Commax DP-201LA User Manual page 3

3. Operation
1. When the call button( on the door station) is pressed, the chime
sounds.
2. Adjust the volume switch(on the room station) to control the call
sound.
3. Pick up the handset( on the room station) to talk.
4. Press the door release button(on the room station) to open the door.
The door-lock should be instatlled.
5. Place the handset to finish talking.
5. Specification
POWER SOURCE
OUTPUT POWER
DISTANCE
DIMENSION
WEIGHT
DOOR-STATION
220V~, 50Hz High 300mW across 8 ohm
Low 50mW across 8 ohm
100m( Ø 0.65mm), 150m( Ø 0.8mm)
208(D) X 98 (W) X 65(H)mm / Room station.
700g
DR-201D / DR-201H / DR-201A/DR-2R/DR-2L
3
4. Wiring
ROOM STATION
DOOR
STATION
DOOR
LOCK
① Connect two wires of door
station to the ① ② of
room station terminal
② Connect electrical door-lock
to the terminal
⑤ ⑥
as below picture.
③ When finished the connection
put in the power cord at AC
outlet.
