Pitco TURBOFRY 2000 Specification Sheet

Model TURBOFRY 2000
Gas Continuous Filtration
Convection Fryer
STANDARD OPTIONS AND ACCESSORIES
n
Digital solid state control
n
Four oblong nickel plated baskets
n
Cleaning brush
n
Skimmer
n
Filter removal tool
n
Clean out rod
n
Basket hanger
n
Heavy duty polyurethane casters
n
Stainless steel tank
n
Stainless steel cabinet front and sides.
AVAILABLE OPTIONS & ACCESSORIES
F Solid shortening system F Square baskets (2)
F I12 computer
F Quick 1" x 36" disconnect
F Stainless steel lift off cover
F Front work shelf
F Side work shelf
F Batter coated food baffle
F 2 year extended warranty
Pitco Frialator, Inc., P.O. Box 501, Concord, NH 03302-0501 • 509 Route 3A, Bow, NH 03304, USA
n
Filter bags
n
Flush hose
n
Drain screen
n
Filter scoop
F 1/3 style baskets (6)
(800) 258-3708 • (603) 225-6684 • FAX (603) 225-8472
Project
Item No.
Quantity
STANDARD SPECIFICATIONS
CONSTRUCTION
n
Welded tank with a super smooth machine peened
finish ensures easy cleaning.
n
State of the art digital solid state cooking controller
with integral melt cycle is accurate to ±1 degree.
n
Heavy duty institutional type construction for years of
rugged performance.
n
A high rate power burner to meet the highest production
demands.
n
Special diameter heat tube and heat recuperation
system transfers heat efficiently with low heated
surface temperatures for improved oil life.
n
Rigid tubular steel frame with stainless steel front and
sides. Sides remove easily for cleaning.
n
Splash back and front deck are 14 gauge stainless
steel. Doors are self closing.
n
Continuous filter system is integral to the tank. High
flow filters have large collection capacity and are fast
to change.
CONTROLS
n
Digital controller maintains fryer temperature between
250°F and 380°F.
n
Digital controller provides a visual display and audible
indication of temperature, high oil temperature, probe
failure, cook times, product ready and other events.
Each digital controller product key is fully field
programmable.
n
Front panel mounted gauges provide the operator with
status of the filters and pump operation.
n
Temperature limit automatically shuts off all gas flow
if the fryer temperature exceeds 450°F (232°C) ±15°F
(±10°C).
OPERATIONS
n
Direct spark ignition for easy start-ups.
n
Front 1-1/4" NPT full port drain valve with 11-1/2" floor
clearance for easy draining.
n
Safety interlock on drain valve stops heat and pump
functions if drain is opened.
n
Continuous filter removes excess breading from the
oil.
n
High powered heating system provides low temperature
drop under full load cooking.
n
Flush hose for wash down or shortening disposal.
APPROVALS
n
AGA Certified
n
CGA Certified
n
NSF Listed
* Patent Pending
