Phoenix BIOS Setup

Use the Phoenix BIOS Setup program for:
Setting system time and date.
Installing new drives for hard disks and floppy disks.
Enhancing system performance by controlling advanced features such as shadow memory and cache
memory.
To start the Phoenix BIOS Setup utility:
1. Turn on or reboot your system.
2. Press the ESC key when ReVolution splash screen appears.
3. PhoenixBIOS displays this message: Press <F2> to enter SETUP
4. Pressing <F2> displays the Main Menu.
Incorrect settings can cause your system to malfunction.

Navigating the Setup Menus

The Menu Bar at the top of the window lists these selections:
Main Use this menu for basic system configuration.
Advanced Use this menu to set the Advanced Features available on your system's chipset.
Security Use this menu to set User and Supervisor Passwords and the Backup and Virus-Check reminders.
Power Use this menu to configure Power-Management features.
Exit Exits the current menu.
Use the left/right arrow keys to make a selection.

Legend Bar

Use the keys listed in the legend bar on the bottom of the screen to make your selections or exit the current menu.
The chart on the following page describes the legend keys and their alternates:
Key Function
<F1> or <Alt-H>
<Esc>
Left or right arrow keys
Up or down arrow keys
<Tab> or <Shift-Tab>
<Home> or <End>
<PgUp> or <PgDn>
<F5> or <->
<F6> or <+> or <Space>
<F9>
<F10>
<Enter>
<Alt-R>
To select an item:
Use the arrow keys to move the cursor to the field you want.
Use the plus-and-minus value keys to select a value for that field. The Save Values commands in the Exit Menu
save the values currently displayed in all the menus.
To display a sub menu:
Use the arrow keys to move the cursor to the sub menu you want.
Press <Enter>. A pointer (_) marks all sub menus.
58
General Help window (See below).
Exit this menu.
Select a different menu.
Move cursor up and down.
Cycle cursor up and down.
Move cursor to top or bottom of window.
Move cursor to next or previous page.
Select the Previous Value for the field.
Select the Next Value for the field.
Load the Default Configuration values for this menu.
Load the Previous Configuration values for this menu.
Execute Command or Select P Submenu.
Refresh screen.
