Summary of Contents for ShoreTel 565g
- Page 1 ® ShoreTel 565g IP Phone Quick Install Guide & Warranty...
-
Page 2: Document And Software Copyrights
ShoreTel, Inc. ShoreTel, Inc. reserves the right to make changes without notice to the specifications and materials contained herein and shall not be responsible for any damage (including consequential) caused by reliance on the materials presented, including, but not limited to, typographical, arithmetic, or listing errors. -
Page 3: Package Contents
Installing Your ShoreTel 565g IP Phone This section shows how to install a ShoreTel 565g IP Phone. Instructions are provided for connecting phones with and without the AC power adapter. (This adapter may be necessary for networks that do not support the IEEE 802.3af standard for Power-over- Ethernet). - Page 4 Attach phone to base Connect the base to the larger of the Rotate the two pillars down onto the three tabs on the back of the phone. smaller tabs and snap into place.
- Page 5 Connect to powered network (no AC adapter required) If the LAN to which this phone will be connected supports power-over-Ethernet, no AC adapter is needed. The phone draws power from the Ethernet network. Connect the network cable between the LAN port on the back of the phone and an Ethernet jack in the workspace (or on a...
- Page 6 Connect to power & network (Non-powered Ethernet network requires AC power adapter) Connect the second network Connect the AC power cable cable to the DATA IN port** between the on the adapter and an Ethernet jack in the adapter and an electrical socket.
- Page 7 Wireless Headset Support: Wireless Headset Support: Bluetooth Electronic Lifter The 565g IP phone supports various The 565g IP phone has an internal Bluetooth wireless headsets. Please electronic handset lifter, allowing some contact your ShoreTel representative wireless headsets to be used without a for the latest list of supported models.
-
Page 8: Choosing Bluetooth Headsets For The Ip 565G Phone
Because of the inherent environmental inconsistencies in the locations in which the IP 565g may be deployed, there is no one best headset solution that is optimal for all environments. ShoreTel recommends that customers test the headsets that work best in their environment before deploying a large number of units in their network. -
Page 9: Important Safety Instructions
Important Safety Instructions For IP TELEPHONE, MODELS 110, 115, 212k, 230, 265, 560, 560g, 565g and BB24 This symbol is to alert you to important operating or servicing instructions that may appear in this owner’ s manual. Always follow basic safety precautions when using this product to reduce the risk of injury, fire, or electric shock. -
Page 10: Features And Functions
(if auto off- hook preference is set to Bluetooth). The headset key lights green when phone is used with a standard headset. Note: You can access the latest user guide for this phone by dowloading a PDF from the following URL: www.shoretel.com/phoneguides... -
Page 11: Warranty And Limitation Of Liability
ShoreTel or its authorized reseller. ShoreTel's sole obligation under this express warranty shall be, at ShoreTel's option and expense, to repair... - Page 12 In accordance with part 15 of the FCC rules, the user is cautioned that any changes or modifications not expressly approved by ShoreTel, Inc. could void the user's authority to operate this equipment.
- Page 13 ShoreTel, Inc. ShoreTel® and the logo design are registered trademarks and ShoreTel® IP is a trademark of ShoreTel, Inc. in the United States, and various countries.
