This manual provides detailed instructions, warnings and other information for individuals using Bullard Free-Air Pump
models EDP30 and EDP50
General Information
Bullard Free-Air Pumps transfer ambient air from a clean air location,
where breathable air can be assured at all times, to workers wearing
Type C or CE continuous flow supplied air respirator hoods or tight
fitting half- or full-face masks.
The ambient air is filtered through a medium efficiency inlet filter and
a CARBOFINE Outlet Filter before entering the respirator's air supply
hose.
Bullard Free-Air Pumps are oil-less and have rotary carbon vanes.
EDP30
They produce no carbon monoxide, oil vapors, oil mist or moisture.
They do not require expensive carbon monoxide monitors, high
temperature alarms or airline filters. No calibration is required.
Read all instructions before using your Free-Air pump.
EDP50
Operating the Free-Air Pump ................................................. 6-7
Maintaining the Free-Air Pump ..................................................8
Trouble Shooting Guide ................................................................9
Replacement Parts and Accessories ........................................10
Warranty ..........................................................................................11
Return Policy and Return Authorizations ............................. 11
Air Filter Replacement Schedule ............................................. 12
www.bullard.com
Free-Air® Pumps
User Manual
Distributed By:
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Bullard EDP30
Summary of Contents for Bullard EDP30
-
Page 1: Table Of Contents
Return Policy and Return Authorizations ......11 Electric Motor Specifications ..............5 Air Filter Replacement Schedule ..........12 Pump Performance Specifications ............5 This manual provides detailed instructions, warnings and other information for individuals using Bullard Free-Air Pump models EDP30 and EDP50 www.bullard.com... -
Page 2: Warnings
2. This pump will supply the required volume of air (6-15 cfm for hoods or 4-15 cfm for tight fitting mask) to low pressure supplied air respirators. The respirators must be approved by MSHA/NIOSH to operate at 30 psig or less if using an EDP30 pump, or 15 psig or less if using an EDP50 pump. -
Page 3: Number Of Respirators That Can Be Used With Pumps
The Respirator’s Minimum Approved right hand column. Pressure must be 30 psig or less if using Model EDP30 or 15 psig or less if using Model EDP50. PUMP PERFORMANCE TABlES... -
Page 4: Air Quality
The only assembly required on an EDP30 or EDP50 Pump is to attach pod (See Figure 4). the air supply hose quick-disconnect pod(s) to the pump’s manifold. -
Page 5: Electric Motor Specifications
Free-Air® Pumps User Manual Electric Motor Specifications: EDP30 and EDP50 Open, Drip-proof ENClOSURE: Natl. Elec. Code: Class B ClASS: Design L Code K H.P. Five PHASE: Single CYClES: 208-230 volts as shipped, with 8 foot cord and three WIRING: wire, 30 amp plug (NEMA L6-30) and manual starter F.l. -
Page 6: Operating The Free-Air Pump
If you have any question as to whether or not your respirator is range. compatible with the pump, call the respirator manufacturer or Bullard’s Customer Service Department at 877-BULLARD or The pump has three pressure adjustment locations: 1-859-234-6616. - Pressure relief valve on the pod(s) - Pressure relief valve on the manifold 5. - Page 7 EDP30 Free-Air Pump. knobs and retightening the lock nut(s) to prevent air from The FRIGITRON 2000 and EDP30 pump will supply two (2) people bleeding at the pod(s). working in hot or humid areas with a continuous flow of cool air. The...
-
Page 8: Maintaining The Free-Air Pump
Avoid Running the Pump at Excessive Pressure gaskets on the filter cartridge Avoid running the pump model EDP30 above 30 psig or the EDP50 above plate for wear, cracks or tears 15 psig for any length of time. Running the pumps above the maximum (Figure 14). -
Page 9: Troubleshooting Guide
4. Check that both the inlet filters (Cat. No. 23611) and outlet filter 2. If using an EDP30 and Bullard supplied air respirator hoods, order cartridges (Cat. No. S17101) are clean. Replace if necessary. Dirty the FRIGITRON 2000 Air Conditioner. Two hoods with FRIGITRON filters will restrict air flow. -
Page 10: Replacement Parts And Accessories
Replacement Parts and Accessories Replacement Parts list Optional Accessory Items FOR BOTH EDP30 AND EDP50 FREE-AIR PUMPS ® Cat. No. Description Cat. No. Description 23611 Inlet Filter 26781 Remote pod, EDP30 (Includes six quick-disconnect 26701 Gasket, Pod, Filter Side couplers, pressure gauge, pressure relief valve and... -
Page 11: Warranty
Laws and/or regula- In no event shall Bullard be responsible for damages for loss of use tions prohibit the shipment of hazardous or contaminated or other indirect, incidental, consequential or special costs, expenses materials. -
Page 12: Air Filter Replacement Schedule
701, Sims Drive, #04-03 certified Toll-free within USA: 877-BULLARD (285-5273) Tel: +49-2642 999980 Singapore 387383 ©2014 Bullard. All rights reserved. Tel: +1-859-234-6616 Fax: +49-2642 9999829 Tel: +65-6745-0556 Free-Air is a registered trademark of Bullard. Fax: +1-859-234-8987 Fax: +65-6745-5176 www.bullard.com 6095000710C (1214)
