Commax DP2SDR2GN User Manual

Download this manual

User Manual

DOOR PHONE DP-2S

• Thank you for purchasing COMMAX products.

• Please carefully read this User's Guide (in particular, precautions for safety) before using a product and follow

instructions to use a product exactly.

• The company is not responsible for any safety accidents caused by abnormal operation of the product.

Need help?

Do you have a question about the DP2SDR2GN and is the answer not in the manual?

Page 1 User Manual DOOR PHONE DP-2S • Thank you for purchasing COMMAX products. • Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow instructions to use a product exactly. • The company is not responsible for any safety accidents caused by abnormal operation of the product.
Page 2 1. W arnings and Caution 2. Overview Handset To prevent fire or shock hazard, do not expose the unit to rain or moisture. This symbol is intended to alert the use to the “ “ dangerous Voltage” ” presence of uninsulated Call Volume Switch within the product’...
Page 3 5. W iring 4. Installation 1. Non polarity wiring with Sub Unit(1) and Master Unit (2). 2. Door Release(3) should be provided with additional power source. SCREW T4X50 (2EA) 6. Specification Model DP-2S Power Source 100/110/120/220/230/240V~, 50/60Hz Consumption Power 4.5W(MAX) Distance 100m( Ø0.65mm), 150m( Ø0.8mm) Wiring...
Page 4 513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea Int’l Business Dept. : Tel.; +82-31-7393-540~550 Fax.; +82-31-745-2133 Web site : www.commax.com Printed In Korea / 2016.04.105...
