Installing Your ShoreTel IP Phone 655 This section shows how to install a ShoreTel IP Phone 655. Instructions are provided for connecting phones with and without the AC power adapter. (This adapter may be necessary for networks that do not support the IEEE 802.3af standard for Power-over- Ethernet).
Page 4
Attach phone to base Connect the wide leg of the base to the larger of the three slots on the back of the phone. Once the wide leg is inserted, rotate the two pillars down onto the smaller tabs and snap into place.
Page 5
Ethernet jack in the workspace (or on a data switch/router that supports Power-over-Ethernet.) Optional Note The USB port on the IP 655 is not Share a single LAN wall jack enabled at this time. between your IP phone and computer by daisy-chaining the PC off the second Ethernet port (purple) on your phone.
Page 6
Connect to power & network (Non-powered Ethernet network requires AC power adapter) Connect the AC power cable between the power adapter and an electrical socket. Upper LED lights green to indicate when phone is Connect the second connected and network cable to the using power.
Page 7
Connect handset For optimal use, attach the shorter end of the handset cable to the handset. Optional Connect a headset to the (blue) connector on phone. Headset not included. Connect the long end of the handset cable to the (green) jack on the phone body.
Important Safety Instructions For IP TELEPHONE, MODEL SHORETEL IP PHONE 655 This symbol is to alert you to important operating or servicing instructions that may appear in this owner’s manual. Always follow basic safety precautions when using this product to reduce the risk of injury, fire, or electric shock.
Audio Control Pads Dial Pad Volume sets handset, speaker, and Delivers high-quality ring volume. Mute and Headset wideband sound. Speaker keys illuminate when functions are active. Note: Access the latest user guide for this phone by downloading a PDF from www.shoretel.com/phoneguides.
Warranty and Limitation of Liability Refer to www.shoretel.com/about/warranty.html for details on ShoreTel’s warranty policy. Safety and Regulatory Information This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
