ASSEMBLY INSTRUCTIONS
RICHMOND DESK
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE OR
USE YOUR RICHMOND DESK
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
HEALTH & SAFETY:
DO NOT use this desk if any parts are missing, damaged or worn
DO NOT use this desk unless all fixings are secured
Always use on a level, even surface
CARE & MAINTENANCE:
Assemble on a soft, clean surface to prevent damages
Periodically check all screws & fixings to ensure they are secure
DO NOT push the desk as this will damage the feet
Always lift the desk with two people to reposition
Keep any sharp objects away from the desk
www.birlea.com
Page 1 of 9
