Summary of Contents for Dahua DH-TPC-PT8320C
- Page 1 Thermal Tribrid PTZ Camera Quick Start Guide Version 1.0.0...
-
Page 2: Table Of Contents
Table of Contents ACCESSORY LIST ..................... 1 DEVICE STRUCTURE ..................2 Structure Components .......................... 2 Device Dimension ..........................3 PTZ INSTALLATION ................... 5 Installation Preparation ......................... 5 3.1.1 Check installation space and intension ..................5 3.1.2 About cable ............................5 Installation Steps ........................... - Page 3 Welcome Thank you for purchasing our thermal tribrid dome! Please read the following safeguards and warnings carefully before you install or use the product!
-
Page 4: Important Safeguards And Warnings
Important Safeguards and Warnings Safety Measures 1. Qualified Engineer Needed The installation engineer or maintenance engineer shall have corresponding CCTV system installation certificate or maintenance qualification certificate. The installation engineer or maintenance engineer shall have qualification certificate for work at height. - Page 5 Note: It is to alert you there is an optional risk of damage or property loss! Warning Be sure to use all the accessories (such as power adapter) recommended by manufacturer. Do not connect several thermal tribrid domes to one power adapter. It may result in overheat or fire if it exceeds the rated load.
- Page 6 Note Safety Transportation Heavy stress, violent vibration or water splash are not allowed during transportation, storage and installation. This series product must use split type package during the transportation. We are not liable for any damage or problem resulting from the integrated package during the transportation.
-
Page 7: Accessory List
1 Accessory List Please check if there is any obvious damage to the device appearance when opening the external packing box, besides, you need to confirm if the accessories are in accordance with the ones on the list. Please refer to sheet 1-1 for the accessories; please be aware that the actual config is based on the specific product. -
Page 8: Device Structure
2 Device Structure 2.1 Structure Components The device structure components are shown in Figure 2-1. Note: The following figures are for reference only, which are only used to know each structure component and cable port function. Slight difference may exist between different device structure components and cables, please refer to the actual device for more details. -
Page 9: Device Dimension
SN Port Port Name Connector Note Alarm IN1 Alarm input port; it is to receive （green） Alarm input the on-off signal of external Alarm IN2 alarm source. Various external alarm （blue） devices, such as smoke Alarm OUT detector etc. NO（pink） Alarm output port, it is to output Alarm output alarm signal to alarm device. - Page 10 Figure 2-3 Figure 2-4...
-
Page 11: Ptz Installation
3 PTZ INSTALLATION 3.1 Installation Preparation 3.1.1 Check installation space and intension Please make sure the installation environment has enough space to install the PTZ and its corresponding bracket. Please make sure the ceiling, wall and the bracket can support the total weight of PTZ and its corresponding installation component. -
Page 12: Step 8
It needs more than 3 people to install the device, pay attention to protect the lens during installation. It is not allowed to power on the device before fixing the device on the installation desktop, otherwise, the device may fall over and cause damage to the upper component especially the lens during power on self test of the device. - Page 13 The “Front” logo is printed on the side of the PTZ (shown in Figure 3-1 ①), pay attention not to install in a wrong direction, make sure the arrow direction is in accordance with the indication direction. Step 5 Connect the PTZ aviation plug to the corresponding location of the aviation port of the housing and tighten the aviation plug firmly.
-
Page 14: Network Configuration
4 Network Configuration 4.1 Modify IP Address IP address can be acquired and modified through quick configuration tool for the thermal tribrid dome (the default IP address is: 192.168.1.108), please refer to the << Quick Configuration Tool Operation Manual>> for more details. Users can modify device IP via this method when they forget the device IP. -
Page 15: Login Web Interface
Modify the camera IP address on the “Net” interface, click “Save” to finish modification. See Figure 4-2 for more details. Figure 4-2 4.2 Login WEB Interface Note: Different devices may have different WEB interfaces, the figures below are just for reference, please refer to the <<WEB Operation Manual>>... - Page 16 Figure 4-3 Step 3 Install controls according to the system prompt; see Figure 3-4 for the WEB main interface. Please modify the administrator password as soon as possible after you successfully logged in. Figure 4-4...
-
Page 17: Appendix Ⅰ Lightening Protection And Surge Protection
5 APPENDIX Ⅰ LIGHTENING PROTECTION AND SURGE PROTECTION This series thermal tribrid dome adopts TVS lighting protection technology. It can effectively prevent damages from various pulse signals below 6000W, such as sudden lighting and surge. While maintaining your local electrical safety code, you still need to take necessary precaution measures when installing the thermal tribrid dome in the outdoor environment. -
Page 18: Appendix ǁ Problems And Solutions
6 APPENDIX ǁ PROBLEMS AND SOLUTIONS SYMPTOM CAUSE SOLUTION 1) No self-diagnosis, Red LED is not on. Check power is connected or no video signal Your power supplying does properly earthed. when I connect PTZ not apply to the power. Or Check power supply condition to power.
