010COV.book Page 1 Thursday, July 2, 2015 2:07 PM
Digital Media
Player
Owner's Record
The model and serial numbers are located on the bottom of the unit.
Record the serial number in the space provided below.
Refer to these numbers whenever you call upon your Sony dealer
regarding this product.
Model No. RSX-GS9
Serial No.
For the connection/installation, see page 33.
Pour le raccordement/l'installation, reportez-vous à la page 00.
RSX-GS9
masterpage: Cover
4-577-101-11(1)
Operating Instructions
Mode d'emploi
RSX-GS9
4-577-101-11(1)
GB
FR
