Summary of Contents for Cosmo COS-QS75
- Page 1 MODEL: COS-QS MANUAL & INSTALLATION GUIDE This manual is made with 100 % recycled paper. Electronic version of this manual is available at : www.cosmoappliances.com...
- Page 2 Thank You Thank you for your purchase. We know that you have many brands and products to choose from and we are honored to know that you have decided to take one of our products into your home and hope that you enjoy it.
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read all instructions before using this appliance. Save these instructions for future references Approved for residential appliances. For residential use only . Due to the weight and size of these vent hoods and to reduce the risk of personal injury or damage to the product, TWO PEOPLE ARE REQUIRED FOR PROPER INSTALLATION. - Page 4 STAINLESS STEEL BAFFLE FILTERS About Your New Filters Stainless Steel Baffle Filters do not need linings or mesh inside of the filters and are completely constructed out of stainless steel. The stainless steel construction allows them to be used again after being cleaned or going through the dishwasher. How do Baffle Filters Work? They function by forcing the grease filled air to quickly and continuously change direction as it passes through the filter.
-
Page 5: Table Of Contents
TABLE OF CONTENTS PARTS DIAGRAM INSTALLATION REQUIREMENTS INSTALLATION PROCEDURES RECIRCULATING MODE OPERATING INSTRUCTIONS MAINTENANCE TROUBLESHOOTING WARRANTY AND SERVICE... - Page 6 30 INCH MODEL DIMENSIONS COS-QS75...
- Page 7 36 INCH MODEL DIMENSIONS COS-QS90...
- Page 8 48 INCH MODEL DIMENSIONS COS-QS48...
-
Page 9: Parts Diagram
PARTS DIAGRAM MAIN PARTS Mounting Bracket Mounting Bracket Damper Drip Tray Baffle Filters Number of Filters will depend on Model /Size. -
Page 10: Installation Requirements
INSTALLATION REQUIREMENTS WARNING Sufficient air is needed for proper combustion and exhausting of gases through the chimney of fuel burning equipment to prevent back- drafting. Follow the cooking equipment manufacturers guideline and safety standards such as those published by the National Fire Protection Association (NFPA), the American Society for Heating, Refrigeration and Air Conditioning Engineers (ASHRAE), and local code. -
Page 11: Ductwork Planning
PRE INSTALLATION PROCEDURES • Please read the instructions carefully. Unpack the Range Hood and check that all functions are working before installing. • Ensure that the voltage (V) and the frequency (Hz) indicated on the sticker match the voltage and frequency at the installation site. -
Page 12: Installation Procedures
INSTALLATION PROCEDURES CAUTION: HOOD MAY HAVE VERY SHARP EDGES; PLEASE WEAR PROTECTIVE GLOVES WHENEVER IT IS NECESSARY TO REMOVE ANY PARTS FOR INSTALLING, CLEANING OR SERVICING. Duct Step 1: Damper Connect the duct into the damper. Step 2: Clearance above stovetop ranging from 24”... - Page 13 Larger images on Pages 4,5,6 Rear Mounted Installation A. Find the key holes in the back of the range hood. Mark their locations at the installation location with a pencil or marker. B. Drill 5/16" (8mm) hole at each of the marked locations.
-
Page 14: Recirculating Mode
RECIRCULATING FILTERS INSTALLATION Skip this page if you are installing a Ducted Range Hood. Charcoal Filters are only included with Ductless Models Before installing make sure the unit is powered off and unplugged. Carbon Filter Filter Ring AFTER CARBON FILTER INSTALLATION Figure 1 Motor Ring Motor Housing... -
Page 15: Operating Instructions
OPERATING INSTRUCTIONS Soft Touch Controls A. Timer Button - When the range hood fan is running, touch once. The timer has a default setting at 1 minute. Use plus or minus to increase or decrease time duration up to 15 minutes. Set The Time: Press Clock symbol when the range hood fan is not running, the time will light up and blink. -
Page 16: Maintenance
MAINTENANCE CAUTION: NEVER PUT YOUR HAND INSIDE OF THE UNIT WHILE ITS OPERATING FOR THE BEST PERFORMANCE CLEAN YOUR RANGE HOOD REGULARLY CLEANING 1. Use only mild soap or cleaning solutions to clean the range hoods outer surface. Dry surfaces using a soft cloth. 2. -
Page 17: Troubleshooting
TROUBLESHOOTING CAUTION: ALWAYS UNPLUG UNIT FROM POWER BEFORE SERVICING PROBLEM SOLUTION TOOLS My range hood is A. Check inside the range hood Phillips Screwdriver noisy. for any loose debris and remove. A. The range hood and cooktop are My range hood has Phillips Screwdriver too far away from each other. -
Page 18: Warranty And Service
WARRANTY AND SERVICE For full warranty details on this product please visit: http://www.cosmoappliances.com/warranty...
