OptiView XG Network Analysis Tablet
Getting Started Guide
USB Port
Link Speed and Utilization Indicators
USB Port, see page 35.
Network Ports A, B, C, and D; see page 18.
External Antenna Connector, see page 35.
Link Speed Indicator, see page 19.
Link Utilization Indicator, see page 19.
Wi-Fi Indicators, see page 24.
10
Port A
Port B
Port C
<View of network connectors>
Figure 5. Top View
Port D
External Antenna Connector
Fans
Wi-Fi Status Indicators
GLZ02.EPS
