- Page 1 ® 4530 4G PRIMARY ALARM COMMUNICATOR ALARM COMMUNICATOR ALARM COMMUNICATOR ALARM COMMUNICATOR ALARM COMMUNICATOR ALARM COMMUNICATOR ALARM COMMUNICATOR ALARM COMMUNICATOR ALARM COMMUNICATOR ALARM COMMUNICATOR ALARM COMMUNICATOR ALARM COMMUNICATOR INSTALLATION & USER’S GUIDE...
- Page 2 4530 4530 © 2012 Uplink Security LLC. All rights reserved. Uplink is a trademark of Uplink Security LLC. No part of this publication may be reproduced or used in any form without permission in writing from Uplink. This includes electronic or mechanical means, such as photo- copying, recording, or information storage and retrieval systems.
-
Page 3: Table Of Contents
B. DIP Switch Settings ..............12 C. LEDs .....................13-14 D. Locating and Installing the 4530 ...........15-17 E. Connecting the 4530 to the Alarm Panel ........18-19 F. Activating the 4530 ...............20 G. Programming and Central Station Reporting .......21 H. Default Event/Email Messages .............22 I. -
Page 4: Introduction
The Uplink 4530 unit will “intercept” the alarm panel’s digital dialer output when the panel has an event to report, and communicate with the panel as if it were a central station alarm receiver. -
Page 5: Key Features
• Unit Disabled by Dealer Command • Watchdog Circuit Activation E. Power Source Monitoring (Low DC Input Voltage Reporting). The 4530 can report a low input Voltage condition to the central station when its DC input voltage drops below 10.2V DC. It will report Low input Voltage Restoral at 11.4V DC. -
Page 6: Key Features
Uplink Customer Service: 1-888-9-UPLINK (1-888-987-5465) Requires the central station receiver phone number and/or its IP address and Port number. J. Web-based Services. Available at www.uplink.com and include: a. secure login for dealers b. immediate, real-time activation c. history of past event transmissions d. -
Page 7: Limitation Of Liability
Uplink is willing and able to repair or replace a defective Uplink Device as provided above or, at its sole option, to refund the purchase price paid. -
Page 8: Warranty & Limitation Of Liability
PARTICULAR PURPOSE, NON-INFRINGEMENT, INTEROPERABILITY WITH THIRD PARTY SERVICES, SYSTEMS, AND FACILITIES, AND NON-OBSOLESCENCE. THE WARRANTY SET FORTH FURTHERMORE DOES NOT COVER UPLINK DEVICES THAT (A) HAVE BEEN IMPROPERLY INSTALLED, OPERATED, OR SERVICED; (B) HAVE BEEN TAMPERED WITH; OR (C) HAVE BEEN SUBJECTED TO ENVIRONMENTAL EXTREMES. -
Page 9: Warranty & Limitation Of Liability
NEITHER UPLINK NOR ITS THIRD PART SERVICE PROVIDERS SHALL BE LIABLE TO ANY UPLINK DISTRIBUTOR OR RESELLER, ANY INSTALLER, ANY END USER OF AN UPLINK DEVICE OR UPLINK SERVICE, OR ANY OTHER THIRD PARTY FOR ANY CONSEQUENTIAL, INCIDENTAL, INDIRECT, EXEMPLARY, PUNITIVE, OR SPECIAL DAMAGES INCLUDING, WITHOUT LIMITATION, LOST DATA, SALES, REVENUES, OR PROFITS, REGARDLESS OF THE FORESEEABILITY OF SUCH DAMAGES. -
Page 10: Fcc And Regulatory Compliance & Part 15
® 4530 FCC & INDUSTRY CANADA REGULATORY COMPLIANCE Part 15 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 11: Fcc Rf Exposure Information
4G PRIMARY ALARM COMMUNICATOR FCC RF ExPOSURE INFORMATION In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated transmitters. -
Page 12: Technical Support
Before calling technical support please ensure you have read the installation guide completely. Technical support requires the caller to provide: • Login name • Password • Serial number of the 4530 UPLINK Technical Support 3330 Cumberland Blvd. Suite 700 Atlanta, GA 30339 888-9-Uplink (888-987-5465) www.uplink.com... -
Page 13: Installation
S4 and move the unit to a location that gives him the best signal strength.) b. Proximity to the alarm panel and where to route the 4530’s relay output that connects to an alarm panel input. B. DIP Switch Settings The 4530 has a four-position dipswitch. -
Page 14: Leds
® 4530 INSTALLATION (cont.) C. LEDs Normal Mode: Upon initial power up, the 5 LEDs on the 4530 will begin to function as follows: (INSTALLATION continued next page) - Page 15 Font: Arial. Font Size: 6pt. 4G PRIMARY ALARM COMMUNICATOR e for reference only. Do not print INSTALLATION (cont.) ont Size: 8pt. RSSI Mode: When the 4530 is placed in Received Signal Strength Indicator (RSSI) Mode by turning Dipswitch S4 to ON, the five LEDs indicate the follow signal strength information: RECEIVED SIGNAL FLASH STRENGTH...
-
Page 16: Locating And Installing The 4530
INSTALLATION (cont.) D. Locating and Installing the 4530 The 4530 is housed in a plastic enclosure. The installer needs to supply DC power from the panel via the AUX output, or battery, via a separate DC power source. Input DC current is listed on page 23. - Page 17 4G PRIMARY ALARM COMMUNICATOR INSTALLATION (cont.) Led 1 Dip Switches Led 2 Led 3 Radio Daughterboard Led 4 Led 5 Telephone Line Interface Module To Alarm Panel FIGURE 1: Model 4530 PC Board Details (INSTALLATION continued next page)
- Page 18 4530 INSTALLATION (cont.) 5. Position the bottom of the 4530 enclosure where it will be installed. Use four (4) #6 screws and mount the unit using the four holes in the enclosure’s plastic bottom. The 4530’s dimensions are shown in Figure 2.
-
Page 19: Connecting The 4530 To The Alarm Panel
INSTALLATION (cont.) E. Connecting the 4530 to the Alarm Panel IMPORTANT: Make all of the connections to the 4530 in the powered down state. Once all of the connections have been established, turn power on. 1. First, remove DC power from the 4530, and then proceed as follows: 2. - Page 20 ® 4530 INSTALLATION (cont.) FIGURE 3: Connections between the 4530 and the Alarm Panel (INSTALLATION continued next page)
-
Page 21: Activating The 4530
4G PRIMARY ALARM COMMUNICATOR INSTALLATION (cont.) F. Activating the 4530 The 4530 is programmed OTA (Over-the-Air) by accessing the Uplink Dealer website or by calling Uplink Customer Service at 1-888-9UPLINK (1-888-987-5465). New Dealer Enrollment: For new dealers/customers, you must first establish an account with Uplink by visiting the Uplink website (www.uplink.com). -
Page 22: Programming And Central Station Reporting
The normal state of the Output Relay can be changed from the dealer website. 4. Output Relay 1 Mapping (Default = #1 Loss of Cellular Service) There are 6 Trouble states that can be declared by the 4530, and each of these states can be programmed from the dealer website to activate the Output Relay. -
Page 23: Default Event/Email Messages
4530 that can be sent to the central station receiver. See Appendix B for a list of the default event codes transmitted by the 4530. The 4530 supports Pulse 4/2 with any combination of :10, :20, or :40 PPS. Two round or checksum, 1400 Hz or 2300 Hz handshake. -
Page 24: Specifications
® 4530 SPECIFICATIONS DIGITAL DIALER INTERFACE Format Compatibility Contact ID, SIA, Modem IIe/IIIa/IIIa , Pulse 4/2 (:10, :20, or :40 PPS) Connector RJ45 and screw terminals Simulated telco line voltage 48 V DC On-Hook Dial tone 350 + 440 Hz +/- 0.2%... -
Page 25: Specifications
4G PRIMARY ALARM COMMUNICATOR SPECIFICATIONS (cont.) RADIO Frequencies 850/1900 MHz Sensitivity -106 dB (typical) ENvIRONMENTAL Temperature Range -30° to +70° C Humidity 0 to 95% non-condensing PHYSICAL Height 2.5 inches Width 5.4 inches Depth 10.5 inches... - Page 26 CONTACT ID, SIA EvENT, AND MODEM II /III /III CODES Following is a list of event codes that can be sent to the central station receiver for events generated by the 4530: EvENT DESCRIPTION CONTACT ID SIA DC-03 MODEM IIe/ EvENT CODE...
- Page 27 4G PRIMARY ALARM COMMUNICATOR APPENDIx A: CONTACT ID, SIA EvENT, AND MODEM IIe/IIIa/IIIa CODES (cont.) EvENT DESCRIPTION CONTACT ID SIA DC-03 MODEM IIe/ EvENT CODE EvENT CODE IIIa/llla Low Temperature Restoral R159 Medical Alarm E100 Medical Restoral R100 Opening E400 Panic Alarm E120 Panic Restoral...
-
Page 28: Appendix B: 4530 Default Event Codes
4530 APPENDIx B: 4530 DEFAULT EvENT CODES The 4530 is defaulted to send both the Alarm/Trouble condition and the Restoral condition for all of the events listed below. Reporting of individual events can be controlled from the Dealer Website. Following is a list of the default event codes sent by the 4530:... - Page 29 4G PRIMARY ALARM COMMUNICATOR UPLINK 4530 4G PRIMARY ALARM COMMUNICATOR INSTALLATION, OPERATION AND PROGRAMMING GUIDE © 2012 Uplink Security LLC. All rights reserved. Uplink is a trademark of Uplink Security LLC. ® 3330 CUMBERLAND BLVD., SUITE 700, ATLANTA, GA 30339 888-987-5465 (888-9-UPLINK) WWW.UPLINK.COM...
- Page 30 ® FOR SALES, PRODUCT INFORMATION & TECHNICAL SUPPORT Uplink 3330 Cumberland Blvd. Suite 700 Atlanta, GA 30339 1-(888) 9-UPLINK, 1-(888)-987-5465 Fax 1-(888)-542-9105 sales@uplink.com www.uplink.com...
