFF button
1
an audible signal (beep) and starts booting for approximately
2 minutes. You will see the following display:
2. After the booting process the screen shows the self-test dialog.
Version 1.1 – 10/2015
. The spectrophotometer gives
Starting the self-test
3. Remove all cells and close the cell compartment cover.
4. Start the self-test with the Start button
5. The spectrophotometer performs the self-test.
Self-test
The self-test covers:
• C hecks on memory, processor, internal interfaces, filter and
lamp
• A calibration of the wavelength
When the self-test has ended, the display shows the main menu.
1
2
2
.
2
3
4
5
13
