Summary of Contents for Kontron NotePAC Semi P470
-
Page 2: Table Of Contents
Table of Contents Operating Instructions............... 1 Getting Started ..................1 Unpacking...................2 Taking a Look at the Office Docking ..........3 Rear Components ..............3 Front Components..............4 Connecting/Disconnecting the Office Docking to/from the Computer................5 Connecting ................5 Disconnecting...............7 Caring for the Office Docking ............9 Specifications..................10... -
Page 3: Operating Instructions
Operating Instructions Getting Started Congratulations on purchasing this office docking for your P470 rugged computer. By connecting your peripheral devices to the office docking, you can save yourself the trouble of having to connect and disconnect several cables every time you transport the computer. On this manual you will find the following helpful information: Package contents Brief introduction to the external components of the office docking... -
Page 4: Unpacking
Unpacking After unpacking the shipping carton, you should find these standard items: Office Docking This User Manual Inspect all the items. If any item is damaged or missing, notify your dealer immediately. Keep the shipping carton and packing materials in case you need to ship or store the office docking in the future. -
Page 5: Taking A Look At The Office Docking
Taking a Look at the Office Docking This section identifies the external components of the office docking. NOTE: Depending on the model you purchased, the appearance of your office docking may not be exactly the same as those shown in this manual. Rear Components USB Ports Parallel Connector... -
Page 6: Front Components
Top Components Power Indicator Expansion Bus Connector For the functions of ports and connectors, see chapter 1 of the P470 User’s Manual. CAUTION: DO NOT touch the expansion bus connector and ports of the office docking. NOTE: When you want to use the two serial ports on the office docking, make sure the two items Serial Port COM1 and Serial Port COM2 are enabled under the Advanced menu of the computer’s BIOS Setup program. -
Page 7: Connecting/Disconnecting The Office Docking To/From The Computer
Connecting/Disconnecting the Office Docking to/from the Computer CAUTION: Use only the AC adapter included with your computer. Using other AC adapters may damage the computer. Connecting CAUTION: DO NOT connect the office docking while the computer is powered on or in the Sleep or Hibernation mode. - Page 8 CAUTION: When you disconnect the AC adapter, disconnect from the electrical outlet first and then from the office docking. A reverse procedure may damage the AC adapter or the office docking. When unplugging the connector, always hold the plug head. Never pull on the cord. NOTE: Be sure to use the AC adapter.
-
Page 9: Disconnecting
6. Align the rear corners of the computer with the office docking ( ) and gently place the computer on top of the office docking ( ), making sure to align both the expansion bus connector of the computer and the office docking. CAUTION: DO NOT attempt to make connections if there is any object between the computer and the office docking. - Page 10 3. Close the expansion bus connector cover of the computer.
-
Page 11: Caring For The Office Docking
Caring for the Office Docking Taking good care of your office docking will ensure a trouble-free operation and reduce the risk of damage to both your computer and office docking. DO NOT place metal objects or containers of liquid on top of the office docking. -
Page 12: Specifications
DO NOT leave the office docking in the vehicle under extreme temperatures for a long period of time. The heat may damage the external plastic parts and some internal parts inside the office docking. Continuing to use the office docking under such a condition may cause a short circuit or insulation malfunction, etc, which may result in a fire or electric shock.
