6-PERSON ROUND
PICNIC TABLE
MODEL #2129
ASSEMBLY INSTRUCTIONS AND OWNER'S
MANUAL
Save this instruction in the event that the manufacturer
has to be contacted for replacement parts.
WARNING
To ensure your safety, do not
attempt to assemble the table
without reading and following
all instructions and warnings
carefully.
INSTRUCTION #1017715
11/03/2006
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Lifetime 2129
Summary of Contents for Lifetime 2129
- Page 1 ® VISIT THE LIFETIME WEB SITE: WWW.LIFETIME.COM 6-PERSON ROUND PICNIC TABLE MODEL #2129 ASSEMBLY INSTRUCTIONS AND OWNER’S MANUAL Save this instruction in the event that the manufacturer has to be contacted for replacement parts. WARNING To ensure your safety, do not...
-
Page 2: Before Beginning Assembly
BEFORE BEGINNING ASSEMBLY A. Identify and inventory all parts using the checklist boxes on the Parts List. SAFETY INSTRUCTIONS FAILURE TO FOLLOW THESE SAFETy INSTRUCTIONS MAy RESULT IN SERIOUS INjURy OR PROPERTy DAMAgE. • Proper and complete assembly and use is essential for proper operation and to reduce the risk of injury. •... -
Page 3: Assemble Legs
Footcaps on Table Legs Step 1 Hardware Turn a Table Leg (AC) upside down. Place a Footcap (AH) on RE (1) the bottom of each leg. Secure the each Footcap with two () #8 x 1/2” Screws (RE). Repeat for remaining two legs. Hardware Bag: Screwdriver 1020883... - Page 4 Note: The Center Leg Braces are joined together always in a Right over Left format. While standing between two legs, line up the end hole on the right brace with the middle hole on the left brace as shown. Secure with one (1) #8 x 1/2” Pan Head Screw (RE). Note: Do not completely tighten the Screws (RE) yet.
- Page 5 Step 3 Hardware 3 Support Braces to Table Top RA (1) Two sets of three () Support Braces (AK & AL) come with your picnic table. Set AK comes with two bolts next to each other (one of the bolts is Hardware Bag: Screwdriver gold colored).
- Page 6 Step 3 Hardware Place a Support Brace (AL) over Support Brace (AK) and lightly secure the Brace to the Table Top with one (1) 1/4” x 1/2” Screw (RA). RA () Note: Do not completely tighten the Screw (RA) yet. Hardware Bag: Screwdriver Pilot Hole...
- Page 7 Step 3 Hardware Note: Do not completely tighten the Screw (RA) yet. RA () Hardware Bag: Screwdriver 1020883 Pilot Hole Underside of Table Note: Do not completely tighten the Screw (RA) yet. Pilot Hole Underside of Table...
- Page 8 Step 3 Hardware Remove the first 1/4” x 1/2” Screw (RA) and gently tilt the Support RA (1) Brace (AK) and slide the last Support Brace (AL) into place. Replace the first 1/4” x 1/2” Screw (RA) into the first Support Brace (AK). Finally, secure the last Support Brace (AL) to the Table Top.
- Page 9 Legs to Support Braces Step 4 Hardware With the Table Top facing top down on the ground, align the Leg RC (9) assembly (Step 2) over the three sets of bolts on the Support Brace assembly. Fasten the Leg assembly to the Support Braces using nine (9) 5mm Cap Nuts (AC).
- Page 10 Lay a Bench Frame (AF) top-side down, with curved Step 5 Hardware edges pointing away from you. BB () RA (1) BA () Hardware Bags: Screwdriver 1020884 Adjustable Wrench Line up a bench leg with the right side of the Bench Frame (AF). Secure to frame with four () 5mm x 12.5mm Carriage Bolts (BA) and four () M5 Centerlock Nuts (BB).
- Page 11 Lay a Bench (AB) top-side down, with curved side pointing away from you. Lay Bench Frame inside the Bench and line up holes. Repeat for all three benches. Fasten the Bench Frame to the Bench with six () 1/4” x 1/2” Screws (RA). Note: Ensure that the holes line-up with the pilot holes in the Bench.
- Page 12 Insert a Cotter Key (BD) through the two holes in the leg of the bench to help prevent the bench from pulling out of the Table Leg. Insert Umbrella Hole Plug If the Umbrella Hole Plug is not already installed, snap it into the hole at the center of the table.
- Page 13 PICNIC TABLE CARE INSTRUCTIONS Congratulations on your Lifetime purchase. By following the instructions below, your new Lifetime table should provide you with years of service and enjoyment. Cleaning and Care The polyethylene tabletop and benches are stain- and solvent-resistant. To clean, use a mild soap and a soft- bristled brush.
- Page 14 This warranty is nontransferable and is expressly limited to the repair or replacement of defective product. If the product is defective within the terms of this warranty, Lifetime Products, Inc. will repair or replace defective parts at no cost to the purchaser. Shipping charges to and from the factory are not covered and are the responsibility of the purchaser.
