Diagnostics and Troubleshooting
User Manual
3.3

LED display

The RLXIB-IHN front panel includes a set of LEDs that indicate the radio's status:
LED
Power
RF Transmit
RF Receive
Serial
Ethernet
Signal Strength
If a radio is configured as a master, the middle light of the three Signal Strength
LEDs will always be on, and the bottom Signal Strength LED will always be off.
The top LED on the master will flash if any radios are linked to this master.
After you first plug in the power cable and Ethernet cable to the radio, the
Power/Status LED should be green, meaning that the radio has power. If the
Ethernet LED is green, then the Ethernet connection is working. The RF Transmit
and RF Receive LEDs should blink.
All three LEDs will blink just after the radio links to the Master's signal but before
it has been fully authenticated. Normally you will see this last only a few seconds.
If it blinks longer, or never turns on, it usually means the encryption keys are not
correct.
Page 44 of 171
Description
This green LED indicates that the radio has power.
This yellow LED indicates RF transmission.
This green LED indicates RF reception.
Reserved for future use.
If this green LED is on, the Ethernet cable is connected. If this LED is flashing,
an Ethernet packet is being transmitted or received.
If only one of these three LEDs is on, then the radio is linked. If two LEDs are on,
the radio's signal strength is fair. If all three LEDs are on, the signal strength is
good.
