HPE LSWM124XG2Q (JH181A) &
LSWM124XG2QL (JH180A) Interface
Modules User Guide
Part number: 5998-7150t
▌Introduction
Product code
JH181A
JH180A
Overview
The LSWM124XG2Q and LSWM124XG2QL interface modules are
similar in appearance. Each interface module provides 24 SFP+ ports
and two QSFP+ ports. The SFP+ ports on the LSWM124XG2Q
interface module support MACsec.
HPE description
HPE 5930 24-port SFP+ and
2-port QSFP+ with MACsec
Module
HPE 5930 24-port SFP+ and
2-port QSFP+ Module
1
Alias
LSWM124XG2Q
LSWM124XG2QL
Advertisement
Table of Contents
Related Manuals for HPE LSWM124XG2Q
Summary of Contents for HPE LSWM124XG2Q
- Page 1 HPE 5930 24-port SFP+ and JH180A LSWM124XG2QL 2-port QSFP+ Module Overview The LSWM124XG2Q and LSWM124XG2QL interface modules are similar in appearance. Each interface module provides 24 SFP+ ports and two QSFP+ ports. The SFP+ ports on the LSWM124XG2Q interface module support MACsec.
-
Page 2: Sfp+ Ports
(1) SFP+ port LED (2) QSFP+ port LED (3) QSFP+ port (4) SFP+ port SFP+ ports The SFP+ ports on the LSWM124XG2Q and LSWM124XG2QL interface modules support the following transceiver modules and cables: • SFP transceiver modules in Table 1 Table •... - Page 3 Product Central HPE description Connector code wavelength (nm) HPE X125 1G SFP JD061A LC LH40 1310nm 1310 Transceiver HPE X120 1G SFP JD062A LC LH40 1550nm 1550 Transceiver HPE X125 1G SFP JD063B 1550 LC LH70 Transceiver Table 2 1000 Mbps SFP transceiver modules available for the...
- Page 4 (1) Central Product HPE description waveleng Connector code th (nm) HPE X130 10G SFP+ LC JD092B SR Transceiver HPE k X130 10G SFP+ JD094B 1310 LC LR Transceiver Table 4 10G SFP+ transceiver modules available for the SFP+ ports (2)
-
Page 5: Qsfp+ Ports
10.31 Gbps SFP+ 5m DAC Cable NOTE: As a best practice, use HPE transceiver modules and cables for the SFP+ ports. The available transceiver modules and cables might change over time. For the most recent list of available transceiver modules and cables, contact Hewlett Packard Enterprise Support or marketing staff. - Page 6 Table 6 40G QSFP+ transceiver modules available for the QSFP+ ports (1) Product Central Conne HPE description code wavelength (nm) ctor HPE X140 40G QSFP+ JG325B MPO SR4 Transceiver HPE X140 40G QSFP+ JG709A MPO MM 850nm CSR4 300m Transceiver Four lanes: •...
- Page 7 Table 9 40G QSFP+ to SFP+ cables available for the QSFP+ ports Product Cable HPE description Data rate code length HPE X240 40G QSFP+ to JG329A 4x10G SFP+ 1m Direct 1 m (3.28 ft) 40 Gbps Attach Copper Splitter Cable HPE X240 40G QSFP+ to JG330A 4x10G SFP+ 3m Direct 3 m (9.84 ft)
- Page 8 NOTE: • When you install the interface modules on the HPE FlexFabric 5930 4-Slot Switch (JH179A), HPE FlexFabric 5930 4-Slot TAA Switch (JH188A), and HPE FlexFabric 5940 4-Slot Switch (JH398A) the 40-GE QSFP+ ports on the interface modules cannot be split into four 10-GE SFP+ ports.
-
Page 9: Installing And Removing The Interface Module
The installation and removal procedures are the same for the LSWM124XG2Q and LSWM124XG2QL interface modules. This section uses the LSWM124XG2Q interface module as an example. Installing the interface module Before you install the interface module, remove the filler panel (if any) - Page 10 To install the interface module: 1. Unpack the interface module. Figure 2 LSWM124XG2Q interface module (1) Ejector lever (2) Latch 2. Press the latch on the interface module to release the ejector lever. 3. Insert the interface module slowly into the slot along the guide...
-
Page 11: Removing The Interface Module
Removing the interface module CAUTION: • Before you remove the interface module, remove the cable from it to avoid cable damage. • If you are not to install a new interface module, install a filler panel in the slot to prevent dust and ensure good ventilation in the device. -
Page 12: Verifying The Installation
Support. ▌Documentation To access documentation and support services, go to the Hewlett Packard Enterprise Support Center website: www.hpe.com/support/hpesc 5998-7150t The information in this document is subject to change without notice. © Copyright 2016 Hewlett Packard Enterprise Development LP BOM: 3101A0JA...
