- Page 1 User Manual Q-Tee II USA / Q-Tee II C USA US English U S E R M A N U A L / M A N U A L D ’ U T I L I S AT I O N...
- Page 2 FIRE ENVIRONMENTALLY FRIENDLY! 5 Eco-friendly advices for sensible heating - common sense both environmentally and economically. 1. Effective lighting. Use small pieces of wood (fir tree) and a suitable fire lighter, for example paraffined wood wool/saw- dust. Open the air damper, so plenty of air is fed to the stove and the gases from the heated wood can burn rapidly.
-
Page 3: Table Of Contents
NAME TAG Q-Tee II USA........ -
Page 4: Introduction
Congratulations on the purchase of your new RAIS woodburning stove. A RAIS woodburning stove is more than just a source of heat, it is a symbol of the emphasis you put on decorating your home with superiorly designed high-quality prod- ucts. -
Page 5: Specifications
User Manual Q-Tee II USA / Q-Tee II C USA US English U.S. ENVIRONMENTAL PROTECTION AGENCY Certified to comply with 2020 par- ticulate emission standards using crib wood. 0.9 g/hr, Method 28R This wood heater needs periodic inspection and repair for proper operation. It is against federal regulations to operate this wood heater in a manner inconsistent with operat- ing instructions in this manual. -
Page 6: Convection
Glass and replacement of glass. All RAIS stoves supplied with Robax® glass in the door. Robax® glass is a ceramic glass type suitable for stoves. The glass is installed from RAIS as an integral part of the door and stove. -
Page 7: Chimney
US English Chimney RAIS stoves must be installed using a Class A UL 103 HT approved factory-built chimney system or a code-approved masonry chimney with a flue liner. In Canada, the appliance must be connected to a factory-built chimney conforming to CAN/ULC-S629. -
Page 8: Chimney
User Manual Q-Tee II USA User Manual Q-Tee II USA / Q-Tee II C USA / US English Required Installation Components: A. Chimney Cap B. Insulated Chimney C. Storm Collar D. Roof Flashing E. Ceiling Support Box or Joist Shield/Firestop Spacer F. -
Page 9: Installation
Do not use grates, andirons, or other fuel support methods. Build fire directly on hearth. Installation WITH or WITHOUT pedestal. An optional pedestal base is available for use with the Q-Tee II USA (838040590 High socket complete) and the Q-Tee II C USA (834051090 ) Warning: Floor protection requirements specified in this manual are different de-... - Page 10 User Manual Q-Tee II USA User Manual Q-Tee II USA / Q-Tee II C USA / US English When installed WITH optional base The floor protection plate must lie under the stove and extend 16” (11cm) (18” (45cm) in Canada) in front of the stove door, 8” (20cm) beyond the sides of the fuel-loading door, and under the pipe and 2”...
- Page 11 User Manual Q-Tee II USA / Q-Tee II C USA US English...
-
Page 12: Name Tag Q-Tee Ii Usa
** Non testé - NFPA Guidelines au USA, CAN/CSA B365-M91 au Canada Replace glass with only Rais authorized dealer supplied ceramic glass La protection de sol doit être au moins de 3/8 inch matériel non combustible placé sous le foyer s'étendant vers l'avant, les côtés les ouvertures et l'arriére comme induqué. -
Page 14: Clearances To Combustible Walls Q-Tee Ii Usa
User Manual Q-Tee II USA User Manual Q-Tee II USA / Q-Tee II C USA / US English Q-Tee II USA Clearance to combustible walls To find out whether the wall by which the stove is to be placed is combustible or not, please contact your architect or the local building authorities. - Page 15 User Manual Q-Tee II USA / Q-Tee II C USA US English **Rear/Top vent option Please refer to NFPA guidelines in Ceiling USA and CAN/CSA B365-M91 in Canada. See further floor prote Évent arrière Avec piédestal Avec piédestal Sans piédestal 14"/356mm...
-
Page 16: Clearances To Non-Combustible Walls Q-Tee Ii Usa
User Manual Q-Tee II USA User Manual Q-Tee II USA / Q-Tee II C USA / US English Clearance to non-combustible wall We recommend a minimum clearance to non-combustible material of at least 2” (50 mm) so that cleaning is easy. The cleaning door of the chimney should be accessible at all times. -
Page 17: Name Tag Q-Tee Ii C Usa
User Manual Q-Tee II USA / Q-Tee II C USA US English Q-Tee II C USA... -
Page 18: Clearances To Combustible Walls Q-Tee Ii C Usa
User Manual Q-Tee II USA User Manual Q-Tee II USA / Q-Tee II C USA / US English Q-Tee II C Clearance to combustible walls To find out whether the wall by which the stove is to be placed is combustible or not, please contact your architect or the local building authorities. - Page 19 Année N° de série User Manual Q-Tee II USA / Q-Tee II C USA US English **Rear/Top vent option Please refer to NFPA guidelines in USA and CAN/CSA B365-M91 in Ceiling Canada. 8" 8" See further floor prot Évent arrière Avec piédestal Avec piédestal Sans piédestal...
-
Page 20: Clearances To Non-Combustible Walls Q-Tee Ii C Usa
User Manual Q-Tee II USA User Manual Q-Tee II USA / Q-Tee II C USA / US English Clearance to non-combustible wall We recommend a minimum clearance to non-combustible material of at least 2” (50 mm) so that cleaning is easy. The cleaning door of the chimney should be accessible at all times. -
Page 21: Firewood
User Manual Q-Tee II USA / Q-Tee II C USA US English Firewood Only burn wood that has been seasoned for at least one full year (two years is better). If the wood has not been seasoned or dried, energy will be lost in evaporating the wa- ter held in the wood. -
Page 22: Adjusting The Combustion Air
US English Adjusting the combustion air All RAIS stoves are equipped with an easy-to-use handle for adjusting the air control. For the various positions of the control please see the following illustrations. To ensure proper combustion process it is very important to supply the correct quantity of air at the right time and place. -
Page 23: Using The Stove
User Manual Q-Tee II USA / Q-Tee II C USA US English REMEMBER THE STOVE IS HOT WHILE IN OPERATION, SO KEEP CHILDREN, CLOTING, AND FURNITURE AWAY. CONTACT WITH A STOVE WHEN BURNING MAY CAUSE SKIN BURNS. Warning: Do not fire the stove with the door open! Using the stove Only use wood as fuel as described in the firewood section of this manual. -
Page 24: Control
First Fire Your new RAIS should be broken into gently for top performance and to prevent paint damage, cracks in the firebrick, and excessive wear and tear. Start with a small fire (never overload the firebox) to allow the materials to get accustomed to the higher temperatures, and then gradually increase the intensity. -
Page 25: Lighting And Stoking
User Manual Q-Tee II USA / Q-Tee II C USA US English Lighting and Stoking To light the stove, use alcohol briquettes or simi- lar, as well as approx. 2 kg of firewood, split into kindling sticks. Set the air damper to the fully open position. - Page 26 User Manual Q-Tee II USA User Manual Q-Tee II USA / Q-Tee II C USA / US English When the flames are clear - after approx. 5-10 min. - close the door. After approx. 10-20 min. - when you have a good bed of glowing embers - add 2-3 pieces of wood.
-
Page 27: Fuel Caution
Never use gasoline, gasoline-type lantern fuel, kerosene, charcoal lighter fluid, naphtha, engine oil, or similar liquids to start or freshen up a fire in your RAIS stove. Keep all such liquids well away form the stove while it is in use. - Page 28 User Manual Q-Tee II USA User Manual Q-Tee II USA / Q-Tee II C USA / US English Maintaining the installation. Establish a routine for the fuel, wood burner and firing tecnique. Check daily for creosote build-up until experience shows how often you need to clean to be safe.
-
Page 29: Cleaning The Smoke/Baffle System
User Manual Q-Tee II USA / Q-Tee II C USA US English Cleaning of smoke chicane Remove the smoke con- verter plate by tilting it to one side and turning it a little slantwise. Pull out the plate carefully. Then remove the smoke impediment by lifting it up and moving it forward. -
Page 30: Disposal Of Ashes
User Manual Q-Tee II USA User Manual Q-Tee II USA / Q-Tee II C USA / US English reosote ormation and eed For emoval hen Wood is burned sloWly it produces tar and other organic vapors Which combine With expelled moisture to Form creosote... -
Page 31: Trouble Shooting
User Manual Q-Tee II USA / Q-Tee II C USA US English Trouble Shooting Smoke seeping through the door: • Not enough draft in the chimney (<12 Pa) • Check if there are any obstructions in the chimney or the wind pipe •... -
Page 32: Spare Part Drawing
Spare parts Q-Tee II USA Only use the specified original Rais components! If spare parts other than those recommended by RAIS are used, the warranty is voided. All replaceable parts can be bought as spare parts from your RAIS distributor. - Page 33 User Manual Q-Tee II USA / Q-Tee II C USA US English Spare parts Q-Tee II USA...
- Page 34 Spare parts Q-Tee II C USA Only use the specified original Rais components! If spare parts other than those recommended by RAIS are used, the warranty is voided. All replaceable parts can be bought as spare parts from your RAIS distributor.
- Page 35 User Manual Q-Tee II USA / Q-Tee II C USA US English Spare parts Q-Tee II C USA...
- Page 36 RAIS A/S Industrivej 20 DK-9900 Frederikshavn www.rais.com...
