Cables

Cable Types
Cable Length
Measurement

Wireless Antennas

Internal Wireless Antennas
External Omni-directional Antenna*
External Directional Antenna*
External Antenna Connector*
*External Antenna port is receive-only (no transmit).
100 Ω Unshielded Twisted Pair (UTP) LAN cables.
100 Ω Shielded or Screened Twisted Pair (SeTP) LAN cables.
TIA Category 3, 4, 5, 5e, and 6. ISO Class C, D and E).
Measurable cable lengths are from 3 feet (0.9 meters) to 500 feet (152
meters).
Accuracy: ± 6 feet (± 2 meters).
Length measurement is based on Nominal Velocity of Propagation (NVP)
for selected cable type.
Seven internal 2.4 GHz, 1.1 dBi peak, 5 GHz,
3.2 dBi peak antennas.
Antenna, WLAN, omnidirectional, 2.4 & 5 GHz,
802.11 A/B/G, 50 Ω. Gain: 2.1 dBi (2.45 GHz),
2.4 dBi (4.9 GHz), 2.6 dBi (5.25 GHz), 2.5 dBi
(5.875 GHz).
Antenna, frequency range 2.4 - 2.5 and 4.9 -
5.9 GHz.
Minimum gain 5.0 dBi peak in the 2.4 GHz
band, and 7.0 dBi peak in the 5 GHz band.
Reverse SMA
Specifications
