Operation
6.10

Replacing the DC plug fuse

➤ Pull the adapter sleeve (fig. 9 4, page 5) off of the plug.
➤ Unscrew the screw (fig. 9 5, page 5) out of the upper half of the housing
(fig. 9 1, page 5).
➤ Carefully raise the upper half of the housing from the lower (fig. 9 6, page 5)
half.
➤ Take out the contact pin (fig. 9 3, page 5).
➤ Replace the defective fuse (fig. 9 2, page 5) with a new fuse of the same type
and rating (3AG, Fast Acting, 10 A).
➤ Re-assemble the plug in the reverse order.
6.11

Replacing the light bulb (CF25, CF35, CF40, CF50)

➤ Press the switch pin (fig. 0 2, page 5) downwards so that the transparent part
(fig. 0 1, page 5) of the lamp can be removed at the front.
➤ Replace the light bulb.
I
NOTE
The LEDs in the light bulb must be aligned with the transparent part of
the lamp.
➤ Press the transparent part of the lamp back into the housing.
